PRIMARY SUMP PUMP
BACKUP POWER SYSTEM
INSTALLATION AND OPERATING INSTRUCTIONS
Specifications
Model #
Input Voltage
Amp Rating
Output Voltage
Battery Charging Current
Rated Power
Size
Weight
Color
Warranty
NOTICE: INSTALLER - Please provide this manual to the property owner
responsible for the service and maintenance of the sump pump system.
INVRIC20
DC 12V
12.5A
AC100V / 110V ±10%
10A
1500W
18.1" x 7.8" x 3.1"
13.4 lbs.
Black
3 Years
Performance
Output Comparison
Competitive
Model
Inverter
12v 75AH
Battery
at full charge
Richtech
Pump
1/2 HP Cast Iron
Output Volume
792 Gal
Richtech
Inverter
12v 75AH
at full charge
Richtech
1/2 HP Cast Iron
3,505 Gal
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for RICHTECH INVRIC20
- Page 1 PRIMARY SUMP PUMP BACKUP POWER SYSTEM INSTALLATION AND OPERATING INSTRUCTIONS Specifications Model # INVRIC20 Input Voltage DC 12V Performance Amp Rating 12.5A Output Voltage AC100V / 110V ±10% Output Comparison Battery Charging Current Competitive Richtech Model Inverter Inverter Rated Power...
- Page 2 Keep visitors at a safe distance from work area. • Make workshop child-proof – with padlocks, master switches, and by removing starter keys. • When wiring an electrically driven pump, follow all electrical and safety codes that apply. ©2021 RICHTECH INDUSTRIES 1.800.677.7791 RICHTECHINDUSTRIES.COM...
- Page 3 The STATUS INDICATOR LED will turn RED when the Power Unit is overloaded, overheating, low household voltage, or a short circuit. See Troubleshooting Guide for more information. STATUS INDICATOR CHARGER SWITCH POWER INDICATOR CHARGING INDICATOR POWER SWITCH REVERSE POLARITY OUTPUT POWER PROTECTION OUTLETS POSITIVE NEGATIVE BATTERY BATTERY TERMINAL TERMINAL (RED) (BLACK) COOLING FANS ©2021 RICHTECH INDUSTRIES 1.800.677.7791 RICHTECHINDUSTRIES.COM...
- Page 4 4. If the pump is using the series (piggyback) cord plug, the plugs may not be connected tightly together. 5. Float may be obstructed. Make sure float is free and not interfering with the pit wall or other obstruction. 6. If all symptoms check OK, the motor winding may be open. Consult factory. ©2021 RICHTECH INDUSTRIES 1.800.677.7791 RICHTECHINDUSTRIES.COM...
- Page 5 3 months or more frequently if the unit is mounted in a an area where excess dust or debris my be present. Deep Cycle Batteries generally last between 3 to 5 years in a sump pump backup installation. It is recommended that the battery is tested every 6 months to ensure it is ready for service. ©2021 RICHTECH INDUSTRIES 1.800.677.7791 RICHTECHINDUSTRIES.COM...
- Page 6 This warranty is effective for three years from the date of installation. Richtech will repair or replace at its option for the original purchaser any part or parts of its Primary Sump Pump Backup Power System found by Richtech to be defective in material or workmanship.
- Page 7 FOR YOUR RECORDS Model Number Serial Number Date of Purchase Place of Purchase Installed by: ©2021 RICHTECH INDUSTRIES 1.800.677.7791 RICHTECHINDUSTRIES.COM...
- Page 8 ©2021 RICHTECH INDUSTRIES 1.800.677.7791 RICHTECHINDUSTRIES.COM...
