EINBREW 30L User Instructions

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EINBREW.COM
EINBREW 30L USER INSTRUCTIONS
V1.0.8 521 © ACKSEN LTD 2019
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 30L and is the answer not in the manual?

Questions and answers

Summary of Contents for EINBREW 30L

  • Page 1 EINBREW.COM EINBREW 30L USER INSTRUCTIONS V1.0.8 521 © ACKSEN LTD 2019...

  • Page 2: Introduction

    These user instructions will help you get the best out of your EINBREW system and allow you to use it safely, and we recommend you read through them fully before starting your brew day!

  • Page 3: Table Of Contents

    Safety Information ............................4 Technical Specifications ..........................5 Components and Accessories .........................6 Getting Started ...............................7 Cleaning ................................8 Before using EINBREW for the first time ....................8 Cleaning EINBREW after your brew day .....................8 Configuring EINBREW ...........................10 Handheld Controller ..........................10 Main Menu..............................10 Start Brewing Menu ..........................11 Settings Menu ............................12...

  • Page 4: Safety Information

    EINBREW vessel, and ensure the vessel is dry before reconnecting the electricity supply. • The EINBREW 30L MUST be used with a RCD/GFCI/RCBO device. Ensure that you test it prior to every use. • Ensure that the supplied power lead is fully unwound during use. If using any extension leads, ensure that they are fully unwound and have a >10A current capacity when unwound.

  • Page 5: Technical Specifications

    EINBREW.COM EINBREW 30L USER INSTRUCTIONS TECHNICAL SPECIFICATIONS Feature Product Dimensions Diameter 550mm, Height 780mm Power Supply Input 220Vac/230Vac, 50Hz, 10A Fuses Two (live and neutral) 15A, 32x5mm quick blow. Control Precision 0.3C Temperature Measurement Accuracy 0.3C Heating Element 2100W, 9.5A @ 230Vac Main Vessel Capacity Max.

  • Page 6: Components And Accessories

    Support immediately. 1) 1 x EINBREW stainless steel main heating vessel and control system with 2m power lead. 2) 1 x Stainless steel inner grain vessel.

  • Page 7: Getting Started

    EINBREW 30L USER INSTRUCTIONS GETTING STARTED We know you’re eager to get on with making some beer, so the first thing to do is get your EINBREW system setup! Once you’ve checked you’ve got everything, place your EINBREW on a flat and level surface near a power outlet.

  • Page 8: Cleaning

    Once the liquid level gets too low for the pump, please stop the pump, and disconnect the controller and the EINBREW from the mains, you can then lift the EINBREW by the rear cable recess and tip out any remaining water.
  • Page 9 Once the liquid level gets too low for the pump, please stop the pump, and disconnect the controller and the EINBREW from the mains, you can then lift the EINBREW by the rear cable recess and tip out any remaining water.

  • Page 10: Configuring Einbrew

    When EINBREW is not in use, the display will indicate that it is in Standby mode, along with the present Date and Time. The “signal” icon at the top-right of the display indicates that the Handheld controller is connected to the EINBREW system successfully.

  • Page 11: Start Brewing Menu

    EINBREW.COM EINBREW 30L USER INSTRUCTIONS Menu Option Explanation Settings Alter system settings. Rinse Begin the Rinse/Cleaning cycle. Pump Out Remove liquid from the system using the Pump Out accessory. Manual Operate the system in manual mode, specifying the Temperature and the pump operation.

  • Page 12: Settings Menu

    EINBREW.COM EINBREW 30L USER INSTRUCTIONS Settings Menu The Settings Menu allows you to configure how the EINBREW performs, and adjust various parameters relating to the Brewing Cycle. Menu Option Explanation Set Clock Allow the System Clock to be set. The present Date and Time can be defined.

  • Page 13: Rinse Menu

    When you select this option, you’ll be asked to confirm if you’ve added water. Please insert the inner vessel, add 30L of water and replace the lid before continuing. Select the Abort option to exit without rinsing.

  • Page 14: Pump Out Menu

    Rinse cycle and return to Standby. Pump Out Menu The Pump Out option allows you to remove water from the EINBREW system, either after brewing or when cleaning. To use, remove the inner vessel and fit the Pump Out Pipe over the pump central outlet at the bottom-middle of the main vessel.

