EverStart MAXX PPS1CWE Instruction Manual page 2

Model number PPS1CWE Model number PPS1CWE
FEATURES
5
6
7
16
PPS1CWE_ManualENSP_051821.indd 2-3 PPS1CWE_ManualENSP_051821.indd 2-3
Contact us / 1-877-571-2391 Contact us / 1-877-571-2391
1
2
3 4
8
10
9
15
2
Model number PPS1CWE
18
11
12
13
14
1. Carry Handle
2. Wireless Charging Pad
3. LED Area Light
4. LCD Screen
5. LED Light Power Button
6. Decrease Compressor Pressure Control Button (–)
7. Boost Cables
Contact us / 1-877-571-2391
17
20
19
8. Alternator Check Button 15. Air Hose and Sure Fit
9. Compressor Power Button 16. Boost Cables Connector
10. Wireless Charging Button 17. Clamp Connection Slot
11. USB Power Button 18. Air Hose and Sure Fit
Groove
12. Increase Compressor Pressure Control Button (+)
19. Nozzle Adapter
13. USB Ports (with USB Power/Fault Indicators)
20. AC Charging Adapter
14. AC Charging Port
3
Nozzle
®
Nozzle in Hose Storage
®
