Summary of Contents for Capstone CS-6000
- Page 1 頂 石 雲 端 CAPSTONE FIRE ALARM R e s i d e n t i a l F i r e A l a r m S o u n d e r I n s t a l l a t i o n I n s t r u c t i o n...
-
Page 2: Table Of Contents
Contents 1. Product Information 2. Function Definition 3. Description of Installation Space Configuration Planning 4. How to avoid the improper installation position? 5. Looking for the best installation position 6. Test and Maintenance of the Residential Fire Alarm Sounder 7. Setup environment 8. -
Page 3: Product Information
1. Product Information Name Residential Fire Alarm Sounder with Photoelectric/Constant Temperature Model CS-6000 Type Photoelectric Two Types/Constant Temperature Voltage 110VAC/220VAC Input Power Current 45mA Frequency 50 / 60Hz Brand Panasonic eneloop Standby Model BK-3MCCE Battery 1.2 VDC 2000mAh/AA Nickel-Hydrogen Specification... -
Page 4: Function Definition
2. Function Definition 1. The residential alarm sounder is mainly powered by supply mains, and will not start until it is connected with supply mains after installing batteries. 2. Upload a group of document to the cloud about every 60 seconds. 3. -
Page 5: Description Of Installation Space Configuration Planning
3. Description of Installation Space Configuration Planning It is recommended to install one residential fire alarm sounder on every floor and every separate compartment in the house to achieve the highest protection function. The stairwell is a passage for smoke circulation, so it is recommended to install one residential fire alarm sounder. -
Page 6: How To Avoid The Improper Installation Position
4. How to avoid the improper installation position Improper installation position will delay the alarm time, and may also cause "false alarm", thus affecting the living quality. The following conditions should be avoided: 1. Please do not install in frequently smoky environments, such as poorly ventilated kitchens, fireplaces, incense burning halls, carpentry studios, and install constant-temperature alarm sounders as fire detection in the above areas. -
Page 7: Test And Maintenance Of The Residential Fire Alarm Sounder
6. Test and Maintenance of the Residential Fire Alarm Sounder 1. Press the test button and hear the alarm sound and flashing red light to confirm the normal operation of the alarm sounder, and test it at least once per month. 2. -
Page 8: Setup Environment
7. Setup environment Setup for supply Built-in AA Nickel-Hydrogen Stable WiFi environment. 110VAC/220VAC power source Charging Battery, position. please don't remove. 8. Quick installation method 1. Firstly, remove the base and fix it on the ceiling or wall. Gently press the bottom plate on the position to be installed, mark the screw location with a pencil, drill the fixed hole with the alignment mark of electric drill after removing the bottom plate, and drill into the plastic nail in the accessories. - Page 9 2. Fasten the rechargeable battery of the accessories and press it into the battery slot at the back of the detector body, fix it in the battery slot, and then fix the battery cover plate with screws. 3. The supply mains wires can be installed on the ceiling or wall according to the requirements, and the wires can be pulled out from the center hole or the side hole of the bottom plate.
-
Page 10: Installation Situation Description
9. Installation Situation Description 1. Undecorated/Light Steel Joist Ceiling (Cement, Iron plate, etc.) 1-1. Use the electric drill to make 2 holes at the installation position, insert plastic nylon anchor (plastic plug), fix the base with screws, and connect the 110VAC (or 220AC) power source to the base. After the residential fire alarm sounder is loaded with battery, lock it to the base, and then set the APP. -
Page 11: App Tutorial
10. APP Tutorial 10-1. Download Tutorial For mobile phone with Android OS, please search for "HF Alarm" in Google player or scan QRcode to download and install. For mobile phone with Ios, please search for "HF Alarm" in Apple Store or scan QRcode to download and install. -
Page 12: Account Registration
10-2. Account Registration 3.Go to mail box to 1.After installing APP, 2.Enter email and receive mail, confirm please click “Log-up” password to start log 4.Verification is successful and enter 4 digit button verification code Log-up Enter Enter Enter Account ID Verification code has been Email sent to the following mail... -
Page 13: Device Setting
10-3. Device Setting 2.Turn on *Wi-Fi 1.When theresidential fire alarm sounder is powered on and press searching“Capstone” 3. Enter password 4.Connection is “Setting” key, Check APP and network and connect “firecloud” successful go to NextStep Set up New-added device New-added device Enter password of “capstone_6adc4a”... - Page 14 5.Enter the 7-1.The new device 7-2.The new device 6.Scan the QR-code pre-connected Wi-Fi name group can be name group can be at back of device, name and password of selected according to selected according to finish pairing device to connect the household unit the household unit New-added device...
- Page 15 Select Select Normal Setting is Living Room New-added Main Bedroom Bathroom Confirm Kitchen Congratulation Cancel Device has been Dining Room successfully set. Capstone FireCloud Co., Ltd Concern about your house safety New-added space New-added space My Group Confirm Confirm Confirm...
-
Page 16: Device Sharing Setting
10-4. Device Sharing Setting 2.Click “Share Device”, 1.Click option at right 3.Skip to the next screen, and select the device to upper corner, clic be shared. Click the left menu Device Sharing Device Sharing Device Sharing Share Device Shared List of 1F-Living Room-01 No Signal Not Share 1F-Living Room-01... - Page 17 “send”, share invitation the devices to select multiple shall be sent. devices, and then press the following Device Please enter Capstone account of part: Share My Device 1F-Living Room-01 Have Shared Recently Shared Accounts...
- Page 18 Device Sharing My Device Share Device Welcome to use Capstone FireCloud safe home You still don’t have any device 1F-Living Room-01 information Have Invited From New-added Device...
- Page 19 9.Sharing party click “Share 8.There has been receiving party of Device”, installed device, click option at Re-click shared device, the receiving right upper corner, click the left notification shall be popped up, menu confirm and complete sharing Device Sharing Device Sharing My Device Share Device No Signal...
-
Page 20: Edit Device
10-5. Edit Device 4.Click “Edit”, select 1.Click option at 2.Click the left menu 3.Click and Edit device to be edited or right upper corner Device Group deleted Edit Device/Group Edit Group Edit Device My Group Edit No.168 5F Edit Guest Normal No Signal No.168 5F... -
Page 21: Edit Group
10-6. Edit Group 4-1.Click group name, 1.Click option at 2.Click the left menu “changing name” 3.Click right upper right upper corner shall bepopped up. Edit Device/Group Edit Device Edit Device Edit My Group Dele My Group Guest Normal No Signal No.168 5F No.168 5F 4-1.Check the circle... -
Page 22: Self-Set Temperature Remind Setting
10-7. Self-set Temperature Remind Setting 4.If you want to delete and click 2. Click “Self-set 3.Set temperature, at right upper corner, Remind”, and click message remind 1.Click device to be and check the Self-set new-added self-set and new-add complete adjusted Remind to be deleted temperature Guest Room-No.168 5F... -
Page 23: Notification Setting
10-8. Notification Setting 2.Click the left menu 3.Adjust notification interval 1.Click option at according to requirement right upper corner Notification Setting Notification Setting Mail Box Setting Guest Normal No Signal Keep to send message to my mail box Current abnormality report mail box Disclaimer Notification Setting Edit Device/Group... -
Page 24: Android System Instruction
10-9. Android System Instruction 2.Go to “Sound Notification” setting, 1.To “Self-Start Management” to turn on alarm volume (or notification volume). to start permission. Self-Start Management Sound Recent Have Preload Installation Downloade Prohibiting software from self-starting, which Media Volume can improve battery life and release memory. All Applications Permit Alarm Volume... -
Page 25: Fcc Statement
11. FCC Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
