delight 55302 User Manual

EN - 55302 – Motion detector alarm with PIN code protection
User Manual
You can know your family and valuables are safe thanks to this wall-mounted, battery-powered
alarm. The PIR sensor detects the movement in the room and gives a sound signal depending on the
setting. Ideal for the entryway of shops, restaurants, office buildings or for home use.

4 functions:

• Entry mark (Short beep when motion is detected)
• Instant loud alarm
• Delayed alarm for entering PIN code
• PANIC button

Features:


Energy saving

Battery operated

Digital PIN protection

Motion detection

LED feedback

Technical parameters:

Siren volume:
Motion Detection Distance: max. 5 m
Power Source:
Protection:
Color:
Dimensions:

Startup:

Before use, remove the battery case screw and cover then insert 3 AA batteries. Watch for the
correct polarity. After inserting the batteries, replace the cover and screw.
Use the slide switch at the front of the unit to select one of the above modes:
CHIME – Entry mark
INSTANT – instant alarm
DELAY – Delayed alarm (20 sec)
Pressing the "PANIC" button will trigger an instant, very loud alarm.
To arm the alarm (to turn it on), enter "0000" and then press the ON / OFF button. To deactivate the
alarm, enter your code and press the ON / OFF button.
You can change the PIN to a 1 to 12-character number string, so you can enter practically any code.
To make a change, first enter the old PIN code, in this case "0000" and then press CODE * to hear a
beep sound, enter the new PIN and press CODE * again. A beep tone acknowledges and accepts the
PIN code. Then you can activate and deactivate the alarm function with the new code.
If you forget the PIN code, remove the battery from the back of the device and replace it. This will
reset to reset the "0000" security code.
100 dB
3 x AA batteries (not included)
IP20
White
138 x 106 x 36 mm
