DARTBOARD CABINET & DARTBOARD SET ASSEMBLY INSTRUCTIONS
Parts Listing
#1 Mounting Plate (1 PC)
#4 Nails
Dartboard cabinet installation height and distance
Assembly Instructions
Step 1 Attach #2 screw and #3 bumpers to back of dartboard, DO NOT insert #2 all the way into board.
This can then be adjusted at step 4.
#2 Short Screw
(3 PCS)
#5 Wall Anchors
(1 PC)
#3 Bumpers
(3 PCS)
#6 Longer Screws
(3 PCS)
(2 PCS)
Advertisement
Table of Contents
Summary of Contents for GSE GD-2002
- Page 1 DARTBOARD CABINET & DARTBOARD SET ASSEMBLY INSTRUCTIONS Parts Listing #1 Mounting Plate (1 PC) #2 Short Screw (1 PC) #3 Bumpers (3 PCS) #4 Nails (3 PCS) #5 Wall Anchors (3 PCS) #6 Longer Screws (2 PCS) Dartboard cabinet installation height and distance Assembly Instructions Step 1 Attach #2 screw and #3 bumpers to back of dartboard, DO NOT insert #2 all the way into board.
- Page 2 Step 2 Drill holes for the center attachment to the wall. If fitting the cabinet to a concrete or solid wall which is recommended insert the wall anchors, if not then the screws go directly into the wall. Step 3 Put #6 screws through mounting plate, cabinet and then into the wall anchors. Step 4 Hanging the dartboard on the mounting plate and adjust screw in back of dartboard to provide secure fit.
