  • Page 1 Home Appliances QW-NA31F45EIO-EN Dishwasher User Manual...
  • Page 2 Thank you for choosing this product. This User Manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference.

  • Page 3: Table Of Contents

    CONTENTS 1.SAFETY INSTRUCTIONS ....................1 1.1. General Safety Warnings ....................1 1.2. Installation Warnings .....................2 1.3. During Use........................3 2.INSTALLATION ......................... 6 2.1. Machine Positioning .....................6 2.2. Water Connection ......................6 2.3. Water Inlet Hose ......................6 2.4. Electrical Connection ....................7 2.5. Fitting the Machine Undercounter .................7 3.TECHNICAL SPECIFICATIONS ..................
  • Page 4 8.CLEANING AND MAINTENANCE ................. 22 8.1. Filters ........................... 22 8.2. Spray Arms ........................22 8.3. Drain Pump ........................22 9.TROUBLESHOOTING ....................24...

  • Page 5: Safety Instructions

    1. SAFETY INSTRUCTIONS 1. General Safety Warnings • Read these instructions carefully before using your appliance and keep this manual for future reference. Please check the packaging of your machine before installation and the outer surface of the machine once the packaging has been removed. Do not operate the machine if it appears damaged or if the packaging has been opened.

  • Page 6: Installation Warnings

    2. Installation Warnings • Choose a suitable and safe place to install your machine. • Only original spare parts should be used with the machine. Unplug the machine before installation. Check that the indoor electrical fuse system is connected in line with safety regulations. All electrical connections must match the values on the plate.

  • Page 7: During Use

    The machine door should not be left open. It may cause accidents. Place knives and other sharp objects in the cutlery basket in a blade-down position. For models with the automatic door-opening system, when the EnergySave option is active, the door will open at the end of a program.
  • Page 8 the door for one minute after it has opened. For effective drying, keep the door open for 30 minutes after a program has ended. Do not stand in front of the door after the auto-open signal sounds. In the case of a malfunction, repair should only be performed by an authorised service company, otherwise the warranty will be void.
  • Page 9 CE Declaration of Conformity We declare that our products meet the applicable European Directives, Decisions and Regulations and the requirements listed in the standards referenced. Disposal of your old machine The symbol on the product or on its packaging indicates that this product may not be treated as household waste.

  • Page 10: Installation

    2. INSTALLATION WARNING: Use the new water inlet 2.1. Machine positioning hose supplied with your machine, do not use an old machine’s hose. When positioning the machine, place it in an area where dishes can be easily loaded WARNING: Run water through the and unloaded.

  • Page 11: Electrical Connection

    2.4. Electrical connection WARNING: After removing the top panel of your dishwasher, the machine should be placed in a space of the dimensions shown in WARNING: Your machine is set to the figure below. operate at 220-240 V. If the mains voltage supply to your machine is 110 V, connect a transformer of 110/220 V and 3000 W between the electrical connection.

  • Page 12: Technical Specifications

    3. TECHNICAL SPECIFICATIONS 3.2. Technical specifications 15 place Capacity settings Dimensions (mm) Height 850(mm) Width 598(mm) Depth 598(mm) Net weight 53 kg Operating 220- 220- voltage / 50 Hz, frequency Total current 10(A) 3.1. General appearance 1. Worktop 2. Upper basket with racks Total power 3.

  • Page 13: Before Using The Appliance

    4. BEFORE USING THE APPLIANCE 4.1. Preparing your dishwasher for first use • Make sure the electricity and supply water specifications match the values indicated in the installation instructions for the machine. • Remove all packaging material inside the machine. •...

  • Page 14: Test Strip

    4.4. Test Strip Run water Keep the Shake the Wait Set the hardness level of through the strip in the strip. (1min.) your machine. tap (1min.) water (1sec) NOTE: The level is set to 3 as default. If the water is well water or has a hardness level above 90 dF, we recommend that you use filter and refinement devices.

  • Page 15: Filling With Detergent

    Do not overfill the detergent compartment. rinse aid is automatically released during Otherwise you can see whitish streaks or the hot rinse phase. If an in-sufficient bluish layers on glass and dishes which amount of rinse aid is used, whitish stains may cause glass corrosion.
  • Page 16 Level Brightener Dose Indicator Rinse-aid not r1 is shown on the dispensed display. 1 dose is r2 is shown on the dispensed display. 2 doses are r3 is shown on the dispensed display. 3 doses are r4 is shown on the dispensed display.

