Page 2
SCHNEIDER ELECTRONICS GMBH-GERMANY 1. CAUTION CA UTION: Use of controls, adjustments or procedures other than those specified herein may result in hazardous radiation exposure. CA UT ION : T O RE DUCE TH E RIS K OF CA U T ION ELECTR ICA L SHOCK, DO NOT RE MOVE COVER (OR BACK).
Page 3
SCHNEIDER ELECTRONICS GMBH-GERMANY IMPORTANT SAFETY INSTRUCTIONS CAUTION: Read all of these instructions. Sa ve these instructions for later use . Follo w all W arnings and Instructions marked on the audio equipment. 1. Read Instructions-All the safety and operating instructionsshouldbe read before the productis operated. 2.
Page 4
SCHNEIDER ELECTRONICS GMBH-GERMANY PROTECTION AND LOCATION OF YOUR SET Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, etc. Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall outlet and refer servicing to qualified service personnel.
Page 5
SCHNEIDER ELECTRONICS GMBH-GERMANY OPERATION OF YOUR SET 18. This television set should be operated only from the type of power source indicated on the marking label.If you are not sure of the type of power supply at your home, consult your television dealer or local power company. For television sets designed to operate from battery power, refer to the operating instructions.
Page 6
EM BUSINESS CENTER FTV PRODUCT MANAGEMENT DEPT. SPECIFICATION RELEASE Version: V1.0 Issued Date: 2011.05.08 Model: C32E320/MT10L-LA/SS8P PICTURE Category LCDTV Naturalight Technology Yes (Natural Light Engine‖) Dynamic Contrast Color Temperature Warm / Normal / Cold SIGNAL FORMAT CAPABILITY Backlight Adjustable Component Video Format Y,Pb/Cb,Pr/Cr:up to 1080P Scale Mode Full, Wide Screen,Subtitle,4:3...
Page 7
Factory Alignment Specification of normal SIACP TCL WW R&D FPD CENTER Factory Alignment Specification of normal SIACP For MT10-LA Version 1.0 PREPARED BY : DATE : 2011-4-22 APPROVED BY : DATE : Page 1 of 12...
Factory Alignment Specification of normal SIACP Table of Contents Feature Specification ............................4 INFO..................................5 1.Electrical Assembly Alignment ........................5 1.1 Preconditions – DC/DC Check........................5 1.2 SW download ..............................5 1.3 Panel ID check and modify ........................... 6 1.4 Functional Test .............................. 6 1.5 DDC &...
Page 9
Factory Alignment Specification of normal SIACP The information contained in this document is proprietary to TCL SZ FPD lab and shall not be disclosed by the recipient to third persons without the written permission of the team leader or GM of R&D.
Factory Alignment Specification of normal SIACP Feature Specification These chassises are designed for South America LCD TV. The main chip is from Mediatec (MT5310 series) and supports below inputs and outputs: class item Status MT10B-LA MT10L-LA Cable&Antenna Cable&Antenna ( PAL- M/N, NTSC-M) Antenna Antenna (SBTVD-T)
Factory Alignment Specification of normal SIACP INFO All tests and measurements mentioned hereafter have to be carried out at a normal mains voltage (220 ~ 240 VAC) All voltages have to be measured with respect to ground, unless otherwise stated All final tests have to be done on a complete set including LCD panel in a room with temperature of 25+/-7°C The White Balance (color temperature) has to be performed into subdued lighted room after at...
Factory Alignment Specification of normal SIACP upgrade FLASH SW from USB”. Remenber to do “Reset all” after upgrade the SW. 1.3 Project ID check and modify There is different ID stored in the NVM depended on different Panels. Modify it with Hyper terminal if the initial ID or a wrong ID make the set can not display clearly.
Factory Alignment Specification of normal SIACP 1.6 HDCP Test For HDCP compliancy, it’s needed to check whether the HDCP key has been well set. 2.Final Assembly Alignment 2.1 FactoryMenu Follow the below steps to pop-up the Factory Menu in case of “FactoryKey” is disable : - press RemoteControl key “MENU”...
Factory Alignment Specification of normal SIACP Each panel has it’s own colour coordinates, Please refer to the following table. L32V6200/L32E5200 L42E5200F/L42V6200F C32E320/L32P60 C42E320F/L42P60F Normal 0.275 0.310 0.275 0.290 0.280 0.290 0.280 0.290 Cool 0.265 0.285 0.265 0.290 0.270 0.280 0.270 0.280 Warm 0.305...
Page 15
Factory Alignment Specification of normal SIACP Item Sub-item Value/Sub-item Note Burning Off/On Select panel On with left/right Mode key, Press “EXIT” key to enter the burning mode; Press “Menu” key on keyboard to exit the burning mode ADC Need not to do ADC when alignment White Balance Item Sub-item...
