- Page 1 OWNER’S MANUAL: EZ-PDU’S ™ OWNER’S MANUAL EZ-PDU’s EZ-PDU’s © 2021 ArcTiv Technologies, Ltd. ATEZPDU-MANUAL-01...
-
Page 2: Table Of Contents
3.1 NETWORK METER FUNCTIONS ………………………………………………………………………………………………………………………………………… 3.2 INITIALIZATION ………………………………………………………………………………………………………………………………………………………………… 3.3 HARDWARE SETTINGS ……………………………………………………………………………………………………………………………………………………… 3.4 DAISY CHAIN SETTINGS ……………………………………………………………………………………………………………………………………………………. 3.5 SOFTWARE OVERVIEW …………………………………………………………………………………………………………………………………………………….. 3.6 SNMP ACCESS ………………………………………………………………………………………………………………………………………………………………….. 3.7 TELNET ACCESS ………………………………………………………………………………………………………………………………………………………………… 4. SPECIFICATIONS …………………………………………………………………………………………………………………………………………………………………. 5. WARRANTY .………………………………………………………………………………………………………………………………………………………………………… © 2021 ArcTiv Technologies, Ltd. ATEZPDU-MANUAL-01... -
Page 3: Product Overview
Upgrade the network module Full Range International and local plugs and outlets Easy Installation Tool-less 0U mounting compatible with Server and Network Racks Safe Operation Locking C13 outlets prevent accidental removal of power cables © 2021 ArcTiv Technologies, Ltd. ATEZPDU-MANUAL-01... -
Page 4: Safety Instructions
Do not use this equipment in the presence of a flammable anesthetic mixture with air, oxygen or nitrous oxide. © 2021 ArcTiv Technologies, Ltd. ATEZPDU-MANUAL-01... -
Page 5: Network Metering
Light up the LCD background, select the address code, threshold of voltage, current, temperature selection key and humidity RESET Restart button Restart the device Screen View the states Display the power and environment status Sensor port Connect the external T/H sensor © 2021 ArcTiv Technologies, Ltd. ATEZPDU-MANUAL-01... -
Page 6: Initialization
OFF indicator will be displayed in red on the screen Note: All above settings must be saved by pressing the MENU key, and the settings will take effective after the beep sound, otherwise, the device will beep but without saving the settings. © 2021 ArcTiv Technologies, Ltd. ATEZPDU-MANUAL-01... -
Page 7: Daisy Chain Settings
User can access the Network Metered EZ-PDU’s through a WEB interface, SNMP (v1) or Telnet command console. Web Browser Access User can access the Network Metered EZ-PDU’s via web browser through the IP address. The login window is illustrated below. The factory default username is ‘admin’, the password is ‘admin’. © 2021 ArcTiv Technologies, Ltd. ATEZPDU-MANUAL-01... - Page 8 Threshold Setting Set the threshold of current, voltage, temperature and humidity. • Input Current Range: Single Phase: 0-63A Three Phase: 0-32A • Input Voltage Range: 170-276VAC • Temperate range: 0-45℃ • Humidity range: 0-99% © 2021 ArcTiv Technologies, Ltd. ATEZPDU-MANUAL-01...
- Page 9 Clear energy line1：Click button. (The same operation for Line 2 and Line3 for 3phase products.) User Settings User can change the user name and password (the max. character length for each is 16 digits). © 2021 ArcTiv Technologies, Ltd. ATEZPDU-MANUAL-01...
- Page 10 Telnet settings • Select from “Enable” or “Disable” to configure the Telnet feature, the default state is enabled. Note: Restarting software is necessary after SNMP setting. Go to “SNMP Access (V1)” section for instructions. © 2021 ArcTiv Technologies, Ltd. ATEZPDU-MANUAL-01...
- Page 11 Select Activity: User can restart the software or restore to factory default settings by clicking “Save”. When the Network Module buzzes, the software restart is successful. Note: Press and hold the MENU button when powering on to restore to factory settings. © 2021 ArcTiv Technologies, Ltd. ATEZPDU-MANUAL-01...
-
Page 12: Snmp Access
C 1.3.6.1.4.1.534.6.6.8.3.12 the current of phase 3 from slave unit 1 s2CurrentC 1.3.6.1.4.1.534.6.6.8.3.13 the current of phase 3 from slave unit 2 s3CurrentC 1.3.6.1.4.1.534.6.6.8.3.14 the current of phase 3 from slave unit 3 © 2021 ArcTiv Technologies, Ltd. ATEZPDU-MANUAL-01... - Page 13 3 from slave unit 2 s3EnergyC 1.3.6.1.4.1.534.6.6.8.6.14 the power consumption of phase 3 from slave unit 3 s4EnergyC 1.3.6.1.4.1.534.6.6.8.6.15 the power consumption of phase 3 from slave unit 4 © 2021 ArcTiv Technologies, Ltd. ATEZPDU-MANUAL-01...
- Page 14 3 from slave unit 1 s1VolAlarmC 1.3.6.1.4.1.534.6.6.8.8.12 1: Normal 2：Low-voltage 3: Over-voltage the voltage alarm of phase 3 from slave unit 2 s2VolAlarmC 1.3.6.1.4.1.534.6.6.8.8.13 1: Normal 2：Low-voltage 3: Over-voltage © 2021 ArcTiv Technologies, Ltd. ATEZPDU-MANUAL-01...
- Page 15 1: Normal 2: Low-temperature 3:Over-temperature the temperature alarm of slave unit 4 s4TemAlarm 1.3.6.1.4.1.534.6.6.8.10.5 1: Normal 2: Low-temperature 3: Over-temperature the Humidity alarm of master unit mHumAlarm 1.3.6.1.4.1.534.6.6.8.10.6 1: Normal 2: Low-Min humidity 3:Over-Max humidity © 2021 ArcTiv Technologies, Ltd. ATEZPDU-MANUAL-01...
-
Page 16: Telnet Access
Example: status 0：To view the amps/volts/kWh and temp/humid of the Master unit Note: the actual value should be 10x of the displayed value Reboot Enter the REBOOT command line to restart the device. Reset Enter the RESET command line to restore to factory settings. © 2021 ArcTiv Technologies, Ltd. ATEZPDU-MANUAL-01... -
Page 17: Specifications
Send E-mail to administrator automatically SNMP sends trap alerts Web based, access via common web browsers Access SNMP v1 support Modbus (optional, request for this feature before production) User name and password configurable User Management © 2021 ArcTiv Technologies, Ltd. ATEZPDU-MANUAL-01... -
Page 18: Warranty
If you have questions about this product or need technical support, please contact us or visit our website. ArcTiv Technologies, Ltd. 4F., No. 12, Ln. 345, Yangguang St., Neihu Dist., Taipei City 114 , Taiwan (R.O.C.) sales@arctiv-tech.com www.arctiv-tech.com ™ Latest Revision: November, 2021 © 2021 ArcTiv Technologies, Ltd. ATEZPDU-MANUAL-01...
