Primare DVDI10 Upgrade

Hide thumbs Also See for DVDI10:
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
Contains:
HDMI upgrade board
1. Download the three latest software from Primares Erez webserver and burn
the files on a CD-rom. (Info about webserver at the last page).
2. Download Flash magic at: www.flashmagictool.com/
3. RS-232 (Two versions available - AM/FM or DAB)
4. HDMI (Internal, unit has to be opened)

Step 1 Download software and burn CD-rom

After burning all 3 files on a disc please proceed as below:
!IMPORTANT! Do not interrupt the update sequence!
- Please switch the DVDI-10 ON
- Open the disc tray
- Put in the CD-rom
- Close the tray
- Wait until the display says *SUCCESS* (the tray will open in the
update sequence, please do not do anything until the update is
ready)
Tel: +46 (0)470 72 92 15, Fax: +46 (0)470 7298 25, Email: info@primare.net
FULL UPGRADE DVDI-10
Primare AB, Renvägen 1, SE-352 45, Växjö, Sweden
www.primare.net
1 pc
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVDI10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Primare DVDI10

Summary of Contents for Primare DVDI10

  • Page 1 - Wait until the display says *SUCCESS* (the tray will open in the update sequence, please do not do anything until the update is ready) Primare AB, Renvägen 1, SE-352 45, Växjö, Sweden Tel: +46 (0)470 72 92 15, Fax: +46 (0)470 7298 25, Email: info@primare.net www.primare.net...
  • Page 2 Step 2 RS-232 How to upload software Please turn the DVDI10 off using the mainswitch on the back side. Start flash magic from your computer. To do the upgrade you will have to use the computer with a null modem cable and an RS232 port Run the program.
  • Page 3 Press the browse button to select the software file that’s located on the CD-ROM. To set the DVDI10 into upgrade mode press and hold the open button while switching the power on using the mainswitch on the backside. When the unit is in programming mode it will not do anything (blank screen etc.)
  • Page 4 4. Attach cable ILP to 5J1 (Be sure to connect G to G (marked black on the cable) 5. NOTE – Pin V is not connected as shown in RED circle below. Primare AB, Renvägen 1, SE-352 45, Växjö, Sweden Tel: +46 (0)470 72 92 15, Fax: +46 (0)470 7298 25, Email: info@primare.net www.primare.net...
  • Page 5 Connect powercable from the updater board to the JP12 cable which you have disconnect. (RED meets RED) and please isolate the updaterboard from the chassis. Primare AB, Renvägen 1, SE-352 45, Växjö, Sweden Tel: +46 (0)470 72 92 15, Fax: +46 (0)470 7298 25, Email: info@primare.net www.primare.net...
  • Page 6 Choose the COM port that you use on your computer. (If COM port is missing use a USB to COM port) Primare AB, Renvägen 1, SE-352 45, Växjö, Sweden Tel: +46 (0)470 72 92 15, Fax: +46 (0)470 7298 25, Email: info@primare.net www.primare.net...
  • Page 7 JP12. (please see page 5) Disconnect programmercable and remount jumpers in original position. Power on the DVDI10 and test its function. Primare AB, Renvägen 1, SE-352 45, Växjö, Sweden Tel: +46 (0)470 72 92 15, Fax: +46 (0)470 7298 25, Email: info@primare.net www.primare.net...
  • Page 8 Webserver instructions http://library.primare.net/ User: matthias Pass: barolo Primare AB, Renvägen 1, SE-352 45, Växjö, Sweden Tel: +46 (0)470 72 92 15, Fax: +46 (0)470 7298 25, Email: info@primare.net www.primare.net...
