60" 4 DRAWER HARDWOOD WORKBENCH
*Actual product may vary slightly
Please carefully read and save these instructions before attempting to assemble, maintain, install, or operate this product.
Observe all safety information to protect yourself and others. Failure to observe the instructions may result in property
damage and/or personal injury. Please keep instructions for future reference.
For warranty purchases, please keep your dated proof of purchase. File or attach to the manual for safe keeping.
For Customer Service, Call 1-800-348-5004
43100
02/2017
or e-mail customerservice@focus-ontools.com
Advertisement
Summary of Contents for Steel Core 43100
- Page 1 Observe all safety information to protect yourself and others. Failure to observe the instructions may result in property damage and/or personal injury. Please keep instructions for future reference. For warranty purchases, please keep your dated proof of purchase. File or attach to the manual for safe keeping. For Customer Service, Call 1-800-348-5004 43100 02/2017 or e-mail customerservice@focus-ontools.com...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in serious injury. Save all warnings and instructions for future reference. 1. Do not exceed weight capacities for the Workbench shelves and drawers. Be aware of dynamic loading! Sudden load movement may briefly create excess load causing product failure. -
Page 3: Parts Diagram
PARTS DIAGRAM 1. Table Top (1) 2. Shelf (2) 3. Cross Brace (3) 2pcs 4. Leg (4) 2pcs 5. Vise (5) 1pc 6. Ø80mm Screw (6) 6pcs (Spar parts 2pcs) 7. Ø80mm Bolt (7) 8pcs 8. Connecting Nut (8) 8pcs 9. -
Page 4: Assembly Steps
ASSEMBLY INSTRUCTIONS Read the ENTIER IMPORTANT SAFETY INFORMATION section at the beginning of this document including all text under subheadings therein before set up or use of this product. 1. NOTE: More than one person is needed for proper assembly. 2. - Page 5 2. Once both Legs have Been fastened to the Cross Brace, slide the Shelf(2) above against the legs so that the far edge fits onto the groove on the Cross Brace. Shelf (2) 3. Insert Connecting Nuts (8) into holes at end of Cross Braces(3). (as same as 1) Cross Brace(3) customerservice@focus-ontools.com...
- Page 6 4. Overturn Table Top (1), facing to FRONT, put Sliding Partition(14) dowel alignment the holes, then tighten Screw(13), Don't lose any screws. 14. Sliding Partition (14) hold FRONT customerservice@focus-ontools.com 1-800-348-5004...
- Page 7 5. Putting the PART 3 to PART 4. Using Ø80mm tighting Screw (6) . Then installing Lower Support (15)。 Lower Support (15) customerservice@focus-ontools.com 1-800-348-5004...
- Page 8 6. After that, overturn the workbench, as following picture 7. Installing the drawers Drawer Handle(21) customerservice@focus-ontools.com 1-800-348-5004...
- Page 9 8. Putting the drawers into the slide rail 1） Note：Before installing, must do as picture A to slide the rail to the top part. Slide the rail to the top part 2）Putting the drawers to the slide rail slowly, don't overexert 3）...
- Page 10 9. Installing Vise(5) on the bench top. 10. Putting the Wood Peg(10) and Small Anvil Peg(11) into the holes on the bench top. Finished customerservice@focus-ontools.com 1-800-348-5004...
- Page 11 Limited Manufacturer Warranty FOT makes every effort to ensure that this product meets high quality and durability standards. FOT warrants to the original retail consumer a 1-year limited warranty from the date the product was purchased at retail and each product is free from defects in materials.
