- Page 1 TQ3 + Throttle Quadrant USER'S MANUAL Rev. 1.2 - November 2020 1. PACKAGE LIST A) TQ3+ Throttle quadrant B) Clamp for TQ3+ C) Screws for clamp D) Allen key TQ3+ | User's manual...
-
Page 2: Clamp Assembly
2. CLAMP ASSEMBLY You have two ways for assembling the clamp: (1) on the back or (2) on the bottom, to get the best position for you. If you choose the bottom position, you must unscrew the two front rubber feet before you screw the clamp. Connect the USB cable to the computer where the flight simulator software is running. - Page 3 3. CONTROLS 4. CALIBRATION ON WINDOWS Adjusting the lever’s hardness If you want you can adjust the lever’s hardness tightening the wheel (K) It is not necessary the calibration on windows because the located on the right side of the device. device is calibrated from factory but you can use the calibra- tion Windows tab to test the device.
- Page 4 5. CONFIGURATION ON FLIGHT SIMULATION SOFTWARE As the TQ3 + control interacts with any computer as a normal HID device (Joystick), this make it compatible with any FLIGHT SIMULATOR software. The follow tables tells how to configurate the TQ3 + on the most popular FLIGHT SIMULATOR software, FSX-Prepar3D and X-Plane. FSX-Prepar3D TQ3 + Configuration options on FSX-Prepar3D Through VFTest&Calibrate-S...
- Page 5 X-Plane TQ3 + Configuration on X-Plane Through X-Plane Configuration\Joystick tab: Full functionality: Throttle-Rev, Propeller-Fth, Mixture-CutOFF. 1. Open X-Plane and go to Configuration\Joystick tab. 2. Select TQ3 + and calibrate the axes if required. 3. Assign the according action to each axis: Throttle-Prop-Mixture. THROTTLE lever configuration: - Reverse axis unchecked.
