Installation and Operating Instructions
Description:
Model Number:
ROBINHOOD DOUBLE DRAWER DISHWAHSER
RHDDW60X
Model pictured: RHDDW60X
Actual unit may differ from image above
Issue: 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RHDDW60X and is the answer not in the manual?

Questions and answers

Summary of Contents for ROBINHOOD RHDDW60X

  • Page 1 Installation and Operating Instructions Issue: 1 Description: ROBINHOOD DOUBLE DRAWER DISHWAHSER Model Number: RHDDW60X Model pictured: RHDDW60X Actual unit may differ from image above...
  • Page 2: Table Of Contents

    It is important that you retain these instructions and your proof of purchase along with any other important documents about this product for future reference. Due to continual product development, Robinhood reserves the right to alter specifications or appearances without notice. Important Safety Instructions………………………………………………………………………………………………………………………..3 Appliance Details……………………………………………………………………………………………………………………………………………4...
  • Page 3: Important Safety Instructions

    Important Safety Instructions When using electrical appliances, in order to reduce the risk of fire, electric shock, and/or injury to persons, basic safety precautions should always be followed, including 1. This appliance is intended to be used in household and similar applications , such as: a.
  • Page 4: Appliance Details

    Appliance details IMPORTANT: To get the best performance from your dishwasher, read all operating instructions before using it for the first time. Product Overview...
  • Page 5 Installation Instructions Height (H1) 820 mm Height (H2) 85-135 (Height of kick plate) Width (W) 595 mm Depth (D1) 570 mm Depth (D1) 1080 mm (Drawer open)
  • Page 6: Installation

    Installation Instructions Before Installation Parts supplied Ensure that the inner end of the tab is protruding by one material thickness Mounting brackets (4) (for drain hose coupling) Hose clamp (1) Wire clamps (2) (for sink waste connection) (for drain hose coupling) Moisture protection tape (1) Drain hose coupling (1) Kick plate brackets (2)
  • Page 7 Installation Instructions Prepare the cavity The cavity will need to conform to the dimensions in the diagram. The water supply and power point for the appliance cannot be in the dishwasher cavity. Ideally they should be in an adjacent cavity, easily accessed for isolating the product.
  • Page 8 Installation Instructions Installation method A: Attach top mounting brackets Installation method B: Attach side mounting brackets Fitting the dishwasher Position the dishwasher in the cavity so the drawer fronts are in line with the adjacent cabinetry. Draw the hoses and power cord through the opening as you slide the product in. This can be checked by using a spirit level on an open drawer.
  • Page 9 Installation Instructions Secure the product in place With suitable fasteners, fix the mounting brackets to the cabinetry. Install the kick plate 1. Prepare a kick plate as shown. (The mounting hole position is measured by the machine at the factory state. If the height of the feet is adjusted, the position of the mounting hole should be changed according to the actual situation.) 2.
  • Page 10 Installation Instructions 3. Secure the brackets to the kick plate with screws and install the kick plate to the bottom of the dishwasher. If you need to install the kick plate inside, please cut the kick plate to the appropriate height according to the actual situation, and ensure that the clearance between the bottom surface of...
  • Page 11 Installation Instructions Connection of the Drain Hose There are two recommended options for connecting the drain hose. Option A: Connecting to the sink waste This is the recommended method. Check if your sink waste pipe has provision for this method. Beware if it has the drain hose spigot that has never been used, it will likely be blanked off inside the spigot.
  • Page 12 Installation Instructions Option B: Connecting to a standpipe The standpipe must be a minimum diameter of 38 mm (1 1/2 inch) and requires a trap for odor control. Use the hose support clip to secure the hoses, ensure they do not enter the standpipe more than 120 mm.
  • Page 13 Installation Instructions Electrical Shock Hazard Disconnect electrical power before installing dishwasher. Failure to do so could result in death or electrical shock. The installation of the pipes and electrical equipment should be done by professionals. For personal safety: Do not use an extension cord or an adapter plug with this appliance. Do not, under any circumstances, cut or remove the earthing connection from the power cord.
  • Page 14: Operating Instructions

