HP-2999
COLOUR TELEVISION
Service Manual
MODEL :
HP-2999
THAILAND
Features
218 programs present
Multiple picture & volume modes
On/off timer
Child-lock Program scan
Slide curtain power on/off display
DVD component input
Haier Group
Manual code: M-AS-TH-HP-2999-9363
Edition: 2003.0222
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HP-2999 and is the answer not in the manual?

Questions and answers

Related Manuals for Haier HP-2999

Summary of Contents for Haier HP-2999

  • Page 1 HP-2999 COLOUR TELEVISION Service Manual MODEL : HP-2999 THAILAND Features 218 programs present Multiple picture & volume modes On/off timer Child-lock Program scan Slide curtain power on/off display DVD component input Haier Group Manual code: M-AS-TH-HP-2999-9363 Edition: 2003.0222...

  • Page 2: Table Of Contents

    Contents 1.Contents 1.Contents……………………………………………………………………… ..1 2. Product code illumination and series introduction………….…. …..2 3. Features…………………………………………………………….…..… ..2 Specifications…………………………………………………………..……3 Safety Precaution……………………………………………………….….4 Warning and cautions………………………………………………….….5 Net Dimension …………………………………………………………….11 Parts and Functions………………………………………………………12 Remote controller Functions……………………….…………………..13 10 Program Diagram…………………………………………………………14 11. Maintenance Service and Trouble Shooting…………………..……22 12. Circuit Diagram……………………………………………………….….27 13.

  • Page 3: Product Code Illumination And Series Introduction

    Product code illumination and series introduction 2. Product code illumination and series introduction P 2 9 Appearance serial CMOS chip type CRT catercorner 29 inch HAIER 3.Features 1) 218 programs present 2) Multiple picture & volume modes 3) On/off timer 4) Child-lock Program scan...

  • Page 4: Specifications

    Specificatio 4. Specifications FUNCTION FUNCTION TDA9373 NO. of built-in speakers Main IC 5W+5W+8W Audio output power(W) Total power input W PAL SECAM Color system 150-250V Voltage range V Audio system 50HZ Power frequency Hz NO.of channels ENG/THA Time of sleep timer(MINS) OSD language 42Kg Net weight(KG)

  • Page 5: Safety Precaution

    SAFETY PRECAUTIONS 5. SAFETY PRECAUTIONS INPORTANT SAFETY NOTICE These parts are identified by many electrical and mechanical parts in this chassis have special safety-related characteristics. It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent X-RADIATION, Shock, Fire, or other Hazards.

  • Page 6: Warning And Cautions

    Warning and Cautions 6 Warning and Cautions 1. When you clean the TV set, please pull 4. To prevent the TV set from firing and out the power plug from AC outlet. Don't electric shock, don't clean the cabinet and the screen with make the TV set rain benzene, petrol and other chemicals.
  • Page 7 Warning and Cautions Explanation on the display tube Generally, it is not needed to clean the tube surface. However, if necessary, its surface can be cleaned with a dry cotton cloth after cutting off the power. Don’t use any cleanser. If using hard cloth, the tube surface will be damaged.
  • Page 8 Warning and Cautions by this service manual might be equipped. 7. Do not apply AC power to this instrument and/or any of its electrical assemblies unless all solid-state device heat sinks are correctly installed. 8. Always connect the test receiver ground lead to the receiver chassis ground before connecting the test receiver positive lead.
  • Page 9 Warning and Cautions Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise even some normally harmless motions such as mutual brushing of your clothes’ fabric or lifting of your foot from a carpeted floor might generate static electricity sufficient to damage an ES device.) General Soldering Guidelines 1.
  • Page 10 Warning and Cautions Draw away the melted solder with an anti-static suction-type solder removal device (or with solder braid) before removing the IC. Replacement Carefully insert the replacement IC in the circuit board. Carefully bend each IC lead against the circuit foil pad and solder it. Clean the soldered areas with a small wire-bristle brush.(It is not necessary to reapply acrylic coating to the areas).
  • Page 11 Warning and Cautions 1. Clip each fuse or resistor lead at top of the circuit board hollow stake. 2. Securely crimp the leads of replacement component around notch at stake top. 3. Solder the connections CAUTION: Maintain original spacing between the replaced component and adjacent components and the circuit board to prevent excessive component temperatures.

