Ocutech VES FALCON Autofocus Bioptic Fitting Instructions Manual

Hide thumbs Also See for VES FALCON Autofocus Bioptic:

Advertisement

Quick Links

Download this manual
6/20/2019
Fitting the
8 Simple steps to get your patient on
their way to the most natural
telescopic vision possible.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the VES FALCON Autofocus Bioptic and is the answer not in the manual?

Questions and answers

Related Manuals for Ocutech VES FALCON Autofocus Bioptic

Summary of Contents for Ocutech VES FALCON Autofocus Bioptic

  • Page 1 6/20/2019 Fitting the 8 Simple steps to get your patient on their way to the most natural telescopic vision possible.
  • Page 2 6/20/2019 Step 1: Align the eyepiece for the eye Loosen the two rear mounting screws and slide the telescope right or left to align the eyepiece directly above the eye that will use the telescope. For use by the other eye, loosen the rear mounting screws a little further and slide the telescope off the bracket, flip it over and reinsert it on the mounting bracket.
  • Page 3 6/20/2019 Step 2: Adjust the nosepads Adjust the nosepads so that the bottom of the eyepiece aligns with the top of the patient’s pupil...
  • Page 4 6/20/2019 Step 3: Align the viewing angle When the patient lowers their head to look through the telescope, adjust the viewing angle of the Falcon so the patient’s line of sight is parallel to the seam on the side of the telescope.

  • Page 5: Step 4: Attach The Battery

    6/20/2019 Step 4: Attach the battery It won’t work unless it’s plugged in! You can use either port. Once plugged in the lights on the battery illuminate and the Falcon starts automatically.
  • Page 6 6/20/2019 Step 5: Set the eyepiece focus Have your patient look through the Falcon at the center of an eye chart held about 20-40” (0.5 to 1.0m) away. Choose print several sizes above their best acuity. Insert the eyepiece focus adjustment tool and rotate it to move the eyepiece in or out until the image is in focus for the patient.
  • Page 7 6/20/2019 Step 6: Lock the eyepiece When dispensing the Falcon to your patient, use the Allen wrench to lock the eyepiece in place. DO NOT OVER-TIGHTEN THE SETSCREW.
  • Page 8 6/20/2019 Step 7: Close the focus port Close the focus access port by inserting the plug provided. It can be easily removed if the Falcon needs to be re-focused.
  • Page 9 6/20/2019 Step 8: Demonstrate the focus over-ride button Review the instructions about how to use the focus over-ride button to lock the focus in place at distance or any near position.
  • Page 10 6/20/2019 That’s it! You’re done! Please, please, please review the printed fitting guide included with each Falcon and watch the full online fitting video at: https://www.youtube.com/watch?v=6X2Lt- CyE40&feature=youtu.be...
