ASSEMBLY INSTRUCTIONS AND INSTALLATION GUIDE
System Line
→ HighPROTEC
CSP2-F → MCA4
RETROFIT KIT FOR THE REPLACEMENT OF SYSTEM LINE DEVICES BY HIGHPROTEC DEVICES
PROTECTION TECHNOLOGY
MADE SIMPLE
RETROFIT KIT FOR THE REPLACEMENT OF SYSTEM LINE DEVICES
BY HIGHPROTEC DEVICES
Original document
English
Revision: A
Advertisement
Summary of Contents for Seg CSP2-F
- Page 1 ASSEMBLY INSTRUCTIONS AND INSTALLATION GUIDE System Line PROTECTION TECHNOLOGY MADE SIMPLE → HighPROTEC CSP2-F → MCA4 RETROFIT KIT FOR THE REPLACEMENT OF SYSTEM LINE DEVICES BY HIGHPROTEC DEVICES RETROFIT KIT FOR THE REPLACEMENT OF SYSTEM LINE DEVICES BY HIGHPROTEC DEVICES Original document...
- Page 2 If the devices are operated by inadequately qualified personnel, there is a justified risk that health and/or devices will be dramatically damaged! All activities marked in this way must be carried out by appropriately qualified personnel. Retrofit Kit for the Replacement of System Line CSP2-F by HighPROTEC MCA4...
- Page 3 This document may have been revised or updated since this copy was made. To ensure that you have the latest revision, please refer to the download area of SEG Electronics GmbH: https://docs.SEGelectronics.de/csp Retrofit Kit for the Replacement of System Line CSP2-F by HighPROTEC MCA4...
-
Page 4: General Information
As the CSP System Line series of protection and control devices has been phased out, it is now necessary to replace them with new protection and control devices if necessary. SEG Electronics GmbH provides a retrofit-kit with which the devices of the System-Line can be →... - Page 5 SEG Electronics GmbH DOK-HB-CSPFHPTE Hardware – Structure of Terminal Strips CSP2-F Retrofit Kit for the Replacement of System Line CSP2-F by HighPROTEC MCA4...
- Page 6 Hardware – Structure of Terminal Strips MCA4 The figure shows a possible example variant, the available variants are shown in the order code ("Typecode MCA4", see page 15). Retrofit Kit for the Replacement of System Line CSP2-F by HighPROTEC MCA4...
- Page 7 X9 / X10 / X11 X103 Optical fiber interface X102 Ethernet-(RJ45-)interface X100 Grounding / PE Power outputs (control circuits) XA1 / X1 N/A (see the note in section “General Information”, page 4) Retrofit Kit for the Replacement of System Line CSP2-F by HighPROTEC MCA4...
- Page 8 DOK-HB-CSPFHPTE Overview Device Software CSP2-F >>> MCA4 The CSP2-F works with the System Line software, the MCA4 works with the Smart view software. → Although these are two different user programs, care has been taken to ensure that the structure tree is basically structured in the same way.
- Page 9 DOK-HB-CSPFHPTE What Has to be Taken into Account During the Remodeling on Site: 1. Disassembly of the CSP2-F Label the plugs of the CSP2-F and the plugs (base unit >mounting plate). This helps to assign the → connectors later. →...
- Page 10 2. Disassembly of the Control Unit CMP1 → Remove the CAN bus cable from the control unit. Remove the power supply/grounding cable. → Remove the control unit from the control cabinet door. → Retrofit Kit for the Replacement of System Line CSP2-F by HighPROTEC MCA4...
- Page 11 Fasten the adapter plate in the control cabinet door using the washers and screws supplied. No drilling or sawing required! (See the dimension drawing on the next page.) Retrofit Kit for the Replacement of System Line CSP2-F by HighPROTEC MCA4...
- Page 12 SEG Electronics GmbH DOK-HB-CSPFHPTE Adapter Plate HPT Catalog- / article identifier of the adapter plate: CSPHPTADAP Retrofit Kit for the Replacement of System Line CSP2-F by HighPROTEC MCA4...
- Page 13 Connect the wires to the corresponding terminal strips (according to the circuit diagram). • To avoid possible wiring errors, check the correct cable occupation with a continuity tester. Retrofit Kit for the Replacement of System Line CSP2-F by HighPROTEC MCA4...
- Page 14 Please contact the service team if required. SEG Electronics GmbH All functions of the CSP2-F can be easily covered by the HighPROTEC MCA4. → Where it is not possible to take over certain functions by simply setting the parameters, corresponding logic modules can be used and parameterised in the HighPROTEC series.
- Page 15 RS 485, Ethernet: IEC 61850 | Modbus TCP/RTU | IEC 60870-5-103 | IEC 60870- 5-104 | DNP3 UDP/TCP/RTU Printed Circuit Board Standard Printed circuit boards are conformal coated Retrofit Kit for the Replacement of System Line CSP2-F by HighPROTEC MCA4...
- Page 16 SEG Electronics GmbH DOK-HB-CSPFHPTE Back View MCA4 (for an example typecode) MCA4-2D0ACA (example device variant) Retrofit Kit for the Replacement of System Line CSP2-F by HighPROTEC MCA4...
- Page 17 SEG Electronics GmbH DOK-HB-CSPFHPTE Back View CSP2-F Retrofit Kit for the Replacement of System Line CSP2-F by HighPROTEC MCA4...
- Page 18 SEG Electronics GmbH DOK-HB-CSPFHPTE Photos from Practice System in original condition - exterior view View of the cable bushing (before) Retrofit Kit for the Replacement of System Line CSP2-F by HighPROTEC MCA4...
- Page 19 SEG Electronics GmbH DOK-HB-CSPFHPTE System Line CMP1 operating unit dismounted Retrofit Kit for the Replacement of System Line CSP2-F by HighPROTEC MCA4...
- Page 20 SEG Electronics GmbH DOK-HB-CSPFHPTE Main unit CSP2-F System Line dismounted Retrofit Kit for the Replacement of System Line CSP2-F by HighPROTEC MCA4...
- Page 21 SEG Electronics GmbH DOK-HB-CSPFHPTE Equipment after remounting HighPROTEC-MCA4 (interior view) Retrofit Kit for the Replacement of System Line CSP2-F by HighPROTEC MCA4...
- Page 22 System Line → HighPROTEC https://docs.SEGelectronics.de/csp SEG Electronics GmbH reserves the right to update any portion of this publication at any time. Information provided by SEG Electronics GmbH is believed to be correct and reliable. However, SEG Electronics GmbH assumes no responsibility unless otherwise expressly undertaken.