  • Page 12: Net Dimension

    Net Dimension 7 Net Dimension 790mm 525mm Figure 1...

  • Page 13: Parts And Functions

    Parts and Funcitions 8 Parts and Funcitions Front and side panel of the TV set １ ． Ｆｒ ｏ ｎ ｔ 　 Ｐａ ｎｅ ｌ 　　　　　ＭＥＮＵ 　　　　　ＴＶ／ＡＶ Ｐ Remote sensor:let The remote controller aim here the set can receive remote control signal.

  • Page 14: Remote Controller Functions

    Remote Controller Functions 9. Remote Controller Functions MARK FUNCTION DESCRIPTION Program scan Standby SWAP Mute TV/AV TV/VIDEO SELECTION -VOL+ VOLUME CONTROL -CH+ CHANNEL NUMBER UP/DOWN PICTURE MENU SOUND SOUND MENU TIME MENU TIME FUNCTION MENU FUNC TION ONE DIGIT SELECTION -/-- MENU DISPLAY MENU...

  • Page 15: Programdiagram

    Program Diagram 10.ProgramDiagram OPERATION MENU TUNE COLOR SYSTEM AUTO SOUND SYSTEM BAND VHFL SKIP PROG NO SEARCH FINE TUNE AUTO SEARCH 6.Selecting color system Usually this should be set in the Auto position. However if the colours displayed on the screen are incorrect you can manually select the correct colour system. When you have finished remember to turn it back to auto again so that other programs will still work correctly.
  • Page 16 Program Diagram O P E R A T IO N M E N U 7. Program ski p The Program ski p feat ure enabl es you t o ski p/ hi de program s t hat you do not w i sh t o be di spl ayed w hen usi ng t he C H +/ - but t ons.
  • Page 17 O P E R A T IO N M E N U Sound A djustm ents Press t he m enu but t on t w i ce or press t he Sound but t on on t he rem ot e cont rol , t o di spl ay t he Sound set t i ng m enu.
  • Page 18 O P E R A T IO N M E N U Functi on M enu 1. B ackground (If t he si gnal i s very poor or t here i s no FU N C T I O N i nput si gnal t he pi ct ure w i l l m ut e t o bl ack) B A C K G R O U N D B L A C K ST R E TC H...
  • Page 19 M U L T I F U N C T IO N T IM E R M ul ti Functi on T i m er T he T V set has in built a com prehensive tim er TIM E that has F ive basic functions C LO C K - - : - -...
  • Page 20 M U L T I F U N C T IO N T IM E R t o adj ust t he am ount of t i m e before t he TV set w i l l aut om at i cal l y t urn off.
  • Page 21 G E N E R A L O PE R A T IO N 1. C hannel C hangi ng (218 possi bl e channel s) U se ei t her t he C H +/ - but t ons on t he rem ot e or t he front of t he T V set t o change t he channel s.
  • Page 22 G E N E R A L O PE R A T IO N 6. P reset Sound M odes O ur engineers have designed in 4 com m only used sound m odes to allow the best possible sound to be selected quickly. E ach m ode is selected in turn by pressing the "S ST D "...

