Installation and Operation Instructions
Stone Age Brick and Vecchio™ Pizza Ovens

1.0 Introduction

The following provides instructions for the instal-
lation, operation and care of Stone Age Brick and
Vecchio™ Pizza Ovens, manufactured by Stone
Age Manufacturing, Collinsville, Oklahoma.
Three generations of
knowledge and experience have gone into the de-
sign, construction and use of these pizza ovens. A
completed Vecchio oven, finished in rock, is shown
in Figure 1.
Figure 1. Vecchio™ Pizza Oven
The only differences between the Vecchio and
Brick Oven are size and the manner in with the
front header attaches to the side walls. These dif-
ferences can be seen in Figures 2 and 3. Tables 1
and 2 show the components and dimensions of the
two.
Table 1
Vecchio/Brick Oven Dimensions
Size (In.) Vecchio
25"
Width
28"
Depth
Opening Height
25"
Opening Width
wood-burning oven
Brick Oven
25"
26"
9" 21"
21"
If installing the oven on something other than a
StoneAge base cabinet, make sure that it will sup-
port the weight of the oven.

2.0 Pizza Oven Components

Components for the Brick Oven and Vecchio Pizza
Ovens are shown in Figures 2 and 3.
9
8
4
3
Figure 2. Vecchio™ Pizza Oven Components
9
8
4
3
Figure 3. Brick Oven Pizza Oven Components
1
9
8
3
7
2
9
8
3
7
2
1
