The Opitec Range of projects is not intended as play toys for young children. They
are teaching aids for young people learning the skills of craft, design and technolo-
gy. These projects should only be undertaken and operated with the guidance of a
fully qualified adult. The finished projects are not suitable to give to children
under 3 years old. Some parts can be swallowed. Danger of suffocation!
Contents List
Wooden Strip
Plywood
Modelling Plywood
Rod
Wooden Strip
Wooden Ball
Foam Rubber
Tapping Screw
General:
The hand sander is designed for a 60 mm sanding belt. If you want to use the abrasive paper cut 280 x 230mm you have to shorten the base plate
and the handle for 2cm. This is pointed out again in the instructions.
1
Hand Sander - Wood
Please Note!
Quantity
117.329
Tools Needed
Fretsaw or
Scroll Saw
Phillips
Screwdriver
Scissors
Size (mm):
1
200x60x10
1
200x100x15
1
70x50x1,5
1
150x4
1
250x15x15
1
ø 20
1
29x40
4
Ruler
Pencil
ø1,5
ø4
Drill
Wood Glue
Adhesive Tape
Locking Clamp
Designation:
Base
Handle
Holder Handle
Fastener Handle
Strips Handle
Fastener Handle
Bottom
Attachment Holder
Sandpaper
Craft Knife
Part-No.
1
2
3
4
5
6
7
8
Advertisement
Summary of Contents for Opitec 117.329
- Page 1 Screwdriver Please Note! The Opitec Range of projects is not intended as play toys for young children. They are teaching aids for young people learning the skills of craft, design and technolo- gy. These projects should only be undertaken and operated with the guidance of a fully qualified adult.
- Page 2 Instructions 117.329 Hand Sander - Wood If necessary, use the dashed template, which is 20 mm shorter! ø1,5 Cut out the template on page 5 and glue it on the plywood (2) by using Cut out the template on page 5 and glue it on the modelling plywood adhesive tape.
- Page 3 Instructions 117.329 Hand Sander - Wood If necessary shorten the base by 20mm! The length of the base plate depends on the used sandpaper! Glue Glue a woodcutting (5c) flush to the outer edge of the base (1) as the wooden strip (1) on the foam rubber plate (7). After the glue has shown.
- Page 4 Instructions 117.329 Hand Sander - Wood Shorten the rod (4) by 60 mm. Clean the saw cut and glue it into the Insert the sandpaper as shown and fix it through inserting the handle. hole of the wooden ball (6).
- Page 5 Instructions 117.329 Template M 1:1 Template Handle Template Holder M 1:1 M 1:1 template for holder 20mm shorter...