  • Page 23: Maintenance Service And Trouble Shooting

    Maintenance Service and Trouble Shooting 11. Maintenance Service and Trouble Shooting a. TROUBLESHOOTING PROCESS Grating off Check +B Abnormal Normal Disconnect R214 to Check lamp filament, check main voltage release and grating voltages Normal Abnormal None Check TDA9373 Check R415, R505 Check CRT voltage and R526...
  • Page 24 Maintenance Service and Trouble Shooting Horizontal bright line Check pin 21 and 22 of N201 for curve output None Check R228 and C227 Check 16V and 47V voltage Abnormal Normal Check N201 Check R413 and R408 Check N301 peripheral circuit Check T444 Disabled remote control Check receiver voltage...
  • Page 25 Maintenance Service and Trouble Shooting Pincushion distortion Enter factory mode and adjust 5EWP to see if picture changes None Check pin 20 of N201for voltage Check and ground resistance V401 and DZ401 Check pin 12 N301 for voltage Check C416 and ground resistance Check and replace Check and replace...
  • Page 26 Maintenance Service and Trouble Shooting TV program sound off Check pin 7 of N201 for Press mute button, or check noise suppression and replace N201 Check N201 44 for sound signal output None Check and replace N201 Check N701 3 for sound signal output None Check N701 15...
  • Page 27 Maintenance Service and Trouble Shooting b. Troubleshooting guide To assist in location possible faults use help guide below BREAKDOWN PHENOMENON CHECKING PICTURE SOUND The aerial direction and connection Picture with snow Noise This is called ghosting which can be minimized with an outside aerial, and good quality cable and terminations.

  • Page 28: Circuit Diagram

    Circuit Diagram 12. Circuit Diagram a. Pane hint picture SF101 TU101 sound surface Speaker1 N610 N701 TUNER Sound filte Sound processing and amplifying amplifying Speaker2 Dark current check-up MUTE N201 RM201 N501 Microprocessor and signal processor remote Video frequency control amplifying PROM The second SIF filter...
  • Page 29 Circuit Diagram Circuit Diagram MENU TV/AV TJC3-2Y AV1-VIN AV1-AL AV1-AR CNS01 RT01 CT01 CNB02 RT02 RT03 CNS02 RB03 RB06 RB08 RB07 RB09 CNB01 1.8K 1.2K N702 CNT01 TJC3-2Y TJC3-10A HEF4053 A6-5V R208 A6-5V N202 R219 R222 R223 R220 R212 R211 R215 24C08 CN201...
  • Page 30 Circuit Diagram PCB Diagram Figure 6...

