SeaPerch
Remotely Operated Vehicle (ROV)
Construction Manual
Standard Assembly Procedures
December 2010
The SeaPerch educational program was created by Harry
Bohm and Vickie Jensen and published in their 1997 book
"Build Your Own Underwater Robot and Other Wet
Projects." The initial curriculum was developed by the
Massachusetts Institute of Technology, and this version of
the SeaPerch Construction Manual was provided under the
Office of Naval Research National Naval Responsibility for
Naval Engineering (NNRNE) Outreach initiative.
Version 2010-02