Page 16
Factory Alignment Specification of normal SIACP Reset ALL Item Sub-item Value Note Reset Clear NVM values and set to default value Power Mode Item Sub-item Value Note Power Boot/Standby/ Boot: Enter power on mode Mode Last Status Standby: Enter standby mode Last Status: power on according to last status USB Clone Mode...
Factory Alignment Specification of normal SIACP Appendix “How to download FLASH SW” Prepare MTK SW tool for update. 1. Connect the PC to the serial connector on board using a special serial device (USB or COMx). 2. Provide the a correct voltage to the board 3.
Factory Alignment Specification of normal SIACP try again. Upgrade without loader(The TV set should be able to display normally): 1. Save the new software file(*.pkg) in the root directory of USB, and modify it’s name as a software number, such as “V8-0MT1006-LF1V017.pkg”. 2.
Page 19
Power supply USB1 USB2 Audio Amp. Panel Head phone DDR3 T90517 DDR3 LVDS MT5310 DEMO IP/GPIO FLASH Flash HDMI RECEIVER 64Mbit CVBS DECODER 3D COMB FILTER MPEG4 DECODER Serial TS in SCALER Audio TMDS YPbPr 4052 HDMI1 IF+/- HDMI 1.3 HDMI2 SWITCH 3 IN 1...
Page 29
1 Have no anything, No backlight/No Video/No Audio etc... Can not Power On +3V3_STB(P100 Check AC input and PSU Pin7) is OK? P100 ON/OFF POWER PIN1,2,4=24V is Check PSU (P100 PIN 10)is >2V? OK?(+24V) Remote Power On Check IR net is CHECK STB LEVER IF Check IR net CHANGE(R156) ?
Page 30
2 Only Backlight, No Video Reset the TV set 1 Check the Q900 and Q901 is Working. LVDS Power(P902 PIN 1) is 12V ? 2 Check the LVDS cable connect normally. The P902 Check LVDS cable. PIN13,31 clock is Check the U500 working normally. normally? Check P406 RS232 information...
Page 31
3 Picture is normal, but speaker no Audio Have picture, no audio L801 L802 if have Check the speaker and signal? cable Check U803 pin Check the audio Power net(L804,R898,R899) and 2,3,34,35,40,41,44 45,is other components around 24V? And pin 13,27 is the Audio Power net) 3.3V? Check if the mute circuit...
Page 32
DC DC CONVERTER CIRCUIT 1 FAILURE POINT CHECK if the 12V OUTPUT 1.CHECK if the 24V 1,L112,L113is open circuit from U100(R194,R195) INPUT at U100 PIN2? 2,C116,C139 short circuit 3,powerboard failure FAILURE POINT 1 L103 is open circuit 2,C100,C108,C140 is short circuit 3,IC U100 4.Other 12V net FAILURE POINT...
Page 33
DC DC CONVERTER CIRCUIT 2 FAILURE POINT 1.CHECK if the 24V CHECK if the 5V OUTPUT from INPUT at U106 1,L111,L105 is open circuit U106+Q100 OUT,L106 PIN1+Q100 PIN 5? 2,C118,C109,C138 is short circuit 3,powerboard failure FAILURE POINT 1,L106 is open circuit 2,C117,C106,C165,is short circuit 3,IC U106 4.Other 5V net...
Page 34
LVDS signal output is OK, but Panel is back Check the P100 PIN12, if is PSU or LVDS cable and H(3.3V). PANEL issue Failure from ADIN3_SRV Check if R191,C163 Q102 and to R191 around Q102 is right U500 issue...
Page 35
Key and IR RC no function Check if the P900 PIN2 have P100 PIN1 is 3.3V Check IR BOARD and RC the RC waveform Check if the IR net(R993,R994) and cable is Failure point right U500 issue Key no function Check if the P901 PIN2 value is variational When you press P901 PIN1 is 3.3V...
Page 41
RAW BAG 130X260X0.06MM -- 00 00 00 R=Y H4-32F12A7-AGSC0AA 74-008010-12C RAW BAG PE 80MM×100MM (AUTO LOCK) --装底座螺丝 H4-32F12A7-AGSC0AA 72-MT10LA-ELA1A PRI IB MT10L-LA TCL EN R=Y H4-32F12A7-AGSC0AA 70-STDE32-EEM1B TV PRI ADDENDUM SHEET E320 STAND ASSY R= H4-32F12A7-AGSC0AA 67-M91257-2G0 RAW SUPPORT CHASSIS_BRK_LOW -- 00 00 00...
Page 42
FOR R CAB T8-32F12RC-SK1 74-095095-80G POLYBAG EPE (95CMX95CMX0.08CM) FOR R CAB. T8-32F12RC-SK1 76-HF1202-0AA RAW CARTON-BOX TCL LCD32F12 RC 635MM 3FOR R CAB. T8-32F12RC-SK1 76-L32F12-0AR RAW CARTON-BOX TCL LCD32F12 RC 818MM 3FOR R CAB. T8-32F12RC-SK1 77-100070-6WC WHITE BUBBLE BAG (100CMX70CM) FOR R CAB.