  • Page 31: Circuit Explanation

    Circuit Explanation 13. Circuit Explanation The UOC module comprised of Philip super advanced CMOS chip TDA9373 is used for model 34F9B-T color TV pictures and text. This product has I C bus-mastering digital control system and DVD component terminals (or SCART terminal) for auto sound identification, independent woofer volume control, English and Russian picture texts, treble and bass tone increase, image and sound mode for individual preference, picture size zooming and 218 channel storage.
  • Page 32 Circuit Explanation 1.2.7 KA7630 Secondary power integrated circuit Electric circuit analyses 2.1 Super single chip integrated circuit TDA9373 As a super large-scale decoding and microprocessing integrated circuit, TDA9373 is comprised of a microprocessor, picture image intermediate frequency amplification, sound intermediate frequency amplification, line and field scanning, dwarf signal processing, color decoding, sound filtering and auto identification, luminance separation, high voltage tracking and over voltage protection.
  • Page 33 Circuit Explanation DECS.DEM 5.9M 3.6M GND2 SND.PLL 6.3M 4.7M 6.2M 3.8M H.OUT F.B.L.SO 6.4M 4.4M AUO.EXT EHTO 21.8K PLL.IF 6.4M 4.6M IF.VO/SVO 4.3M 4.6M CVPS.INT 5.4M 4.1M GND1 CVBS/Y 6.2M 4.0M CHROMA AUD.OUT 6.4M 4.8M 0.86K 0.86K INSS.W2 BL R2/V.IN 6.3M 4.5M G2/Y.IN...
  • Page 34 Circuit Explanation suitable for M sound signal. The IF signals which have passed through sound carrier deep trap by sound surface filter will be sent to the (23) and (24) of N201 TDA9373 . HF amplification AGC will be sent out from the (27) of N201 TDA9373 under the control of I C bus for the gain control of HF tuner.
  • Page 35 Circuit Explanation from (13) and (20) will be directly fed into the (12) of woofer amplification integrated circuit N610 (TDA7297); and, as for the audio signals that have gone through sound tone processing , the audio signals exported from the (18) and (15) will be directly fed into the (12) and (4) of the sound amplifying integrated circuit N601 TDA7297 .
  • Page 36 Circuit Explanation Post-AV audio input of right channel 4.6M 3.2M Woofer control 6.9M 4.8M Pre-AV audio input of right channel 4.6M 3.2M 2.6 Analysis of sound amplifying circuit The sound amplifying circuit is comprised of an integrated circuit TDA7297 and peripheral components.
  • Page 37 Circuit Explanation The data is to be tested under the mode of 49.75MHz PAL D/K and cylindrical color card, using a model FLUKE 79 instrument. Table 5 Resistance to Ground R Working Function Forward Test Back Voltage V Test Sound output from right channel 12.8K 12.7K Sound output from right channel...
  • Page 38 Circuit Explanation both the forward and return strokes of TDA8350Q , the two power supplies being +16.5V and +46V respectively. Table 6 lists the pin functions and test data of TDA8350Q as the reference for maintenance. The data is to be tested under the mode of 49.75MHz PAL D/K and cylindrical color card, using a model FLUKE 79 instrument.
  • Page 39 Circuit Explanation C414, C415 and C427 are the capacitors for line return stroke, C406 is the line S correction capacitor, and L402 is the linear inductance for line. E-W geometric correction signals are sent out by the (20) of N201 and fed into the (12) of N301, which, after being rectified, will be sent out from the (11) of N301 and, after being amplified by a triode V401(KSA614Y) and waveshaped by C403 and L401, put into line scanning circuit for a geometric correction in transmeridional direction.
  • Page 40 Circuit Explanation G input 7.6K 7.4K Ground Dark current detection output 3.1M 2.7M Power supply 182.6 34.2K 28.2K R cathode output 97.6 1.4M 2.6M G cathode output 100.1 1.4M 2.6M B cathode output 93.4 1.4M 2.6M 2.10 Analysis of power switch circuit A typical self-excited pulse power switch has been chosen for this TV receiver.

  • Page 41: Adjustment

    Adjustment 14. Adjustment Operating method: After a normal start-up, successively push the combination keys of mute, screen display, -/--, screen display and mute on the workshop remote controller to enter a maintenance menu. Push numeric 0 7 keys for a rapid choice in the maintenance menu. Push P+/- CH+/- key to choose items to be adjusted;...
  • Page 42 Adjustment identifiable 50/60hz systems. Push numeric 3 key: Maintenance menu 3 Picture adjustment Table 10 Table 10 Adjusting Item Description Default Remarks range 0~63 Mild color Red 0~63 Mild color Green White neutralizing red 0~63 White neutralizing green 0~63 White neutralizing blue 0~63 YDFP Luminance delay PAL...
  • Page 43 Adjustment Push numeric 6 key Analogue of picture mode Table 13 Table 13 Adjusting Item Description Default Remarks range 2CON Standard mode contrast 0~100 Unadjustable 2BRI Standard mode luminance 0~100 Unadjustable 2COL Standard mode color 0~100 Unadjustable 2SHP Standard mode definition 0~100 Unadjustable 3CON...

  • Page 44: Exploded View

    Exploded View 15. Exploded View EXPLODED VIEW OF CABINET PARTS Model: HP-2999...
  • Page 45 Exploded view part list Exploded view part list Location Parts Name Material code Type Notes Front Frame 0090201362 MTAA2035AA--Q 0094001005 A68LWF188X50 Washer 0090100122 MTBH2003BA--Q Combined Nut 0090600018 Degaussing coil clip 0090800186 BJZ0002-----Q CRT grounding assembly 0090401147 JE229B02-4--Q Speaker Set 0090802664 BJG5007-----Q Degaussing coil 0094500529...