  • Page 17: Loading Your Dishwasher

    5. LOADING YOUR WARNING: To avoid any possible DISHWASHER injuries, place long-handle and sharp- pointed knives with their sharp points facing down or horizontally on the baskets. For best results, follow these loading guidelines. Loading the household dishwasher up to the capacity indicated by the manufacturer will contribute to energy and water savings.
  • Page 18 Foldable racks Foldable racks on the upper basket are designed in order to let you place big items easier such as pots, pans, etc. If requested, each part can be folded separately, or all of them can be folded and larger spaces can be obtained.
  • Page 19 Direct wash function This function is used to wash glasses, bottles etc. by directing the water upwards while the apparatus on the upper basket (shown in the figure) is in vertical position. While the apparatus is in horizontal position, water is directed downwards, contributing to washing the lower basket.
  • Page 20 Upper Cutlery Basket The upper cutlery basket is designed for the placement of large and small cutlery and utensils. WARNING: Knives and other sharp objects must be placed horizontally in the cutlery basket. The basket is easily removed from the...

  • Page 21: Alternative Basket Loads

    5.2. Alternative basket loads Unsuitable items for dishwashing Lower basket • Cigarette ashes, candle leftovers, polish, paint, chemical substances, iron- alloy materials. • Forks, spoons and knives with wooden, bone, ivory or nacrecoated handles; glued items, items soiled with abrasive, acidic or base chemicals.

  • Page 22: Program Table

    6. PROGRAM TABLE Intensive 65°C Auto Quick 30’ Program Express 50’ Hygiene 70°C (Model (Model Name: 40°C 65°C depending) depending) Standard program for Suitable for Suitable normally Suitable for normally for heavily soiled daily Suitable for Auto program lightly soiled soiled daily soiled dishes Type of Soil:...
  • Page 23 • The program duration may change according to the amount of dishes, the water temperature, the ambient temperature and selected additional functions. • Values given for program other than the eco program are indicative only If your model has a turbidity sensor, it has an auto program instead of an intensive •...

  • Page 24: The Control Panel

    5. Start/Pause Button 7. THE CONTROL PANEL Press the Start/Pause button to start the program. The wash lamp turns on and the (16) (11) (15) (9) (8) (10) Remaining Time Indicator shows the prog- ram duration. It also indicates the remaining time during the program flow.

  • Page 25: Cancelling A Program

    13. Extra Rinse Option Indicator Press the Start/ If the Rinse option is selected, Pause button. washing-rinsing steps will be added into the selected program, so you can ensure that your dishes will be extra clean and shiny. 14. Extra Dry Option Indicator If you select Extra Dry option, extra heating and drying steps will be added into the se- lected program,so your dishes will be dried...

  • Page 26: Switching The Machine Off

    save energy. 7.3. Switching the Machine Off 4. When Save Power Mode is deactivated “IL0” will be displayed. If Save Power Mode Switch your machine off with the On/Off is deactive, interior lights will be on as long button after the program has ended and as the door is open, and the machine will the End light turns on.

  • Page 27: Cleaning And Maintenance

    8. CLEANING AND To remove and clean the filter combination, turn it counter clockwise and remove it by MAINTENANCE lifting it upwards (1).Pull the coarse filter out of the micro filter (2).Then pull and remove Cleaning your dishwasher is important to the metal filter (3).Rinse the filter with lots of maintain the machine’s service life.

  • Page 28: Drain Pump

    8.3 Drain Pump Large food residues or foreign objects which were not captured by the filters may block the waste water pump. The rinsing water will then be above the filter. Warning Risk of Injury! When cleaning the waste water pump, ensure that you do not injure yourself on pieces of broken glass or pointed implements.

  • Page 29: Troubleshooting

    9. TROUBLESHOOTING TROUBLE POSSIBLE FAULT WHAT TO DO CODE Make sure the water inlet tap is open and water is flowing. Separate the inlet hose from the tap and clean the filter of Water inlet system failure the hose. Contact for service if the error continues. Pressure system failure Contact for service.
  • Page 30 FAULT POSSIBLE CAUSE TROUBLESHOOTING Use the correct amount of detergent, Not enough detergent used. as instructed in the program table. Rinse aid dosage and/or water Increase rinse aid and/or water softener softener setting set too low. level. Whitish stains remains on dishes.
  • Page 31 Service & Support Visit Our Website sharphomeappliances.com...