    Operating Instructions QUICK USER GUIDE Starting A Wash Discard scraps Load dishes carefully Scrape large food particles off For better washing result, place the and remove any foreign dishes properly avoiding any contact objects. or overlapping between them. Check spray arm Add detergent and check rinse aid Ensure there are no items blocking If the “...
  • Page 15 Operating Instructions After The Wash The drying fan may continue to run for a set time after that the washing cycle is over or until the drawer is open. For best drying result, we recommend remove unloading the dishes when they have cooled down. NOTE: ...
  • Page 16 Operating Instructions Control Panel Operation (Button) Press this button to turn on your dishwasher, the screen will light up. Power Press the button to select either upper drawer or lower drawer loaded, the Drawer corresponding indicator will light up. selector Press this button to select the appropriate washing program, the selected Program program indicator will light up.
  • Page 17 Operating Instructions Display Auto sensing wash, lightly, or heavily soiled crockery, with or without dried-on food. For the heaviest soiled crockery, such as pots, pans, casserole dishes and dishes that have been sitting with dried food on them for some time. For normally soiled loads, such as pots, plates, glasses and lightly soiled pans, standard everyday cycle.
  • Page 18 Operating Instructions Display If the delay time is set, the corresponding indicator will be lit. For better drying result. (It can only be used with Intensive, ECO, Heavy, Wash&Dry, Delicate) Option For removing bad odor and moisture even when dishes a re left longer time in the baskets.
  • Page 19 Operating Instructions Before using your dishwasher: Remove the larger residue from the wash items Load the basket Load the detergent Fill the rinse aid dispenser Basket Use Tips There are many ways to adjust the loading pattern of the basket. Removing the rear rack The rear rack can be removed to create a flat surface for such things as pots and pans.
  • Page 20 Operating Instructions Folding down the pins The spacing between the pins can be increased by folding them down. This will help the loading of large bowls and deep pots and pans. Folding down the pins, the maximum size 290mm plates can be loaded.
  • Page 21 Operating Instructions Adjustable the cup racks You can adjust these cup racks to different heights independently: 1. Fold the cup racks if you need more space. 2. Remove the cup holder and installation an iron wire of different height to adjust the height of the cupholder.
  • Page 22 Operating Instructions Preparing and Loading Dishes  Consider buying utensils which are identified as dishwasher-proof.  For delicate items, select a program with the lowest possible temperature.  To prevent damage, do not take glass and cutlery out of the dishwasher immediately after the program has ended.
  • Page 23 Operating Instructions  To avoid damage, glasses should not touch one another.  Please do not overload your dishwasher. This is important for good results and for reasonable consumption of energy. Note: Very small items should not be washed in the dishwasher as they could easily fall through the basket.
  • Page 24 Operating Instructions Loading the cutlery basket You can place each knife, spoon, or fork separately into the spoon stands in the basket’s covers to prevent chipping and discoloration. Below image demonstrates the suggested placement of cutlery items. Match the numbers in the diagram to the numbers in the list of cutlery items above. Settings for Standards Wash Test AS/NZS 2007.1 Capacity: 7 place settings per drawer Wash Program: ECO Detergent quantity: 23.75g...
  • Page 25 Operating Instructions To shorten the drying time, the drawer can be opened approx. 50mm at the end of the wash cycle. This however is not compulsory. The wash load will dry completely given the drying time suggested in the Wash Cycle table. Adding Detergent The chemicals in Dishwasher Detergent are necessary to remove, dissolve and help dispose of all the soils from the wash load.
  • Page 26 Operating Instructions Undo the plug by turning it Fill the dispenser slowly to avoid anticlockwise. spillage. Each dispenser will take 300ml from empty. NOTE: It is important to clean up any spills rinse aid, as it will cause excessive foaming in the wash cycle.
  • Page 27 Operating Instructions Wash Cycle Table The table below shows which programs are best for the levels of food residue on them and how much detergent is needed. It also shows various information about the programs.
  • Page 28 Operating Instructions Note: AS/NZS 2007.1: This program is the test cycle. The information for comparability test in accordance with AS/NZS 2007.1. Select A Drawer 1. Close the drawer; press the Power button to switch on the machine. 2. Press the Drawer button to choose a drawer. After selecting a drawer, the response light will turn on, and the corresponding drawer program, reservation, and other information are displayed.
  • Page 29 Operating Instructions Changing The Program Once Started A wash program can only be changed if it has not been running long. You need to ensure that the wash water is still present and it has not drained out and began rinsing. Detergent will have to be re added if there is no wash water present.
  • Page 30: Cleaning And Maintenance

