Vinyl Patio Cover
OWNER'S MANUAL /
Instructions for Assembly
Size 5 Ft x 5 Ft / 1.5 m x 1.5 m (Approx.)
Ver : 0.0
Approximate Size
Area
5 Ft x 5 Ft
48 5/8
Sq. Ft 235 1/8 Cu.Ft
4.5 Sq.m
1.5 m x 1.5 m
Building Dimensions
Base Dimension
Volume
inch
Width
83 3/4 212.7
Depth
83 3/4
212.7
6.6 Cu.m
Height
Exterior Dimension
Color
cm
cm
inch
113 1/4
287.9
White
287.9
113 1/4
96 7/8
246
Model #
-----------
Customer
Service Hotline
(800) 483-4674
www.duramaxbp.com
Call us for any missing or damaged parts.
Do not return to the store.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for USP DuraMax Vinyl Patio Cover
Summary of Contents for USP DuraMax Vinyl Patio Cover
- Page 1 A L L P U R P O S E V I N Y L F E N C I N G Vinyl Patio Cover OWNER’S MANUAL / Model # ----------- Instructions for Assembly Size 5 Ft x 5 Ft / 1.5 m x 1.5 m (Approx.) Ver : 0.0 Customer Service Hotline...
-
Page 2: Parts List
Parts List Standard Items Qty - 4 Nos. Qty - 2 Nos. Description 5”x 5” Support Posts 5”x 5” Interim Posts Qty - 5 Nos. Qty - 3 Nos. 2”x 6” Rafters 2”x 3.5” Batten Holders 1 3/4”x 1 3/4” Battens 2”x 3.5”... - Page 3 Post Layout Layout post pattern as shown. Fasten posts per instructions. SLAB 5”x 5” Posts x” Rebar Detail Determine the post to post dimensions for your style patio cover kit from the footprint drawing provided. Mount the posts as shown on page 3. Once posts are in place continue with the installation of top members.
-
Page 4: Post Mounting
Post Trim Instalation If your kit was ordered with the base trim option, slide these trim pieces onto the post as shown before continuing to the next step. Post Mounting 1/2” Rebar Mark concrete slab where rebar is to be installed. 5”... - Page 5 Patio Cover Assembly Full View Lower Rafter Slots (must be aligned) Upper Rafter Slots (must be aligned) Important: When setting posts make sure that the orientation of the posts is correct. The rafter slots must be properly aligned or the assembly can not be completed. See photo above for complete alignment details.
-
Page 6: Rafter Assembly
Rafter Assembly Interim Post Slide short interim post onto rafter. Do not fasten at this time. Slide rafter assembly into slots provided at top of posts. x 12 Post Top View Post Rafter Screws Center rafter between posts Center rafters and fasten with screw provided through the top of the post. Center interim post on rafter between posts and fasten with screw through top of post. - Page 7 Rafter Assembly Continued slide upper rafters into place through upper holes provides as shown below.
- Page 8 Picket Assembly Slide picket support rafters into place through holes provides as shown below. Align picket holes...
- Page 9 Insert pickets as shown Center and align pickets as shown below. Structure should look as shown at this point.
- Page 10 Final Trim Assembly Glue end caps and post caps into place. Note: The standard kits come with flat rafter end caps and pyramid post caps. Optional corbel rafter ends and New England caps are shown. x 10 Finish your Patio Cover unit by cleaning with soft non abrasive soap and water. If there are hard to remove spots or dirt on your unit, they may be removed with a light application of Laquer Thinner and a soft clean cloth.
- Page 11 Model - 1 1.5” x 1.5” Pickets Square...
- Page 12 Model - 2 1.5” x 1.5” Pickets Diamond...
- Page 13 Model - 3 7/8” x 3” Pickets Duramax Vinyl Fencing Limited Fifteen Year Warranty U.S. Polymer Inc. will send a replacement part free of charge, in the event of material defects and or workmanship for a period of fifteen years from the date of purchase.
- Page 14 U.S. Polymers, Inc. 1057 S. Vail Ave Montebello, CA 90640, United States of America SKU#--------- RD-0.0 07-03-2018...
