- Page 1 Phone: 800-669-1303 or 801-561-0303 Fax: 801-255-2312 e-mail: treborservice@idexcorp.com SS40 Surge Suppressor Operation / Maintenance Manual SERIAL NUMBER (located on back of product): 12/16/2020 – MSS40-AB PATENTS: U.S. 05971402...
-
Page 2: Table Of Contents
Inline ...................... 5 MAINTENANCE ......................6 RECOMMENDED SPARE PARTS ..............6 TOOLS ........................ 6 PARTS ILLUSTRATION ..................6 PARTS LIST ....................... 7 CLEAN-UP ......................7 DISASSEMBLY ....................7 ASSEMBLY ......................8 WARRANTY ......................... 9 SS40 SURGE OPERATION / MAINTENANCE MANUAL CONTENTS... -
Page 3: Installation
• Remove port plug from pump. • Install new port seal. • Hand tighten surge suppressor into port. Do not over tighten. ATTENTION: Over-tightening adapter into pump will result in pump damage. SS40 SURGE OPERATION / MAINTENANCE MANUAL PAGE 3... -
Page 4: Mounted
NOTE: Install the branch tee in the pump air supply port to replace the pump air connector fitting and then use the supplied tubing to connect between the pump and the “SUP” port suppressor fitting. NOTE: When mounted to a Maxim 25E/U pump, the SS40 requires it’s own separate air supply line. PAGE 4... -
Page 5: Inline
1.2.b Inline Figure 1-2 The SS40 Inline must be mounted in an upright position. See Figure 1-3: Maxim Figure 1-3: Maxim 25 SS40 SURGE OPERATION / MAINTENANCE MANUAL PAGE 5... -
Page 6: Maintenance
The following tool kit is recommended as standard service equipment. KTSS40-00-A Tool Kit, which includes: Part No Description 98003108 Torque Wrench, 30-150 Ft. Lb. 1/4” Drive Handle 98003305 T0129 Strap Wrench 3/4” Pin Tool T0146 1/2” Pin Tool T0148 PARTS ILLUSTRATION PAGE 6 SS40 SURGE OPERATION / MAINTENANCE MANUAL... -
Page 7: Parts List
Mounting Bracket 98003207 Screw CLEAN-UP The SS40 Surge Suppressor may be flushed clean with either DI water or a rinse tank for 10 to 15 minutes. DISASSEMBLY During the life of the Surge Suppressor it may be necessary to perform certain preventative maintenance procedures to ensure its continued high performance. -
Page 8: Assembly
Reinstall suppressor on pump to hand tight plus 1/4 turn. If connection leaks, increase an additional 1/8 turn only. If leaking cannot be stopped, remove suppressor, replace disk seal and check mating surfaces for scratches or depressions. PAGE 8 SS40 SURGE OPERATION / MAINTENANCE MANUAL... -
Page 9: Warranty
Operation/Maintenance Manual. TREBOR’s obligation under this warranty is limited to repairing or replacing, at TREBOR’s option and at the TREBOR factory, any part or parts thereof which shall, within 1 year after delivery thereof to the original purchaser, be demonstrated to TREBOR’s satisfaction to have been defective.