    Cleaning and Maintenance Keeping your dishwasher clean improves its performance, reduces unnecessary repairs, and lengthens its life. WARNING: Disconnect the dishwasher from the power supply (unplug or switch off at the circuit breaker) and allow all its parts to cool before any cleaning or maintenance. External Care It’s best to clean spills on the outside of your dishwasher as they occur.
  • Page 31 Cleaning and Maintenance Lift up the handles and remove the Rotate the Cylinder filter counter- plate support clockwise. Lift the Cylinder filter upwards and out of under the basket. Pull forward the Fine filter. Tilt the Fine filter and remove it from under the basket.
  • Page 32 Cleaning and Maintenance Rotate the Cylinder filter clockwise to the close arrow. Spray arms If you are in a hard water area, it is necessary to clean the spray arms regularly for hard water chemicals will clog the spray arm jets and bearings. To clean the spray arms, follow the instructions below: With one hand raise the basket Slightly tilt the arm and remove...
  • Page 33 Cleaning and Maintenance Wash the arms in soapy and warm water and use a soft brush to clean the jets. After cleaning, replace it in the opposite direction. Caring for the Dishwasher Frost precaution If you live in a region that is where the inside temperature can drop below zero, care needs to be taken to avoid possible damage if the water in the dishwasher freezes.
  • Page 34: Troubleshooting

    Troubleshooting Tips Before Calling For Service Before calling for service, check the following list for problems probable causes and what you can Problem Possible Causes What To Do Dishwasher won’t start No power. Check that the power cord is plugged in to a live power outlet and it is turned on.
  • Page 35: Product Specification

    Troubleshooting Tips Problem Possible Causes What To Do Wash items are not fully Unloading dishwasher too soon. The drying cycle must be complete before the dishwasher is unloaded. Check the Display for end time. Insufficient Rinse Aid. Check for Low Rinse Aid Level warning and re fill if necessary.
  • Page 36 Standard place settings 7 place settings top drawer 7 place settings bottom drawer Energy efficiency class Water consumption class Standard cleaning cycle Energy consumption of the standard cleaning 0.367 kWh cycle Water consumption of the standard cleaning 6.6 liter cycle Program duration of the standard cleaning cycle 170 mins Noise level...
  • Page 37: Warranty Certificate (New Zealand)

    The following conditions apply in respect of the warranty given in this certificate: Monaco Corporation Limited (“Monaco”) warrants the following Robinhood products against manufacturing defects and faulty materials, under normal use and subject to the exclusions in this certificate, for a period of: ...
  • Page 38: Warranty Certificate (Australia)

     The product was used outdoors. All Robinhood Rangehoods are suitable for indoor use only and not suitable over BBQs or charcoal cookers designed for outdoor use. In addition, this warranty does not extend to damage or defects which in our opinion, directly or indirectly arise from or are due to: exposing the product to acidic or corrosive materials or chemicals such as dyes, solvents, denture cleaner or acetone;...
