Summary of Contents for AWC AWR-RP9000N
- Page 1 User Manual AWR-RP9000N Repeater...
- Page 2 RP9000N fix installed radio will provide you with the reliable performance and high quality you demand. This manual should be read to ensure that the user understands the operation of the AWR-RP9000N. Please read the Safety Instructions before use. User Instructions Please carefully read this manual before attempting to deploy the repeater.
- Page 3 (90 cm) shall be maintained during transmission. • The separation distance from a properly installed externally-mounted antenna to satisfy the RF exposure requirements. If there are any problems with the Repeater, please contact AWC or your local distributor. Product Safety and RF Exposure...
- Page 4 FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 5 General Items This warranty policy establishes the liability limits for which AWC is responsible. AWC has the right to decide, in their sole discretion, whether to repair, replace, or refund the purchase price of any equipment subject to this warranty. There are no other options available under this warranty.
-
Page 6: Table Of Contents
CONTENTS Unpacking and device check ..............1 Packing list ....................1 Product images ................... 1 Front panel ....................1 Front panel functions................1 Back panel ....................2 AUX interface pin ..................2 Installation ....................3 Status indication ..................4 LED indicator ................... 4 Product operation .................. -
Page 7: Unpacking And Device Check
If any item has been lost or damaged, please submit a claim with the carrier or deliverer. Items Quantity AWR-RP9000N Repeater Adapter ANTENNA KIT Repeater Programming Software Available at www.advancedwireless.com User Manual Available at www.advancedwireless.com... -
Page 8: Back Panel
Back Panel Antenna AUX interface pin No. Part Name No. Part Name DC-OUT AF-OUT VBAT-BAT SPK1 SPK2 Installation Before installing the Repeater , please read the following precautions carefully. Precautions It shall be firmly attached in the mounting location with supplied hardware to ensure Repeater cannot break lose and cause damage or physical injury. -
Page 9: Installation
Installation • Power drill w/ appropriate drill size. • Phillips screwdriver. Preparation Steps the Repeater to the desired position. Connecting antenna. Connect the power supply. -
Page 10: Status Indication
LED Indicator The front panel LED indicator allows the user to determine the radio state. Indicator Status Radio Status Power Red LED glows Normal power supply Tx Red LED glows Transmitting USB uploading data Rx Green LED glows Receiving signal USB download data Product Operation Power on... - Page 11 3、Start Repeater Programming Software. 4、Open the menu Setting/communication Port，ConfigurationPort. 5、Programming /Read data from radio/Start，Read data completed. 6、Set the data. 7、Programming /Read data from radio/Start，Save data to Repeater.
- Page 12 (952) 469-5400 / Toll Free: (800) 475-5852 20809 Kensington Blvd Lakeville, MN 55044-8353 www.AdvancedWireless.com...
