Summary of Contents for AWS M Series
- Page 1 AWS MSeries AWS Wind Turbine Controller with MPPT User Manual Model WW15-24-48 V1.3...
-
Page 2: Table Of Contents
Contents 1. Important Safety Warning ......................１ 2. Basic Information........................２ 2.1 Introduction and Features ....................... ２ 2.2 Product Structure ........................３ 3. Product Installation ........................５ 3.1 Installation Notes ........................５ 3.2 Installation and Wiring ......................６ 3.2.1 Installation Steps ........................６ 3.2.2 Installation Steps ........................ -
Page 3: Important Safety Warning
1. Important Safety Warning Before Using the controller, please read all instructions and cautionary markings on the unit and this manual. Store the manual where it can easily be accessed. This manual includes all safety warnings, installation, and operation guidance of MWM wind controllers. -
Page 4: Basic Information
The power curve can be set by setting the wind turbine voltage and current, which allows the wind turbine to operate within its best power output all the times. (All AWS wind controller solar with AWS Wind turbines are preset, do not alter these setings) Features: ➢... -
Page 5: Product Structure
2.2 Product Structure Chart1. Product Overview (1-3kW) V1.3 ３... - Page 6 Chart2. Product Overview (5-10kW) ① ⑤ Battery terminal Manual brake switch ② ⑥ Dump load terminal Browse button ③ Wind turbine terminal LCD display ⑦ ④ Communication device port Unload indicator light ⑧ V1.3 ４...
-
Page 7: Product Installation
Chart3: Dump Load with different power 3. Product Installation 3.1 Installation Notes 1) The controller must be kept indoors and well ventilated; 2) Environment temperature: -20～+40℃; Humidity: <=95%，no condensing 3) Altitude should not be more than 4000m (＞1000 m derating according to the GB/T3859.2 regulations). -
Page 8: Installation And Wiring
3.2 Installation and Wiring 3.2.1 Installation Steps Chart 4: Installation Overview V1.3 ６... - Page 9 3.2.2 Installation Steps Chart5: Installation Steps V1.3 ７...
-
Page 10: Electrical Connection
3.2.3 Electrical Connection (1-3kW) V1.3 ８... - Page 11 (5-10kW) Chart 6: System Overview 1. Connect Dump load to the controller terminal “DUMPLOAD” by using copper conductor cable. 2. Connect the battery bank to the controller by the terminal which marks “BATTERY”. (do not reversed the connection of positive and negative terminals) 3.
-
Page 12: Operation Interface Introduction
4. Operation Interface Introduction 4.1 LCD Display After the power is connected, the screen is in a browsing status. It shows battery voltage, and can be changed to the following information by press related buttons. V1.3 １０... -
Page 13: Lcd Information Define
4.2 LCD Information Define Name Icon Status Rotate means wind turbine is working normally Wind Turbine Brake mode has been activated from the controller Charging Fully charged. flickering for over voltage, stop Battery flickering when it recover from over voltage Flickering means over -discharge Press it to enter next LCD display. -
Page 14: Technical Parameters
Battery is connected in wrong polarity to Need change the internal fuse in battery input terminals. controller, and reconnect the battery. The connection cable between wind turbine Reconnect and fix the cables. and controller is loose. Wind turbine output voltage hasn’t reached Check whether the system voltage is the charging voltage, reasonable. - Page 15 Charge Parameters (optional) Rated battery voltage 48Vdc 240Vdc Temperature -3mV/ ℃ /2V compensation function (optional) Output Parameters Rated output voltage 48Vdc 240Vdc 56Vdc (factory default, 280Vdc (factory default, Start unload voltage 44Vdc~64Vdc settable) 220Vdc~320Vdc settable) Complete unload 60Vdc (factory default, add 4V to 300Vdc (factory default, add 20V to voltage the start unload voltage)
- Page 16 Product dimension 300×375×145mm (W*H*D) Product net weight 10kg Dump load dimension 360*80*120mm (W*H*D) Dump load net weight 2.8kg Note: Part of parameters can be adjusted according to customer’s specific demand. Model WW20-48-48 WW20-48-240 Type Boost Buck Wind Turbine Input Rated input power Rated input voltage 56Vdc 280Vdc...
- Page 17 Brake by over wind 18m/s (0-30m/s settable),Unload completely when reached the set wind speed (optional) speed, and recover automatically after working 10mins. Brake by over 500r/min (factory default,0~1000r/min settable)Unload completely when rotational Speed reached the set rotational speed, and recover automatically after working (optional) 10mins.
- Page 18 Product dimension 300×375×145mm (W*H*D) Product net weight 10kg Dump load dimension 300*400*210 mm (W*H*D) Dump load net weight Note: Part of parameters can be adjusted according to customer’s specific demand. Model WW30-48-240 WW30-120-120 WW30-240-240 Type Buck Boost Wind Turbine Input Rated input power Rated input voltage 280Vdc...
- Page 19 320Vdc (Factory default), PWM unload step by step once reached Refer to “output overvoltage” Brake by overvoltage the set unload voltage, and it will unload completely if the voltage rise 20Vdc more. Brake by over wind 18m/s (0-30m/s settable),Unload completely when reached the set wind speed (optional) speed, and recover automatically after working 10mins.
- Page 20 Lightning protection ≥92% Conversion efficiency ＜5W Static loss -20℃～+40℃ Ambient temperature Humidity 0~90%, No condensing ≤65dB Noise Forced air cooling Cooling mode Installation mode Wall-mounted Cover protection class IP42 Product dimension 360×440×191mm 300×375×145mm (W*H*D) Product net weight 13kg 10kg Dump load dimension 400×390×210mm (W*H*D) Dump load net weight...
- Page 21 50A (factory default,0~50A settable)Unload 25A (factory default,0~25A settable)Unload completely completely when Brake by over current when reached the set current, and recover automatically reached the set after working 10mins. current, and recover automatically after working 10mins. 320Vdc (factory default,220Vdc~320Vdc settable)PWM unload step by step Brake by overvoltage Refer to “output overvoltage”...
-
Page 22: Warranty
19kg 45kg Note: Part of parameters can be adjusted according to customer’s specific demand. 7. Warranty The AWS Wind controller is warranted for 5 years against fault or defect when operated and installed as detailed in this manual. V1.3 ２０...
