Racelogic 02 - VBOX Quick Start Manual

Sport battery and charging

02 - VBOX Sport Battery and Charging

To check the remaining battery time, briefly press the power button. The LEDs will then illuminate to indicate charge,

with each LED representing 25% of remaining charge.

75% battery remaining

Charge the VBOX Sport using the provided USB cable, connected either to a powered USB port or to the optional in-car

12 V charger. During charging, the power LED will slowly flash. Once the internal battery of the VBOX Sport has been

fully recharged the Power LED will change to a double flash. This should take no more than 4 hours.

NOTE: The power LED double flashing indicates the unit is no longer accepting charge. Normally, this is due to the

battery being full. However, this can also indicate that the unit has an inadequate power source or the battery is not

charging at all. To determine this, please check the units charge as per the 'check battery level' section above.

https://en.racelogic.support//Product_Info/Performance_Meters/VBOX__Sport/VBOX_Sport_User_Guide/02_-

_VBOX_Sport_Battery_and_Charging

Table of Contents

Do you have a question about the 02 - VBOX and is the answer not in the manual?

Page 1 02 - VBOX Sport Battery and Charging Check battery level To check the remaining battery time, briefly press the power button. The LEDs will then illuminate to indicate charge, with each LED representing 25% of remaining charge. 75% battery remaining...
Page 2 Fully charged, the VBOX Sport will provide a minimum six hours battery life, but in typical use this can be in excess of eight. https://en.racelogic.support//Product_Info/Performance_Meters/VBOX__Sport/VBOX_Sport_User_Guide/02_- _VBOX_Sport_Battery_and_Charging...
