Summary of Contents for Solid Technologies Alliance eROU
- Page 1 Alliance_eROU User Manual Document Reference: Version: V1.0 Document Status: Release 1 Issue Date: March 10, 2020 Author: Yang-Su Kim Department: R&D Division Team 2 Authorizing Manager: hyun-suk Chae Confidential & Proprietary 1/19...
- Page 2 REVISION HISTORY No. of Version Issue Date Initials Details of Revision Changes Pages V 1.0 March 09, 2020 Original Technical Support SOLiD serial numbers must be available to authorize technical support and/or to establish a return authorization for defective units. The serial numbers are located on the back of the unit, as well as on the box in which they were delivered.
-
Page 3: Table Of Contents
Contents Section1 Safety & Certification Notice ............... 4 Section2 System configuration and Functions ............10 2.1 eROU(edge Remote Optic Unit) ............... 10 2.1.1 Specifications of eROU ................11 Port on eROU ................... 12 2.1.2 2.1.2.1 Functions ....................12 Section3 System Installation ................... 14 3.1 eROU Installation ................... -
Page 4: Safety & Certification Notice
Section1 Safety & Certification Notice Confidential & Proprietary 4/19... - Page 5 “Only qualified personnel should handle the DAS equipment. Any person involved in installation or service of the DAS should understand and follow these safety guidelines.” - Obey all general and regional installation and safety regulations relating to work on high voltage installations, as well as regulations covering correct use of tools and personal protective equipment.
- Page 6 overvoltage protection device - Only 50 ohm rated antennas, cables and passive equipment shall be used with this remote. Any equipment attached to this device not meeting this standard may cause degradation and unwanted signals in the bi-directional system. All components connected to this device must operate in the frequency range of this device.
- Page 7 - Use of unauthorized antennas, cables, and/or coupling devices not conforming with ERP/EIRP and/or indoor‐only restrictions is prohibited. - Home/ personal use are prohibited. UL/CUL: This equipment complies with UL and CUL 1950-1 Standard for safety for information technology equipment,including electrical business equipment ...
- Page 8 of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
- Page 9 minimum de au moins 50 cm entre la source de radiation (l’antenne) et toute personne physique. Cet appareil ne doit pas être installé ou utilisé en conjonction avec une autre antenne ou émetteur. Confidential & Proprietary 9/19...
-
Page 10: Section2
Section2 System configuration and Functions 2.1 eROU(edge Remote Optic Unit) eROU receives TX optical signals from eHUB and converts them into RF signals. The converted RF signal is radiated to the antenna port via the AMP and Multiplexer. When receiving RX signals through the antenna port, this unit filters out-of-band signals in a corresponding Multiplexer and sends the results to OPTIC to make electronic-optical conversion of them. -
Page 11: Specifications Of Erou
<Integrated Antenna> <External Antenna> Figure 2. eROU outer Look 2.1.1 Specifications of eROU Spec. Item Remark eROU 700LTE_FN +19dBm The rated mean output Power 2500_100TDD +23dBm per band 1900P AWS13 +23dBm 700LTE_FN 39MHz The nominal downlink 2500_100TDD 194MHz bandwidth 1900P 65MHz AWS13 70MHz... -
Page 12: Port On Erou
1900P 43dB AWS13 43dB 700LTE_FN 2500_100TDD Uplink 45dB 1900P AWS13 Input/ Output Impedance 50 ohm 2.6 kg(Internal) Weight 3.0 kg(External) Common Part Power consumption Temperature range -5°C to +50°C Ambient Temperature Humidity Range 5% ~ 90% Non-condensing Sealing (Remote Unit) IEC/UL/CSA 62368-1 IP50 220 x 220 x 90... - Page 13 Port Quantity Remark Optical Port LC/APC ANTENNA PORT(External Only) 2.2-5 type female Power IN Terminal_Block_CONN_2P(TLPS-302V-02P-G) ADD ON eROU Port QMA-type female ADD ON eROU Port RJ45 USB Port USB-C Type Confidential & Proprietary 13/19...
-
Page 14: Section3
Section3 System Installation eROU Installation The following table shows the required accessories and tools for installing eROU. Tools Q’ty Specification Remark (+), Ø 3.0 For fixing Length is more than 20mm 3.1.1 eROU Enclosure installation The eROU can be mounted on a wall or ceiling. and divided into the version of External Antena and the version of Internal Antena. - Page 15 Figure 5. Dimension used to install eROU (internal) Figure 3. Dimension used to install eROU (internal) Confidential & Proprietary 15/19...
-
Page 16: Erou(Internal Antenna) Mount Installation_ Case .1
3.1.2 eROU(Internal Antenna) Mount Installation_ Case .1 3.1.3 eROU(Internal Antenna) Mount Installation_ Case .2 Confidential & Proprietary 16/19... -
Page 17: Erou(Internal Antenna) Mount Installation_ Case .3
3.1.4 eROU(Internal Antenna) Mount Installation_ Case .3 3.1.5 eROU(External Antenna) Mount Installation Confidential & Proprietary 17/19... -
Page 18: Installation Cable Gland
3.1.6 Installation Cable Gland 3.1.6.1 eROU 3.1.6.2 Combine of eROU and cROU From/To eHUB From/To eHUB Confidential & Proprietary 18/19... -
Page 19: Power Cabling
3.1.7 Power cabling 1. The eROU receives DC power from the eHub or external adapter. 2. Cable length between eHub and eROU supports up to 2.4 km.(Cable specifications recommend AWG14.) 3. If the maximum length between the eHub and the eROU is exceeded, the use of the External Adapter is recommended.
