  • Page 1 INTEGRAL-VC1 User manual www.dasaudio.com...
  • Page 2 INTEGRAL Overview DAS Audio is a unique brand. We create sound solutions for businesses, always adapted to the different needs of our clients. The Integral Series is the heart and brain of our installation solutions. It comprises of a series of devices that in addition...
  • Page 3: Description And Features

    INTEGRAL Description and features INTEGRAL-VC1 is a 100V volume control capable of han- dling power up to 120W. The volume is adjustable with a rotatable selector in 5 steps of -6dB each. It is equipped with a relay and separated input for the reception of 24V priority signals.
  • Page 4: Front Panel

    INTEGRAL Front panel Rotatory selector. 5 positions: -18dB -12dB -6dB INTEGRAL-VC1 Manual...
  • Page 5: Rear Panel

    INTEGRAL Rear panel Main Connector. Pin Assignment: Input terminals (+,-) to connect cabling from amplifier´s output Output terminals (+,-) to connect the line of speakers 24V terminals to activate the emer- gency relay 120W 120W transformer INTEGRAL-VC1 Manual...
  • Page 6 INTEGRAL Connections Shown in the following image an INTEGRAL-VC1 controller connected to an INTEGRAL-Axxx amplifier delivering on bridge mode 100Volts. In this case the VC1 has been connected to 4 x Arco-24T systems, each one configured at 30W. INTEGRAL-Axxx or MAxxx models...
  • Page 7 A more complex system is shown in the following im- age. There is a paging microphone connected to an IN- TEGRAL-MAxxxx model with priority selection. A back- ground music program is provided by the INTEGRAL-AS2 audio source. DAS AUDIO - INTEGRAL AS2 VOL+ NEXT SKIP+ PLAY/PAUSE STOPE...
  • Page 8: Installation

    • Run the cables out of the wall thru the electrical box. • Connect the cables to the screw connector located at the back plate of the VC1 following the pin out previously described. • Fix the unit it to the electrical box with the provided M4x25 screws. INTEGRAL-VC1 Manual...
  • Page 9: Specifications

    INTEGRAL Specifications 120W Power Handling 20Hz – 20kHz Frequency Response Attenuation -18dB -12dB -6dB 86 x 86 x 52mm Dimensions (H x W x D) (3.38 x 3.38 x 2 in) 530g (1,16845 lb) Weight INTEGRAL-VC1 Manual...
