Summary of Contents for Orinoquia U5760

Page 1 Quick Start Guide U5760 Orinoquia...
Page 2 Copyright © Industria Electrónica Orinoquia S.A. 2014. All rights reserved. No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of Industria Electrónica Orinoquia S.A. The product described in this manual may include copyrighted software of Industria Electrónica Orinoquia S.A.
Page 3 Thus, the descriptions herein may not exactly match the product or its accessories which you purchase. Industria Electrónica Orinoquia S.A. reserves the right to change or modify any information or specifications contained in this manual without prior notice and without any liability.
Page 4 Import and Export Regulations Customers shall comply with all applicable export or import laws and regulations and be responsible to obtain all necessary governmental permits and licenses in order to export, re-export or import the product mentioned in this manual including the software and technical data therein.
Page 5: Safety Precaution
Safety Precaution Please read these safety precautions carefully before operating your phone. Do not crush, throw, or puncture your phone. Avoid dropping, squeezing, or bending it also. Your phone is not meant for use in a damp environment, such as the bathroom. Do not submerge your phone in liquid of any sort and avoid getting your phone wet.
Page 6 Do not attempt to disassemble your phone or its accessories. Only qualified personnel are allowed to service or repair the phone. Do not place your phone or its accessories in containers with a strong electromagnetic field. Do not place magnetic storage media near your phone.
Page 7: Your Phone
1 Your Phone Earpiece Screen Confirm key Left soft key Call/Answer key Music key Number keys * key Microphone # key...
Page 8 Back key End/Power key Right soft key Navigation keys Camera Loudspeaker Headset jack Charger jack/USB port...
Page 9: Installing The Sim Card And Battery
2 Installing the SIM Card and Battery Before you begin to use your phone, a SIM card must be inserted. Follow the steps laid out below to insert your SIM card into the phone. Power off your phone before attempting to remove the battery or SIM card.
Page 10: Inserting The Microsd Card
3 Inserting the microSD Card 4 Charging the Battery When the battery icon changes to or the charging animation becomes static, the battery is fully charged. If the battery has not been used for a long time or if the battery power is completely depleted, the charging icon may take several minutes to appear after you start charging.
Page 11: Keys And Functions
5 Keys and Functions In this guide, the navigation keys of the phone are indicated by Press Select the option displayed in the lower left corner of the screen. Select the option displayed in the lower right corner of the screen. Dial a number or answer a call.
Page 12 Press In text input mode, delete the character to the left  of the cursor. Press and hold the key for 3 or more seconds to clear all the characters to the left of the cursor. Return to the previous menu. ...
Page 13: Text Input
Press Enter #.  Lock the keypad in standby mode (press and hold  the key for about 3 seconds). 6 Text Input Changing the Text Input Mode The current text input mode indicator is displayed in the upper right corner of the text input screen.
Page 14: Creating A Contact
number. In any input mode other than 123 input mode, press and hold  the number key for about 3 seconds to enter the desired number. Entering a Symbol 1. In any input mode, press to display the symbol list. 2.
Page 15: Playing Music
4. Select Options > Send to send the message. 10 Camera Select Menu > Multimedia > Camera, and press to take a photo. On the Camera screen, press (Options) to configure camera settings. To view your photos, select Options > Go to Album. To set the default storage location, select Options >...
Page 16: Locking The Keypad
12 Locking the Keypad To lock the keypad, press and hold for about 3 seconds in standby mode. When the keypad is locked, you can still press to answer a call or make an emergency call. To unlock the keypad, press then 13 Phone Lock The phone lock protects your phone from unauthorized use.
Page 17: Safety Information
14 Safety Information This section contains important information about the operation of your device. It also contains information about how to use the device safely. Read this information carefully before using your device. Electronic device Do not use your device if using the device is prohibited. Do not use the device if doing so causes danger or interference with other electronic devices.
Page 18: Traffic Security
Exposure to high volumes while driving may cause distraction  and increase your risk of an accident. Areas with flammables and explosives Do not use the device where flammables or explosives are stored  (in a gas station, oil depot, or chemical plant, for example). Using your device in these environments increases the risk of explosion or fire.
Page 19: Operating Environment
wireless networks, present a hazard to aircraft operation, or be illegal. Operating environment Avoid dusty, damp, or dirty environments. Avoid magnetic fields.  Using the device in these environments may result in circuit malfunctions. Do not use your device during thunderstorms to protect your ...
Page 20 quality may be reduced. Do not allow children or pets to bite or suck the device or  accessories. Doing so may result in damage or explosion. Observe local laws and regulations, and respect the privacy and  legal rights of others. Child's safety Comply with all precautions with regard to Child Safety.
Page 21: Battery Safety
Unplug the charger from electrical outlets and the device when  not in use. Do not drop or cause an impact to the charger.  If the power cable is damaged (for example, the cord is exposed  or broken), or the plug loosens, stop using it at once. Continued use may lead to electric shocks, short circuits, or fire.
Page 22: Cleaning And Maintenance
Do not attempt to modify or remanufacture the battery, insert  foreign objects into it, or immerse or expose it to water or other liquids. Doing so may lead to fire, explosion, or other hazards. If the battery leaks, ensure that the electrolyte does not make ...
Page 23 with an external heat source, such as a microwave oven or hair dryer. Do not expose your device or accessories to extreme heat or cold.  These environments may interfere with proper function and may lead to fire or explosion. Avoid collision, which may lead to device malfunctions, ...
Page 24: Environmental Protection
Emergency calls The availability of emergency calls is subject to your cellular network quality, service provider policy, and local laws and regulations. Never rely solely on your device for critical communications like medical emergencies. Environmental protection The device and its accessories (if included), such as the power ...
Page 25 The highest SAR value reported to the FCC for this device type when using at the ear is 1.489 W/kg, and when properly worn on the body is 1.325 W/kg. FCC statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 26 Caution: Any changes or modifications to this device not expressly approved by Industria Electrónica Orinoquia S.A. for compliance could void the user's authority to operate the equipment.
