Turn the long carriage bolt clockwise until it makes contact with the bottom insert.
Slide the short carriage bolt into the Rototrac approximately to the midway point. Tighten the AD10 adaptor plate to the
Rototrac using the washer, nut, and included wrench. Place Rototrac assembly on top of the Ratchet Block Tilter.
Short Carriage
Bolt

ROTOTOM ASSEMBLY INSTRUCTIONS

Notch
AD10 Adaptor Plate
Place stand and tilter in
the upright position.
Tension Rod
Rototrac
Ratchet Block Tilter

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ROTOTOM and is the answer not in the manual?

Questions and answers

Summary of Contents for REMO ROTOTOM

  • Page 1 ROTOTOM ASSEMBLY INSTRUCTIONS Place stand and tilter in the upright position. Turn the long carriage bolt clockwise until it makes contact with the bottom insert. Slide the short carriage bolt into the Rototrac approximately to the midway point. Tighten the AD10 adaptor plate to the Tension Rod Rototrac using the washer, nut, and included wrench.
  • Page 2 Tighten AD10 & Rototrac to the Ratchet Block with the included Dum Key. Tighten the Handle to secure the Slide the 10” Rototom Assembly into the 10” Rototom to the Rototrac. Re- Rototrac with the washer on top. peat for the 6” & 8” Rototoms, sliding them into the Rototrac from the left side of the stand.
