EMX Industries CellOpener-365 Instruction Manual

Instruction Manual
This GSM access control system allows up to 2000 registered users to operate any garage door /
gate using their phone with no cost for the call to the user. This simple to use access control
system uses a GSM SIM card that must be activated upon installation. Simply dial the associated
phone number for the SIM Card from any phone or mobile-phone and the gate will open
without any cost of a call to you. The CellOpener-365 also allows for an input contact to be used
to trigger a SMS text message to a property manager letting them know that someone is at the
gate or door.
In addition, the unit offers Weekly Timer and 365 Day Timer capability to offer maximum
security and allow a property manager to prevent a gate or overhead door from opening on
certain days and times such as national holidays or special events. The current date and time is
automatically set via the GSM network so there is never a reason to ever make adjustments for
daylight savings time.
All programming of the CellOpener-365 occurs using simple SMS text commands. This feature
allows programming to be done remotely from anywhere in the world making life easy for
maintenance, security and HR staffs that need to enable or disable an individual person's access
to a site.
Specifications
Power
Standby Current–LEDs enabled
Standby Current-LEDs disabled
Max Authorized Users
Relay Contact Rating
Operating Temperature
Antenna Cable Length
Lead Cable Length
EMX Industries, Inc.
CellOpener-365_Rev1.0_0601201
CellOpener-365
GSM Access Control
With Yearly & Weekly Timer
12V – 18V AC or DC
0.2A @ 12 VDC / 0.3A @ 24 VDC
0.1A @12
1600 Normal Users and 400 Special Users
5A @ 24V
Min -40°C / Max 65°C
1 m (39.4 inches)
0.5 m (19.7 inches)
Tech support: 216-518-9889
technical@emxinc.com
VDC / 0.15A @ 24 VDC