  • Page 46: List Of Parts

    List of Parts 15. List of Parts Location Material Parts Name Type Remark 0090300076 Washer 1mm φ6.5 0090100128 Washer 1MM φ6.5 0090800171 Degaussing coil tie BJZ0001-----Q 0090600069 M6 (98025) 0094001005 M68LWF188X50(JJ) 0094500529 Degaussing coil HXC-74T 0094500982 Degaussing coil AHA-HXC-RR-3A 0090200287 clamp MTAJ0068AH--Q 0090400840...
  • Page 47 List of Parts Type Location Material Parts Name Remark RT05 0094102124 Resister RT13-1/6W-100Ω±5%-07-A-A CT01 0094201773 Capacitor CL11-100V-1000PF-K-05-C-A CT02 0094202149 Capacitor CD110-16V-10μF-M-05-F-A CNT06 0094300168 S-Video terminal CNT01 0094300112 Connect housing TJC3-4A A1000 0094000216 Infrared sensor HS0038 0094000226 Power switch KDC-A11 0094300110 Connect housing TJC1-2A VD001...
  • Page 48 List of Parts Type Location Material Parts Name Remark V403C 0094400184 Transistor 2SD1887YD V403D 0090600076 Screw SJ2831-87 ST3*10F N301B 0090100024 Heatsink QHS-30152C1 N301C 0094400185 TDA8350Q N801B 0090100014 plastic board QHS-10162A N301D 0090600099 Screw SJ2831-87 ST3X8F N501A 0090100016 Heatsink QHS-30175D N501B 0094400186 TDA6107Q N501C...
  • Page 49 List of Parts Type Location Material Parts Name Remark C819 0094200717 Capacitor CT1-500V-06b-2B4-561-K-05-C-A C404 0094201355 Capacitor CT1-10-2B4-500V-1000PF-K-05-C-A C814 0094200067 Capacitor CT81-2KV-10b-2B4-561-K-07-C-A C407 0094201373 Capacitor CT81-10-2B4-2KV-680PF-K-07-C-A C427 0094201356 Capacitor CT81-10-2B4-2KV-1000PF-K-07-B-A C503 0094201487 Capacitor CT81-10-2F4-3KV-10000pF-Z-07-C-A C502 0094201234 Capacitor CL23B-AC250V-0.1μF-K-15-B-A C805 0094201061 Capacitor CT81-10B-2B4-2KV-2200PF-K-10-C-A C804 0094201061...
  • Page 50 List of Parts Type Location Material Parts Name Remark Z204 0094600042 trap TPT01B Z203 0094600093 trap XT4.5MHz SF101 0094600082 Filter D38.9 F801 0094000012 Fuse T4A/250V F801A 0090100118 Fuser holder FC503 F801B 0090100118 Fuser holder FC503 L402 0094500539 Inducer LX170 L401 0094500030 Inducer AA27-40001B...
  • Page 51 List of Parts Type Location Material Parts Name Remark R252 0094100017 Resister RT13-1/6W-100Ω±5%------T R507 0094100017 Resister RT13-1/6W-100Ω±5%------T R508 0094100017 Resister RT13-1/6W-100Ω±5%------T R509 0094100017 Resister RT13-1/6W-100Ω±5%------T R510 0094100017 Resister RT13-1/6W-100Ω±5%------T R511 0094100017 Resister RT13-1/6W-100Ω±5%------T R512 0094100017 Resister RT13-1/6W-100Ω±5%------T R705 0094100017 Resister RT13-1/6W-100Ω±5%------T R706 0094100017...
  • Page 52 List of Parts Type Location Material Parts Name Remark R207 0094100029 Resister RT13-1/6W-4.7KΩ±5%------T R262* 0094100029 Resister RT13-1/6W-4.7KΩ±5%------T R710* 0094100029 Resister RT13-1/6W-4.7KΩ±5%------T R604 0094100072 Resister RT13-1/6W-6.2KΩ±5%------T R607 0094100072 Resister RT13-1/6W-6.2KΩ±5%------T R847 0094100072 Resister RT13-1/6W-6.2KΩ±5%------T R610* 0094100072 Resister RT13-1/6W-6.2KΩ±5%------T R611* 0094100072 Resister RT13-1/6W-6.2KΩ±5%------T R848 0094100072...
  • Page 53 List of Parts Type Location Material Parts Name Remark R503 0094101142 Resister RS11-1/2W-1.8KΩ±20%------T R801 0094101361 Resister RS11-1/2W-3.3MΩ±20%------T R808 0094101361 Resister RS11-1/2W-3.3MΩ±20%------T R809 0094101362 Resister RS11-1/2W-4.7MΩ±20%------T R260 0094100106 Resister RJ13-1/6W-9.1K-J------T R262 0094100106 Resister RJ13-1/6W-9.1K-J------T R259 0094102210 Resister RJ13-1/6W-100KΩ-J------T R203 0094100108 Resister RJ13-1/6W-10K-F------T R204 0094100108...
