[FLEXI]
SENSOR
LED SPOTLIGHT
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLEXI SENSOR and is the answer not in the manual?

Questions and answers

Related Manuals for Teknik FLEXI SENSOR

Summary of Contents for Teknik FLEXI SENSOR

  • Page 1 [FLEXI] SENSOR LED SPOTLIGHT USER MANUAL...
  • Page 2 SENSOR for use with the [FLEXI] LED SPOTLIGHT. Please ensure that the sensor is installed in accordance with the below instructions. TEKNIK assumes no responsibility for inappropriate use or installation of the product, including any associated damage caused. Teknik Lighting Solutions Pty Ltd...
  • Page 3 SPECIFICATIONS Input Voltage 5V DC Ambient Light <10-2000 Lux (adjustable) min: 10sec ±3sec, max: 12min±3min Time Delay Detection Range 2 - 12m (< 24 C) (adjustable) Detection Angle 0.6 ~ 1.5m/s Motion Detection Speed 1.8m-2.5m Recommended Installation Height...
  • Page 4 INSTALLATION Remove the cap of Attach the sensor the [FLEXI] to the bottom of the fitting. [FLEXI] fitting ensuring all pins are aligned. Turn the [FLEXI] ON and follow the test and function setting instructions.
  • Page 5 FUNCTIONS Use this setting to adjust the sensor according to ambient light. When the lux dial Is set to the moon position the [FLEXI] will only operate when the ambient light level is below 10lux. When the lux dial is set to the sun position, the [FLEXI] will operate with an ambient light up to 2000lux.
  • Page 6 TEST For testing in daylight turn lux dial to the ÔsunÕ position, sensitivity dial to max (+) and time dial to (-). Adjust the angle and orientation of the sensor as desired. Make final lux, sensitivity and time adjustments to your preferred settings.