  • Page 15: Recipes Menu

    Pump Out mode and return to Standby. Recipes Menu EINBREW will let you pre-define 10 of your favourite recipes to make brewing quick and easy! You can change the recipes settings just before you begin in the Start Brewing menu, or use the Recipes Menu to get everything setup before your brewday.
  • Page 16 EINBREW.COM EINBREW 30L USER INSTRUCTIONS Each Recipe has several settings you can adjust. You can define up to 9 mashing stages - if you would like to skip/bypass a stage, you can set its Time to off (0 minutes!) and it’ll be ignored when brewing.
  • Page 17 Enable optional cooling at the end of the Brewing Cycle. This will allow you to use the EINBREW integrated cooler in conjunction with a cold water feed to reduce the temperature of your wort to safe levels for fermentation before pumping out.

  • Page 18: Brewing Wort

    Before brewing, please ensure that you have followed the steps in the Cleaning section – this will help prevent infection. Also make sure that the inner vessel has been removed from EINBREW. It is also important to note that the system will preheat faster and use less energy if you keep the lid on as much as possible during the brewing process.
  • Page 19 (e.g. 00:04:15/00:18:04). All times are in Hours, Minutes and Seconds (hh:mm:ss). EINBREW uses proportional heating, so it’ll apply less heat energy the closer you get to your Set Temperature. This reduces overshoot and minimises energy usage.

  • Page 20: Mashing

    Mashing At the end of the Preparation stage, an alarm will sound and you can add the inner vessel to EINBREW. You may find it easier to leave adding the grain until the inner vessel has been added and is beginning to fill up with water –...

  • Page 21: Grain Removal

    EINBREW.COM EINBREW 30L USER INSTRUCTIONS equalise and start rising. The wort will begin to be pumped into the bottom of the inner vessel, and will slowly rise through to the top and spill over back into the main vessel. This provides gentle recirculation and continuous sparging of the grain.

  • Page 22: Boiling Wort

    Raise the inner vessel slowly out of the hot wort, using the fixings on the side to rest it near the top of EINBREW. Let the wort drain out for a few minutes first – this will return most of the liquid back to the brew and make it easier to lift it out.

  • Page 23: Cooling Wort

    EINBREW has the ability to pump at boiling point to help infuse your wort with the flavour from the hops, although normally it will be set to go off at higher temperatures, to prevent the pump struggling due to boil turbulence and cavitation.

  • Page 24: Brew Complete And Pumping Out

    We strongly recommend that you always save your exhaust water. As EINBREW pumps the wort through the cooler automatically, all you have to do is sit and wait – the controller will alarm and turn the pump off when your target temperature is reached, you can then turn off your cold water (coolant) feed.

  • Page 25: Cleaning

    Pump Out mode and return to Standby. Cleaning One last thing to take care of before you can safely store away your EINBREW for your next batch – cleaning! Please follow the instructions in the Cleaning section for how to proceed. It’s important to clean immediately after brewing, as leaving it as-is will encourage growth of mould and other unpleasant effects.

  • Page 26: Troubleshooting

    • Brew taking a long time to reach Set Temperature It can be normal for EINBREW to take a reasonable length of time to preheat to temperatures in your mashing stage – typically you may find an increase in temperature of 1°C every 1 minute.
  • Page 27 If you accidentally or purposefully disconnect the Handheld controller, then it will lose power and any progress in the present brewing process will be lost. For safety, after a short period the EINBREW will automatically turn off the Pump and Heater when it senses the Handheld is disconnected.
  • Page 28 If a power failure occurs, please switch off EINBREW at the plug. Once power has been restored, turn on EINBREW again. Depending on the duration of the outage, you may be able to pick off close to where you left off. There are two ways to achieve this.

  • Page 29: Volumes And Masses (Weights)

    VOLUMES AND MASSES (WEIGHTS) Maximum Strike volume is about 30L with <4kgs grain. If you want a larger grain bill then strike with less and for every added kg of grain above 4kg, deduct 2L from 30L strike volume, at mash-out suspend grain and sparge to desired volume &...

  • Page 30: Returning Einbrew For Repair

    The heating element is not user serviceable; please contact your supplier in the first instance, then the manufacturer. Please remember to follow the Cleaning instructions when you receive EINBREW, and after every time you utilise the product.
