- Page 1 OPERATION & MAINTENANCE MANUAL MODELS SSCB15W-R, SSCB15W-RE SSCB15G-R, SSCB15G-RE CEILING MOUNTED ELECTRONIC AIR CLEANER IMPORTANT: PLEASE READ MANUAL BEFORE OPERATING UNIT FOR TECHNICAL SUPPORT AND REPLACEMENT FILTERS CALL: 416-410-3450 info@purdistribution.com...
-
Page 2: Table Of Contents
IMPORTANT: Please read entire instructions before Your High Efficiency Electronic Air Cleaner has been installing the Electronic Air Cleaner. designed to remove tobacco smoke particles, cooking smoke and grease, atmospheric dust, coal dust, CONTENTS insecticide dust, mites, pollen, mold spores, fungi, bacteria, viruses and more down to 0.01 micron (0.01 SAFETY CONSIDERATIONS micron = 1/2,540,000 of an inch). -
Page 3: Major Components
MAJOR COMPONENTS Motor & Fan Blade The motor is 1/12 HP, 1050 RPM, 3 speed, controlled Description by a 3-position slide switch. The motor is thermally The Electronic Air Cleaner is approximately 29½ x 27 x protected. The fan blade is aluminum, 18 inches (45.7 14½... -
Page 4: Operation & Maintenance
OPERATION & MAINTENANCE 60ºC maximum). Repeat washing process 3 times. 4. If dirt or nicotine remains on plates, let Cells soak in Wiring hot soapy water for 30 minutes. Never use any WARNING instrument to clean the cell, as this may damage the ionizing wires or bend cell plates. -
Page 5: Service
SERVICE TROUBLESHOOTING GUIDE Adjusting High Voltage Output PROBLEM: CHECK: In case of excessive arcing on a clean, dry Cell, there is Unit Does Not 1. Main breaker is ON or voltage an adjustable resistor mounted on the Power Board. Operate is supplied to unit. -
Page 6: Electrical Schematic - 120 V
Electrical Schematic - A - 120 Volt Electrical Schematic - B - with Wired Remote - 120 Volt... -
Page 7: Electrical Schematic - 220 V
Electrical Schematic - A - 220 - 240 Volt Electrical Schematic - B - with Wired Remote - 220 - 240 Volt... -
Page 8: Exploded View
Fig. 7 — Exploded View and Parts List Description Part Number Description Part Number Fan Motor C5-070D 12a Power Switch (Black) C5-0221 3-Position Slide Switch (Gray) H9-0222 Fan Blade C5-0710 Copper Contact R1-9925 13a 3-Position Slide Switch (Black) H9-0219 Power Board Fibreboard C5-0526 Fibreboard (with 2 Copper Contacts) C5-0621... -
Page 9: Warranty
LIMITED ONE YEAR WARRANTY This PUR product is warranted to the original owner to be free from electrical and mechanical defects in material and workmanship, under normal use and maintenance, within its listed capacity, for a period of one (1) year from the date of original purchase;...
