Action Sports Equipment Verao S002035-3 Manual

427cm (14ft)

Advertisement

427cm (14ft) Trampoline
READ PRIOR TO ASSEMBLING AND USING THE TRAMPOLINE
To ensure your safety, please do not attempt to assemble this trampoline without reading
WARNING:
this instruction manual carefully. Failure to comply with this warning may result in injury and/or property
damage.
Prior to assembly, this trampoline includes small parts/accessories that are not suitable for
children under 3 years of age as they may cause a choking hazard.
This trampoline should be assembled by 2 adults.
Only use this trampoline on a soft, flat level surface.
This trampoline has a maximum user weight of 120kg.
This trampoline is suitable for users aged 6 years and over.
Do not allow more than 1 person on the trampoline at any time.
This trampoline is designed for domestic use only, it is not intended for gymnastics or high
level acrobatic stunts.
For parts and service enquiries, please contact Action Spares on 1800 465 070 or e-mail
service@actionspares.com.au
ATTENTION!
SAFETY INFORMATION, INSTALLATION, CARE
AND MAINTENANCE INSTRUCTIONS.
S002035-3

Advertisement

loading
Need help?

Need help?

Do you have a question about the Verao S002035-3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Action Sports Equipment Verao S002035-3

  • Page 1 427cm (14ft) Trampoline S002035-3 ATTENTION! SAFETY INFORMATION, INSTALLATION, CARE AND MAINTENANCE INSTRUCTIONS. READ PRIOR TO ASSEMBLING AND USING THE TRAMPOLINE To ensure your safety, please do not attempt to assemble this trampoline without reading WARNING: this instruction manual carefully. Failure to comply with this warning may result in injury and/or property damage.
  • Page 2: Table Of Contents

    Contents Warnings Installation Instructions Care and Maintenance Instructions Safety Information Parts List Assembly Instructions Warranty Information S002035-3 Verao 427cm (14ft) Trampoline...
  • Page 3: Warnings

    Warnings To reduce the risk of serious injury, read the entire manual before you assemble or use this trampoline. In particular, please note the following safety precautions. Please keep this manual in a safe place for future reference. Prior to assembly, this trampoline includes small parts/accessories that are not suitable for children under 3 years of age as they may cause a choking hazard.
  • Page 4 Warnings (cont) 18. Ensure that the frame padding is correctly and securely positioned prior to use. 19. Climb on and off the trampoline, do not jump on or off. It is dangerous to jump from the trampoline to the ground when dismounting, or onto the trampoline when mounting. Always use two hands to hold onto the frame when getting on or off the trampoline.
  • Page 5: Installation Instructions

    Installation Instructions Place the trampoline on a flat level surface with impact attenuating properties such as grass and ensure that it is sufficiently stable to prevent it from tipping over and/or blowing away. Sandbags or pegs may be suitable anchorage devices. Keep a minimum of 5m overhead clearance when measured from the bed height to prevent users inadvertently contacting overhead hazards such as electric wires, tree limbs and clotheslines.
  • Page 6: Care And Maintenance Instructions

    Care and Maintenance Instructions Components of this trampoline are susceptible to deterioration from use and environmental conditions, such as sunlight, rain, salt and heat, to varying degrees. It is essential that you inspect the trampoline before each use and replace any worn, defective, or missing parts before further use. Use only parts that are recommended by the manufacturer.
  • Page 7: Safety Information

    Safety Information Trampolines are great fun, encourage the development of gross motor skills; provide opportunities for physical activity and present users with manageable challenges to find and test their limits. However, like many physical activities, trampoline use involves potential risk of injury, particularly if the equipment is used improperly.
  • Page 8 Safety Information (cont) Safe Use Instructions To reduce the risk of injury while using the trampoline, develop household rules such as the following: • Do not allow children under 6 years on the trampoline. • Allow only one person on the trampoline at any one time. •...
  • Page 9 Safety Information (cont) Basic Trampolining Instructions This trampoline is a domestic trampoline, not a gymnastics trampoline. You will get the safest and best use from it by following these basic principles: • Do not attempt or allow somersaults on the trampoline. Landing on your head or neck while doing somersaults can cause serious injury, paralysis or even death.
  • Page 10: Parts List

    Parts List Part No. Description Frame Pad Top Rail Leg Base Leg Extension Spring Safety Instruction Placard Spring Hook T-Joint Lower Enclosure Pole Upper Enclosure Pole Pole Cap Fibreglass Rod Pole Sleeve Some parts may be supplied pre-assembled. NOTE: S002035-3 Verao 427cm (14ft) Trampoline...
  • Page 11: Assembly Instructions

    Assembly Instructions To assemble this trampoline all you will need is the spring hook that is provided within the carton. During periods of non-use, the trampoline can be disassembled and stored. Prior to assembling this trampoline, remove all parts from the carton and check to ensure that all parts listed in the Parts List on page 10 are present.
  • Page 12 Assembly Instructions (cont) Step 2 Attach the 12 x Leg Extensions (5) to the 6 x Leg Bases (4) and secure them into place using the locking pins. Take the 6 sets of legs and insert them into the base of the T-Joints (9) on the frame and secure them into place using the locking pins.
  • Page 13 Assembly Instructions (cont) Step 3 Lay the Mat (1) out flat on the floor inside of the completed trampoline frame. Ensure that the side of the Mat (1) with double stitching is facing downward, the warning label stitched into the mat should be located on the top side of the mat.
  • Page 14 Assembly Instructions (cont) Step 4 To attach the Net (13) to the Mat (1), unfold the net and line up the zipper with the frame where you would like to position the entrance. Next, take the tabs at the bottom of the Net (13) and place these tabs over the V-Rings on the Mat (1) so the net sits against the mat.
  • Page 15 Assembly Instructions (cont) Step 5 Attach 1 x Safety Instruction Placard (7) to the trampoline frame in a position that is easily visible. Thread the included cable tie through the hole in the Safety Instruction Placard (7) and wrap it around the frame. Lay the Frame Pad (2) over the trampoline so that the springs and frame are completely covered.
  • Page 16 Assembly Instructions (cont) Step 6 Insert 1x Lower Enclosure Pole (10) into the base of 1x Upper Enclosure Pole (11) and secure it in place using the locking pins. Repeat the above instruction for all remaining 11 x Lower Enclosure Poles (10) and 11 x Upper Enclosure Poles (11).
  • Page 17 Assembly Instructions (cont) Step 7 2 people will be needed at this point to insert the fibreglass rods. NOTE: Take the Net (13) and lay it out flat across ground. The top of the Net (13) is the edge with the sewn-in loop.
  • Page 18 Assembly Instructions (cont) Step 8 Locate the zipper on the Net (13) and align this to face the where you would like the entrance of the trampoline to be. Lift the Fibreglass Rod (14) ring and connect it to the enclosure pole caps by inserting it into the grooves.
  • Page 19 Warranty Information Congratulations on your purchase! This Verao 427cm (14ft) Trampoline is warranted to be free from defects in material and workmanship under normal use and service conditions for a period of 2 years on the frame and mat, 12 months on all other parts, from the date of purchase of this article.
  • Page 20 9:00am – 4:30pm Monday to Friday (excluding Public Holidays) 9:00am – 3:00pm Saturday This product is warranted and distributed by: Action Sports of 48B Egerton St, Silverwater NSW, 2128 Phone: (02) 8799 3500 © 2017 Action Sports Equipment Pty Ltd. S002035-3 Verao 427cm (14ft) Trampoline...
