Innovative THEPROTECTOR Air Purifier-500 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
THEPROTECTOR Air Purifier-500
READ AND SAVE THESE INSTRUCTIONS
WARNING!
Please note that the air purifier should only be used with parts approved by
supplier. The use of unauthorized parts or alterations to the machine could void your warranty.
Contact an approved distributor for further assistance.
To Avoid the Risk of Fire or Electric Shock:
Unit must be electrically grounded.
•
Insert 3-prong plug directly into outlet with Ground Fault Circuit Interrupting device.
•
Do not use an adapter with this unit.
•
Do not use the unit in standing water.
•
If electrical parts get wet, they must be dried prior to use.
•
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the THEPROTECTOR Air Purifier-500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Innovative THEPROTECTOR Air Purifier-500

  • Page 1 THEPROTECTOR Air Purifier-500 Owner's Manual READ AND SAVE THESE INSTRUCTIONS WARNING! Please note that the air purifier should only be used with parts approved by supplier. The use of unauthorized parts or alterations to the machine could void your warranty.

  • Page 2: Special Features

    Precautions before use 1.Please make sure all filters paking bags removed before the machine plug in power supplier,otherwise it will cause risks or damage to the machine,like no filting,machine does not work,etc. 2. The power supplier must be cutted off before replace any filters,all filters must use autherised or approved components,otherwise it will effect the filter efficience or cause damage to the machine.

  • Page 3: Key Features

    units). When storing, the machines can be stacked horizontally to save space. KEY FEATURES...

  • Page 4: Control Function

    INSTRUCTIONS SETUP Place the air purifier so that it is in the upright, vertical position. Plug the machine into a standard 120 volt outlet. Note: Each unit needs 3.6amps to operate. Power the unit on and adjust the speed by turning the variable speed control. The maximum speed is 500 CFM.

  • Page 5: Changing The Filters

    CHANGING THE FILTERS Loosen the 2 locks that hold the filter board in place. Slide out the filter panel board. Remove the used filters and replace with new filters. WARNING Always wear approved protective gear when changing the filters. • Filters should be changed after each remediation job.

  • Page 6: Safety Notes

    WARNING! WARNING: To reduce the risk of electric shock, do not expose to water or rain. WARNING: NOT SUITABLE FOR USE WITH SOLID-STATE SPEED CONTROLS CAUTION:To reduce the risk of electric shock,connect only to an outlet provided with a ground fault circuit interrupting device.

  • Page 7: Wiring Diagram

    Improper voltage Lack of normal care Failure to follow instructions Corrosion Freezing Any additional costs due to changes in laws or building codes Freight charges Any costs due to lost profit or delay Damage to property Cause beyond control Consumable parts, including but not limited to: Filters Batteries Power cords...