  • Page 54 List of Parts Type Location Material Parts Name Remark C613 0094201741 Capacitor CL21X-50V-1000PF-J------F C717 0094201735 Capacitor CL21X-50V-5600PF-J------F C402 0094201436 Capacitor CL21X-50V-0.01μF-J------F C860 0094201436 Capacitor CL21X-50V-0.01μF-J------F C721 0094200997 Capacitor CL11-63V-0.015μF-J------F C723 0094200997 Capacitor CL11-63V-0.015μF-J------F C809 0094201538 Capacitor CL11-50V-0.047μF-K------F C259 0094201090 Capacitor CL21X-50V-0.022μF-J------F C713 0094201437...
  • Page 55 List of Parts Type Location Material Parts Name Remark C740 0094200043 Capacitor CD110-50V-1μF-M------F C830 0094200043 Capacitor CD110-50V-1μF-M------F C224 0094200044 Capacitor CD110-50V-2.2μF-M------F C603 0094200044 Capacitor CD110-50V-2.2μF-M------F C614 0094200044 Capacitor CD110-50V-2.2μF-M------F C712 0094200046 Capacitor CD110-50V-10μF-M------F C719 0094200046 Capacitor CD110-50V-10μF-M------F C829 0094200046 Capacitor CD110-50V-10μF-M------F C201 0094200046...
  • Page 56 List of Parts Type Location Material Parts Name Remark VD810 0094400049 Diode 1N4148------T VD815 0094400049 Diode 1N4148------T VD816 0094400049 Diode 1N4148------T VD850 0094400049 Diode 1N4148------T VD101 0094400191 Diode 1SS133T-72------T VD402 0094400473 Diode 1N4004------T VD403 0094400051 Diode T1N4004------T VD802 0094400052 Diode TB1206------T VD407 0094400053...
  • Page 57 List of Parts Type Location Material Parts Name Remark V208 0094400192 Transistor KSC815-YTA------F V209 0094400192 Transistor KSC815-YTA------F V212 0094400192 Transistor KSC815-YTA------F V213 0094400192 Transistor KSC815-YTA------F V801 0094400192 Transistor KSC815-YTA------F V803 0094400192 Transistor KSC815-YTA------F V851 0094400192 Transistor KSC815-YTA------F V211 0094400193 Transistor KSR1010TA------F V202 0094400193...
  • Page 58 List of Parts Type Location Material Parts Name Remark EY435 0090100078 Rivet φ2.3mm*3.0mm EY601 0090100078 Rivet φ2.3mm*3.0mm EY602 0090100078 Rivet φ2.3mm*3.0mm EY603 0090100078 Rivet φ2.3mm*3.0mm EY604 0090100078 Rivet φ2.3mm*3.0mm EY605 0090100078 Rivet φ2.3mm*3.0mm EY606 0090100078 Rivet φ2.3mm*3.0mm EY607 0090100078 Rivet φ2.3mm*3.0mm EY608 0090100078...
  • Page 59 List of Parts Type Location Material Parts Name Remark W981 0094101102 Jumper φ0.6mm/5mm------B W134 0094101102 Jumper φ0.6mm/5mm------B W210 0094101102 Jumper φ0.6mm/5mm------B W225 0094101102 Jumper φ0.6mm/5mm------B W406 0094101102 Jumper φ0.6mm/5mm------B R505 0094101102 Jumper φ0.6mm/5mm------B W711 0094101102 Jumper φ0.6mm/5mm------B W103 0094101102 Jumper φ0.6mm/5mm------B W104 0094101103...
  • Page 60 List of Parts Type Location Material Parts Name Remark VD615 0094101103 Jumper φ0.6mm/7.5mm------B W701 0094101103 Jumper φ0.6mm/7.5mm------B W702 0094101103 Jumper φ0.6mm/7.5mm------B W703 0094101103 Jumper φ0.6mm/7.5mm------B W704 0094101103 Jumper φ0.6mm/7.5mm------B W707 0094101103 Jumper φ0.6mm/7.5mm------B W712 0094101103 Jumper φ0.6mm/7.5mm------B W714 0094101103 Jumper φ0.6mm/7.5mm------B W715 0094101103...
  • Page 61 List of Parts Type Location Material Parts Name Remark W306 0094101104 Jumper φ0.6mm/10mm------B W308 0094101104 Jumper φ0.6mm/10mm------B W309 0094101104 Jumper φ0.6mm/10mm------B W310 0094101104 Jumper φ0.6mm/10mm------B W311 0094101104 Jumper φ0.6mm/10mm------B W312 0094101104 Jumper φ0.6mm/10mm------B W401 0094101104 Jumper φ0.6mm/10mm------B W404 0094101104 Jumper φ0.6mm/10mm------B W407 0094101104...
  • Page 62 List of Parts Type Location Material Parts Name Remark W417 0094101105 Jumper φ0.6mm/12.5mm------B W501 0094101105 Jumper φ0.6mm/12.5mm------B W632 0094101105 Jumper φ0.6mm/12.5mm------B W803 0094101105 Jumper φ0.6mm/12.5mm------B W814 0094101105 Jumper φ0.6mm/12.5mm------B W982 0094101105 Jumper φ0.6mm/12.5mm------B L209 0094101105 Jumper φ0.6mm/12.5mm------B W237 0094101106 Jumper φ0.6mm/15mm------B W255 0094101106...

