American Recorder PHPO-1001 Quick Start Manual

IMPORTANT FYI

- For intended use only - can only be used to power a single channel
condenser microphone. Do not attempt to operate more than one
microphone at a time with this device, damage may occur.
- For use with balance level microphones and audio devices. When connect-
ing OUTPUT to an unbalanced device, an adapter plug may be required.
- To avoid sound spikes, always turn the sound levels all the way down
before powering up this device.
- Never plug a microphone into this device when the power is on.
- Turn the power off when not in use.

SPECIFICATIONS

Input Voltage (Power Supply): 110VAC
Output Voltage: (Power Supply): 18VAC
Output Voltage (XLR INPUT): 48VAC
Power Consumption: 5 watts or less

WARRANTY

AMERICAN RECORDER TECHNOLOGIES, INC. (ART) includes with this product a limited
one year guarantee, free from defects in manufacture and workmanship to the original owner.
Warranty does not apply to misuse, abuse, neglect, accident, improper use, etc. ART
reserves the right to make such determination on the basis of factory inspection. A valid
return authorization number must be obtained from ART customer service department
for all factory warranty service. All warranty repairs must be returned prepaid. (COD's will be
refused).
visit us on the web at:
www.AmericanRecorder.com
manufactured and distributed by
American Recorder Technologies, Inc
1872 Angus Ave., Simi Valley, CA 93063 - USA
P. 805-527-9580 ● E. sales@AmercianRecorder.com
Supports Device: Condenser Microphone
Enclosure Material: Aluminum
Enclosure Dimensions: 3.5" x 3.5" x 1.75"
Weight: 1.2 lbs
Made in China
48V PHANTOM

POWER SUPPLY

MODEL: PHPO-1001
