Summary of Contents for Cordex LM3000
- Page 1 USER MANUAL LM3000 EXPLOSION PROOF LASER DISTANCE METER RUGGED AUTHORITY www.cord-ex.com...
-
Page 2: Table Of Contents
Congratulations CONTENTS – You are the owner of the next generation explosion proof laser distance Getting To Know Your 3000XP meter designed and certified Overview specifically for use in hazardous Preparation Settings (explosive) atmospheres. Basic Operation 10-11 Advanced Functions 12-15 Troubleshooting Specification 3000XP is certified CSA as follows:... -
Page 3: Getting To Know Your 3000Xp
LaserMETER 3000XP - Explosion-proof Laser Distance Meter GETTING TO KNOW YOUR 3000XP Keypad Display OFF/ REF/ LIGHT CLEAR ftim A / V / P UNITS ftim ON / DIST On / measure distance Change reference (front/back) Advanced mode: Area (one Reference indicator Battery charge indicator Addition/subtraction mode... -
Page 4: Overview
LaserMETER 3000XP - Explosion-proof Laser Distance Meter OVERVIEW Congratulations on your purchase of the The LaserMETER 3000XP is capable of LaserMETER 3000XP. measuring distances of 30m (100ft) with an accuracy of 3mm (0.1in) - accuracy may The LaserMETER 3000XP is an explosion- vary depending on reflectivity and ambient proof laser distance meter, CSA-certified conditions. -
Page 5: Preparation
LaserMETER 3000XP - Explosion-proof Laser Distance Meter PREPARATION SETTINGS Battery Pack and Charging Connecting the Reference Mode Place the CorDEX Approved Battery Pack Load the battery pack paying careful attention When you make a measurement using the BACK in the supplied Charging Station. Plug to its orientation. -
Page 6: Basic Operation
LaserMETER 3000XP - Explosion-proof Laser Distance Meter BASIC OPERATION Single Measurements Continuous Measurement Hold down the ON/DIST button for about Press the ON/DIST button to switch on the 2 seconds to start continuous measuring. meter. The laser is activated. Place the meter The meter beeps with each updated ftim against a stable surface and aim the laser at... -
Page 7: Advanced Functions
LaserMETER 3000XP - Explosion-proof Laser Distance Meter ADVANCED FUNCTIONS Area Volume Position yourself at one corner of the area to Position yourself at one corner of the volume be measured (X - see diagram). to be measured (X - see diagram). Press the ON/DIST button to switch on the LaserMETER. - Page 8 LaserMETER 3000XP - Explosion-proof Laser Distance Meter ADVANCED FUNCTIONS (CONT) PYTHAGOREAN (hypotenuse mode) PYTHAGOREAN (baseline mode) The Pythagorean mode allows you to measure The second Pythagorean mode calculates a distances accurately when it is not possible baseline length from the measurements of the to gain access to an area, or when there is an hypotenuse and the adjacent side.
-
Page 9: Troubleshooting
LaserMETER 3000XP - Explosion-proof Laser Distance Meter TROUBLESHOOTING SPECIFICATION Error Message Cause Correction Certification information Data overflow Repeat the measurement steps. Certificate No 2379424 Measurement The meter has a maximum range of 30m (100ft). If you need to Certificate Type: Class I Div.1 Groups B, C, D range exceeded measure a greater distance, try to break it down into smaller steps. - Page 10 Copyright © 2014, CorDEX Instruments Limited. All other brand and product names are trademarks of CorDEX Instruments Limited. Ref. ID 2102, Rev. B...
