Pod Installation Instructions
Installation
All Necessary Safety Items/PPE
•
Utility Knife
•
Two (2) Cordless Drills/Drivers
•
(1) 4-6 ft. Ladder
•
4"+ Long Magnetic Bit Holder
•
Pod S - 46" x 46" x 91" H
Notes before starting:
Evaluate existing room to ensure there are no obstructions that will interfere with placement of Pod.
Ensure building outlet is near final placement of Pod.
Determine whether or not your Pod can be transported preassembled to its final location.
Keep all material for one Pod together as parts are specific for each Pod.
1199 Pod Installation Instructions
- Tools Needed
Pod M - 53" x 77" x 91" H
4' Level
•
1/2" Wrench
•
Dead Blow Hammer/Mallet
•
Panel Cart(s)
•
(2) Vacuum Suction Cups with load
•
capacity of 100 lbs. per cup
1 of 10
Call 888-766-7834
Press 0 and ask for Pod
installation assistance
Pod L - 77" x 77" x 91" H
8/14/2019
Advertisement
Related Manuals for SnapCab Pod S
Summary of Contents for SnapCab Pod S
- Page 1 • capacity of 100 lbs. per cup Pod M - 53” x 77” x 91” H Pod S - 46” x 46” x 91” H Pod L - 77” x 77” x 91” H Notes before starting: Evaluate existing room to ensure there are no obstructions that will interfere with placement of Pod.
- Page 2 YGEN IS BEING ADMINISTERED • DO NOT SIT OR STAND ON TABLE (WEIGHT RATING MAX LOAD POD S: 120LBS. POD M AND POD L: 200LBS.) WARNING: RISK OF ELECTRIC SHOCK – CONNECT THIS FURNISHING TO A PROPERLY GROUNDED OUTLET ONLY. SEE GROUNDING INSTRUCTIONS.
- Page 3 (6) total 1/4”-20 x 1 1/2” Flange head bolts securing Cano- removes screws from outside Pod. Use provided bit to re- py to Corner Extrusions. If a Pod S or Pod M, the Ceiling move eight (8) #10 x 3/4” Round head square drive screws Canopy is one piece.
- Page 4 Call 888-766-7834 Press 0 and ask for Pod installation assistance 5. Remove Front Frame Assembly from Floor Base: 6. Remove Rear Corner Extrusions from Floor Base: Use provided 9/16” wrench to remove four (4) 3/8 x 1-3/4" Remove two (2) 3/8 x 1-3/4" Serrated Flange Bolts per cor- Serrated Flange bolts holding Front Corner Extrusions to ner, holding each Corner Extrusion to Floor Base.
- Page 5 (rear) labeled panels. 11. Attach middle and top rows of Interior Panels: 12. Place Ceiling Canopy Note a Pod S and Pod M will have a one piece canopy. A Pod L will have a two (2) piece Starting with Red (side) labeled panel, insert bottom canopy.
- Page 6 Secure table mounted electric unit to notch in table by 1/4"-20 x 1" bolts into T-Nuts from inside Canopy. Lift Ceil- tightening clamps. If Pod S, install brackets on rear and ing into place and slide Rear Ceiling Legs onto partially in- side wall into predrilled holes with #10 x 3/4”...
- Page 7 19. Install Glass Door and Bottom Filler Block: Pod S—Take provided Strike Post and angle diagonally inside Pod S – Using suction cups lift and angle top of door to input Front Frame opening, careful not to scratch Front Frame.
- Page 8 21. Adjust and Secure Glass Sidelight(s): Loosen four set screws holding interior door pull. Remove Pod S—Skip to Step 22 screw attached to exterior door pull. From inward side of Pod M & L—From outside Pod take provided green tip set...
- Page 9 Front Corner Extrusion and lower bot- panel. Using 1 1/4" SnapCab panel screws, attach wall pan- tom tongue of panel into previously installed Toe Kick Bind- els.
- Page 10 Clean Pod using provided glass cleaner and paper towels, leave remaining cleaning supplies with end user. Put trash in supplied trash bag and dispose. Take some great in- stalled Pod pictures and email them to Marketing@SnapCab.com. 1199 Pod Installation Instructions 10 of 10 8/14/2019...
