AquaCal
Expansion Board Upgrade
(Upgrade Kit #STK0247)
Installation Quick Start Guide
This document describes how to install an HP9 expansion board upgrade
For more installation advice, see the online installation and operation manual.
http://www.aquacal.com/wp-content/uploads/manuals/landingpage/exp/Expansion_Board_Upgrade_Manual.htm
Important
Read this document before operating this product
For additional product manuals and operation / installation procedures, please visit www.AquaCal.com
LTP0168 REL B
- (project rel 8.00)
Advertisement
Summary of Contents for Aquacal STK0247
- Page 1 This document describes how to install an HP9 expansion board upgrade For more installation advice, see the online installation and operation manual. http://www.aquacal.com/wp-content/uploads/manuals/landingpage/exp/Expansion_Board_Upgrade_Manual.htm Important Read this document before operating this product For additional product manuals and operation / installation procedures, please visit www.AquaCal.com LTP0168 REL B - (project rel 8.00)
-
Page 3: Table Of Contents
Table of Contents 1 - Connections 2 - Presets 3 - Configuration 3.1 Create a Group 3.2 Create a Schedule... -
Page 4: Connections
1 - Connections This section describes how to connect actuators, circulation pumps, and relay-controlled devices to the heat pump. Failure to heed the following will result in injury or death. DANGER Deactivate power while routing wiring to control board. RISK OF ELECTRICAL SHOCK FROM ENERGY STORED IN CAPACITORS - MODELS EQUIPPED WITH VARIABLE FREQUENCY COMPRESSOR DRIVES STORE ELECTRICITY EVEN AFTER THE POWER HAS BEEN DEACTIVATED AT THE POWER BREAKER. - Page 5 Figure 1 - Port Connections 5. Remove power control board from the heat pump. 6. Connect plastic standoffs into the expansion board. 7. Press the expansion board onto the control board making sure that data pins are aligned with data ports as indicated in Figure 1 .
-
Page 6: Presets
2 - Presets When the heat pump is first activated, an installation wizard will be displayed. If used, a list of site configurations (presets) will be offered. If the installation wizard was skipped, the system can be set to factory default and the wizard will reappear. See "Factory Reset". Press the button under "START" to use the wizard and view the available heat pump presets. - Page 7 Pool / Spa, No Valves, Pentair VS This preset configures the heat pump as follows: No valve actuator is configured. A Pentair (or Sta-Rite) variable speed circulation pump is configured. A pool schedule is configured (Everyday from 8:00 am to 6:00 pm) When pressed, the "Pool/Spa"...
- Page 8 Pool / Spa, No Valves, Single Speed This preset configures the heat pump as follows: No valve actuators are configured. A single speed circulation pump is configured to use the relay "A" connection point on the expansion board. A pool schedule is configured (Everyday from 8:00 am to 6:00 pm) When pressed, the "Pool/Spa"...
- Page 9 Pool / Spa, Valves, Hayward VS This preset configures the heat pump as follows: Two actuator valves are configured named intake (on "VA INTAKE") and return (on "VA RETURN"). A Hayward variable speed circulation pump is configured. A pool schedule is configured (Everyday from 8:00 am to 6:00 pm) When pressed, the "Pool/Spa"...
- Page 10 Pool / Spa, Valves, Single Speed This preset configures the heat pump as follows: Two actuator valves are configured named intake (on "VA INTAKE") and return (on "VA RETURN"). A single speed circulation pump is configured to use the relay "A" connection point on the expansion board.
- Page 11 Pool Only, No Valves, Hayward VSS This preset configures the heat pump as follows: No valve actuators are configured. A Hayward variable speed circulation pump is configured. A pool schedule is configured (Everyday from 8:00 am to 6:00 pm) When pressed, the "Pool/Spa" button will display with two choices. 1.
- Page 12 Spa Only, No Valves, No Pump This preset configures the heat pump as follows: No valve actuators are configured. No circulation pump is configured. No schedules are configured. When pressed, the "Pool/Spa" button will display with two choices: 1. Spa - With an initial timer of 2 hours at 104° F. 2.
- Page 13 Spa Only, No Valves, Jandy VS This preset configures the heat pump as follows: No valve actuators are configured. A Jandy variable speed circulation pump is configured. A pool schedule is configured (Everyday from 8:00 am to 6:00 pm) When pressed, the "Pool/Spa" button will display with two choices. 1.
- Page 14 Use Setup from USB A file, previously saved onto a USB thumb drive, can be used to configure the heat pump. PLEASE NOTE: This file will take advantage of any custom configurations entered by the installer on prior installations. The file will contain the equipment, group, and schedule settings. Other settings such as multi-unit installations, external control mode, etc.
-
Page 15: Configuration
3 - Configuration 3.1 Create a Group EXAMPLES OF GROUPS THAT CAN BE CREATED: Backyard Lights Group A pool light and a spa light that have been connected and configured by the heat pump installer can be activated upon demand. Cold Plunge Group - A spa can be set to "COOL"... - Page 16 ENTER TO SAVE USE ARROWS TO SET ENTER TO SAVE FREEZE PROTECT OPTION PRESS BUTTON UNDER PRESS "ENTER" USE ARROWS TO "YES" TO SAVE TO ADD EQUIPMENT SELECT EQUIPMENT ENTER TO SAVE USE ARROWS TO ENTER TO SAVE DEVICE OPERATING STATE USE ARROWS TO PRESS "ENTER"...
-
Page 17: Create A Schedule
3.2 Create a Schedule A maximum of four (4) schedule programs can be configured for each group. In this example a schedule is created to activate the backyards lights on the weekends from 9:00 pm to 10:00 pm. Enter "Schedules" menus, then proceed IF UNIT IS ASLEEP, PRESS MENU USE ARROWS TO... - Page 18 MENU TO EXIT, PRESS & HOLD TO STATUS Page - 15...