  • Page 63: Damageable Parts List

    16. Damageable Parts List MATERIAL REPARATION LOCATION PARTS NAME TYPE Q'ty CODE RATE(%) N202 0094400636 INTEGRATED CIRCUIT CAT24C08P 0.1188 N301C 0094400185 INTEGRATED CIRCUIT TDA8350Q 0.0877 V403C 0094400184 TRIODE 2SD1887YD 0.0554 N501B 0094400186 INTEGRATED CIRCUIT TDA6107Q 0.0438 N201 0094401505 INTEGRATED CIRCUIT TDA9373PS/N2/5I 0.0145 N802...

  • Page 64: Information Of Resistors And Capacitors

    Information of Resistors and Capacitors 17. Information of Resistors and Capacitors RESISTORS & CAPACITORS-PARTS NO.CODE Notes: 1.part numbers are indicated on most mechanical parts. Please use this part number for parts orders. 2.The unit of resistance is (ohm).K=1000 ,M=1000K 3.The unit of capacitance is F(microfarad).
  • Page 65 Information of Resistors and Capacitors Terminal view of transistors 2SC1815-Y------F 2SC4544----B-A 2SA1015-Y------F 2SB1569A-E----B-A EXPORT 2SC752GTM-Y------F EXPORT 2SP2400A-E----B-A EXPORT 2SC2878-A(TEM)------F EXPORT 2SC3853(2SC3852)----E-A RN1204(DTC144ESATP) EXPORT KSR1010TA 3DD2553----B-A 2SA562TM-Y------F KSR2010TA 3CA688----E-A 2SC3355------F EXPORT 2SC3853(2SC3852)----B-A 2SD18887YD...
