Page 1: Table Of Contents
Instructions F342 JPD-FR202 Rapid Response Infrared Thermometer IMPORTANT! READ THE INSTRUCTIONS THOROUGHLY AND KEEP FOR FUTURE USE It is important to use this thermometer correctly in order to get and accurate result. Read the instructions carefully before use. CONTENT 2. TEMPERATURE RANGE 3.
Page 2: Temperature Range
34.7°C–37.3°C / 94.46°F–99.14°F Anus 36.6°C–38.0°C / 97.88°F–100.40°F This Infrared Thermometer F342 measures the human body or an object temperature based on the infrared energy emitted by the forehead or an object (such as milk and water). You can quickly get measurement results...
Page 3: Warnings
WARNING • Keep thermometer out of reach of children. • This item is not a toy. Do not allow children to play with it. • This thermometer is for domestic or home use only. • The thermometer is not intended to diagnose or treat any health problem or disease.
Page 4: Parts
PARTS A. IR sensor B. Power-on trigger / Measure button C. Battery cover D. LCD display E. Mute / Un-mute button F. Mode button G. Celsius / Fahrenheit Switch button H. Handgrip...
Page 5 FEATURES • Rapid response 1 second reading • One-click trigger action • Large backlit display with fever alert • Fever light and sound alert • Silent mode option • 20 reading memory recall • Body or object mode • ºC / ºF changeable •...
Page 6: To Use
TO USE The thermometer is provided with batteries that were installed in the factory. Before ﬁrst use open the battery cover and remove the insulating piece. CHOOSE CELSIUS OR FAHRENHEIT 1. Press and release Trigger B to turn on. 2. Press the ºC/ºF button G to switch between ºC and ºF. 36.
Page 7 BODY TEMPERATURE MEASUREMENT • It is important to know each individual's normal temperature when they are well. This is the only way to accurately diagnose a fever. To determine normal temperature, take multiple readings when healthy. Re-measure with a standard digital thermometer for conﬁrmation. •...
Page 8 1. Aim sensor at centre of forehead. 2. Move towards the forehead to a distance of 2-3cm. 3. Press and release Trigger measure button 4. Read the temperature on the display 36. 5 º 5. Check Alerts Range Sounds Backlight 34.9°C–37.5°C / 94.8°F–99.5°F A long beep Green...
Page 9 OBJECT TEMPERATURE MEASUREMENT 1. Aim sensor at centre of object 2-3cm away. 2. Press and release Trigger measure button 3. Read the temperature on the display 36. 8 º 4. Check Alerts Range Sounds Backlight 0°C-100°C / 32.0°F-212.0°F A long beep White 5.
Page 10: Memory Function
MEMORY FUNCTION A maximum of 20 temperature readings can be recalled. 1. Turn power on. 2. Press and hold the M Mode button until F-1 is displayed. F- 1 3. Press the ºC / ºF or the button, will be shown, followed by the recorded reading. 36.
Page 11 MUTE MODE 1. Press and release Trigger to turn on. 2. Press the Mute/un-mute button for silent operation. 3. The symbol is displayed in sound mode and disappears in mute mode. 36. 5 36. 5 º º Sound Mute TO CHANGE FEVER ALERT LEVEL 1.
Page 12 REPLACING BATTERIES If the low-battery symbol is displayed on the screen, replace the batteries. Requires: 2x AAA (DC 3V) 1. Slide the battery cover off along the marked direction. 2. Insert the 2x AAA batteries into the compartment correctly following + - direction. 3.
Page 13: Care And Maintenance
CARE AND MAINTENANCE To Clean: 1. Remove batteries 2. Clean the lens of the temperature probe with a dry cotton swab. Do not use tissue paper. 3. Wipe body of thermometer with soft, slightly damp cloth and mild detergent. Do not immerse in water. Do not use corrosive cleaners.
Page 14: Troubleshooting
TROUBLESHOOTING Problem Possible Cause Solution Low battery Change the batteries. The thermometer Polarities of the batteries Make sure that the batteries fails to power on. are reversed. are installed correctly. The thermometer is damaged. Contact the manufacturer. The ambient temperature is lower Take a measurement under an "...
Page 15 Error information The ambient temperature is A long beep and a red backlight for 3 seconds. higher than 40.0ºC (104.0ºF) or Er 1 lower than 10.0ºC (50.0ºF). An error occurs when data A long beep and a red backlight for 3 seconds. is being read from or written to the memory, or the temperature correction is...
Page 16: Specifications
SPECIFICATIONS Product Name Infrared Thermometer Product Model (#342) Power Supply Mode Internal power supply Operating Voltage DC 3V Battery Model AAA x 2 Operating Mode Continuous operating Display Segment LCD Measure time About 1 second Latency Time About 1 second Measuring Distance 1 to 5 cm / ½...
Page 17 Security Class • Type of protection against electric shock: internally powered equipment. • Degree of protection against electric shock: Type BF applied part • Degree of protection against ingress of water: IP22 • Safety degree of using in ﬂammable anesthetic gas blending with air, oxygen or nitrous oxide: Non-AP/APG •...
Page 18 Guidance and manufacturer's declaration – Electromagnetic immunity – for all equipment and systems Guidance and manufacturer´s declaration – Electromagnetic immunity The Infrared Thermometer JPD-FR202 is intended for use in the electromagnetic environment speciﬁed below. The customer or the user of the Infrared Thermometer JPD-FR202 should assure that it is used in such an environment. Immunity test IEC 60601 Compliance level...
Page 19 Recommended separation distances between portable and mobile RF communications equipment and the EQUIPMENT or SYSTEM -for EQUIPMENT and SYSTEMS that are not LIFE-SUPPORTING The Infrared Thermometer JPD-FR202 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the Infrared Thermometer JPD-FR202 can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the Infrared Thermometer JPD-FR202 as recommended below, according to the maximum output power of the communications equipment.
Page 20 Rapid Response F342 Infrared Thermometer JPD-FR202 Tee-Zed acknowledges that its customers may be entitled to statutory consumer guarantees and does not seek to exclude or limit them. These guarantees include that Tee-Zed’s products are of acceptable quality. This Tee-Zed product is for the specific purpose detailed in the instructions and packaging and Tee-Zed considers use outside of that purpose to be abnormal use.
