Windows Based Network Video Recorders
NW-16/24

Package Content

Inspect the packaging carton. Make sure the Windows Based NVR is properly delivered. Remove all items
from the box and make sure the box contains the following items.
Windows Based NVR

Front Panel

1
USB 3.0 Ports
2
USB 2.0 Ports
3
Camera LED
4
UpLink LED
5
WAN LED
6
HDD LED
7
PoE LED
8
Reset Switch
The USB 3.0 ports support all 3.0, 2.0 and 1.0 devices. Users can connect
external USB devices, such as a USB mouse, a USB keyboard, a USB
storage device, etc.
The USB 2.0 ports allow users to connect external USB devices, such as
a USB mouse, a USB keyboard, a USB storage device, etc.
With different models of NVR, the number of Camera LED is also
different. The following is description of the lightened LEDs.
1. Orange: The power is supplied by the camera itself.
2. Green: The power is supplied by the PoE switch at the rear panel.
1. Orange: Network speed is 10/100 Mbps.
2. Green: Network speed is 1000 Mbps.
1. Blink: The HDD/CF Card is running.
2. OFF: No storage device is found.
The PoE LED will start to blink when the output power is reaching to the
limit.
Insert a pin to force restart the system.
Setup Guide
SATA Cable
Power Cord
