TV4K-NICAM / A2 STEREO
COLOUR TELEVISION RECEIVER
SECIFICATIONS
SYSTEM
POWER INPUT
POWER CONSUMPTION
AERIAL IMPEDANCE
TUNER
RECEICING CHANNELS
PROGRAMME
PICTURE TUBE
SOUND OUTPUT
SPEAKER
AV JACKS
CAUTION
: Before servicing the chassis, read the "Safely Precaution".
"X -Ray radiation Precaution" and "Product Safety Notice" on Page 2 of
this manual.
X-RAY RADIATION PRECAUTION
1. Excessive high voltage can produce potentially hazardous X-RAY RADIATION. To
Avoid such hazards the high voltage must not be specified limit. The normal value of
the high voltage of this receiver is App. 28.5KV at zero beam current (minimum
brightness) under 230V AC power source. The high voltage must not under any
circumstances exceed 30KV.
2. Each time a receiver requires servicing the high voltage should be checked following
the HIGH VOLTAGE CHECK procedure in this manual. It is recommended the
reading of the high voltage be recorded as a part of the service record. It is
important to use an accurate and reliable high voltage meter.
SERVICE MANUAL
PAL/SECAM,B/G,D/K, I
GERMAN STEREO,NICAM
AC 170-260v(50/60Hz)
100W
75OHM UNVALANCED
VOLTAGE SYNTHESIZER TUNING
VHF-L E2-S10
VHF-H E5-S41
UHF E21-E69
MAX.99 PROGRAM MEMORIES
28",110°
5W
X2
8W 8 OHM ×2
AV SCART ×1
FULL SCART ×1
Advertisement
Table of Contents
Related Manuals for Tauras TV4K-NICAM
Summary of Contents for Tauras TV4K-NICAM
- Page 1 TV4K-NICAM / A2 STEREO COLOUR TELEVISION RECEIVER SERVICE MANUAL SECIFICATIONS SYSTEM PAL/SECAM,B/G,D/K, I GERMAN STEREO,NICAM POWER INPUT AC 170-260v(50/60Hz) POWER CONSUMPTION 100W AERIAL IMPEDANCE 75OHM UNVALANCED TUNER VOLTAGE SYNTHESIZER TUNING RECEICING CHANNELS VHF-L E2-S10 VHF-H E5-S41 UHF E21-E69 PROGRAMME MAX.99 PROGRAM MEMORIES PICTURE TUBE 28”,110°...
- Page 2 3. The primary source of X -RAY RADIATION in this TV receiver is the picture tube. For continued X-RAY RADIATION protection, the replacement tube must be exactly the same type tube as used in this TV receiver. 4. Some parts in this receiver have special safety-related characteristics for X-RAY RADIATION protection.
- Page 3 Make sure the AC power supply is 230V, 50Hz. Switch on the TV receiver, tune in an active channel. Measure the voltage between C641 on Main P.C. Board DC voltmeter. Set contrast, brightness, color to maximum. Adjust VR631 on Main P. C. Board for B+140V+/-0.5V voltage reading. HIGH VOLTAGE CHECK AUTION: There is no high voltage adjustment in this chassis, B+140V voltage directly relates to the high voltage.
- Page 4 Table 2 Service V3.0 Parameter Fix value Tuner AGC Fix value H position adjusted VPOS 50 not adjusted not adjusted VPOS 60 not adjusted VAMP 50 not adjusted VAMP 60 Bright max Fix value Bright min Fix value Sub Tint Fix value VCO Coarse Fix value...
- Page 5 H POS OSD V POS OSD H POS TXT V POS TXT OPTION1: B5=P/N/S Crystals application (0=2 crystals, 1=1 crystal) B4=Cutoff Loop (0= OFF, 1=ON) B3=Safety_Reset (0=Active, 1=non) B2=Super Tuner (0=OFF, 1=ON) B1=Sound Demodulation (0= Intercarrier/MONO, 1=QSS/NICAM) B0=Logo Display (0=OFF, 1=ON) OPTION2: (It’s better to keep the default setting option2=0) B5=Half_Contrast (0=OFF, 1=ON) B4=Color 6db (0=OFF, 1=ON)
- Page 6 can be switched by press key MENU on remote control in TEXT mode for TV4K. If you set OPTION 5 = 00, 02, 04, 06, then there is no any activity while press MENU in TEXT mode. Please check. A.F.C. ADJUSTMENT Removing any R.F.
- Page 7 CTV2811N-JL TXT/NICAM SCHEMATIC DIAGRAM NOTE: SUBJECT TO CHANGE WITHOUT NOTICE CRITICAL PARTS SCART1 SCART2 R810A +26V 1R/2W VIN2 D3401 R507 RQ07 R421 R422 R423 R424 R501 IC501 LIN1 LQ03 4148 RQ08 2.7K 5.6K R429 5.6K 2.7K C3417 10UH C432 C433 1000UF/35V C3418 RIN1...
