Summary of Contents for EtiamPro ENVR208

  • Page 2 ENVR208 User Manual About this Manual This Manual is applicable to Network Video Recorder (NVR). The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
  • Page 3 ENVR208 Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.

  • Page 4: Symbol Conventions

    ENVR208 Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Provides additional information to emphasize or supplement important points of the main text. Indicates a potentially hazardous situation, which if not avoided, could result in equipment damage, data loss, performance degradation, or unexpected results.

  • Page 5: Safety Instructions

    ENVR208 Safety Instructions ⚫ Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. ⚫ In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region. Please refer to technical specifications for detailed information.

  • Page 6: Product Key Features

    ENVR208 Product Key Features General ⚫ Connectable to network cameras, network dome and encoders. ⚫ Connectable to the third-party network cameras like ACTI, Arecont, AXIS, Bosch, Brickcom, Canon, PANASONIC, Pelco, SAMSUNG, SANYO, SONY, Vivotek and ZAVIO, and cameras that adopt ONVIF or PSIA protocol.
  • Page 7 ENVR208 ⚫ HDD group management. ⚫ Supports HDD standby function. ⚫ HDD property: redundancy, read-only, read/write (R/W). ⚫ HDD quota management; different capacity can be assigned to different channel. ⚫ RAID0, RAID1, RAID5, RAID6 and RAID 10 are supported. ⚫ Hot-swappable RAID storage scheme, and can be enabled and disabled on your demand. And 16 arrays can be configured.
  • Page 8 ENVR208 Files Management ⚫ Vehicle detection files and human files search and export. ⚫ Export video data by USB, SATA or eSATA device. ⚫ Export video clips when playback. ⚫ Either Normal or Hot Spare working mode is configurable to constitute an N+1 hot spare system.
  • Page 9 ENVR208 ⚫ ANR (Automatic Network Replenishment) function is supported, which enables the IP camera save the recording files in the local storage when the network is disconnected, and synchronizes the files to the device when the network is resumed. ⚫ Remote reverse playback via RTSP.

  • Page 10: Chapter 1 Introduction

    ENVR208 Chapter 1 Introduction 1.1 Front Panel Figure 1-1 DS-7600NI Series Table 1-1 Panel Description No. Name Connections POWER Turns green when device is powered up. Flickers red when data is being read from or written to HDD. Flickers blue when network connection is functioning Tx/Rx properly.
  • Page 11 ENVR208 On the IR Remote: Step 3 Press the DEV button. Step 4 Use the Number buttons to enter the Device ID# that was entered into the device. Step 5 Press Enter button to accept the new Device ID#. Figure 1-2 Remote Control...

  • Page 12: Function Description

    ENVR208 Table 1-2 IR Remote Functions No. Name Function Description •To Turn Power On: -If User Has Not Changed the Default device Device ID# (255): 1.Press Power On/Off button (1). -If User Has Changed the device Device ID#: 1.Press DEV button.
  • Page 13 ENVR208 Enable IR Remote: Press DEV button, enter device Device ID# with number keys, press Enter to pair unit with the device Disable IR Remote: Press DEV button to clear Device ID#; unit will no longer be paired with the device...
  • Page 14 ENVR208 Checks checkbox Play or pause video in Playback mode Advance video a single frame in single-frame Playback mode Stop/start auto switch in auto-switch mode Enter PTZ Control mode Go back to previous screen RESERVED Reserved Select all items on a list...
  • Page 15 ENVR208 ⚫ Batteries are installed correctly and the polarities of the batteries are not reversed. ⚫ Batteries are fresh and not out of charge. ⚫ IR receiver is not obstructed. ⚫ No fluorescent lamp is used nearby If the remote still can’t function properly, please change a remote and try again, or contact the...

  • Page 16: Usb Mouse Operation

    ENVR208 1.3 USB Mouse Operation A regular 3-button (Left/Right/Scroll-wheel) USB mouse can also be used with this device. To use a USB mouse: Step 1 Plug USB mouse into one of the USB interfaces on the front panel of the device.

  • Page 17: Rear Panel

    ENVR208 1.4 Rear Panel Figure 1-3 DS-7600NI-I2/8P and DS-7600NI-K2/8P Series Table 1-4 Panel Description No. Name Description Audio In RCA connector for audio input. Audio Out RCA connector for audio output. VGA Interface DB9 connector for VGA output. Display local video output and menu.

  • Page 18: Chapter 2 Getting Started

    ENVR208 Chapter 2 Getting Started 2.1 Start up the Device Purpose: Proper startup and shutdown procedures are crucial to expanding the life of the device. Before you start: Check that the voltage of the extra power supply is the same with the device’s requirement, and the ground connection is working properly.

  • Page 19: Configure Unlock Pattern For Login

    ENVR208 Figure 2-1 Setting Admin Password We highly recommend you create a strong password of your own choosing (Using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters.) in order to increase the security of your product. And we recommend you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your product.
  • Page 20 ENVR208 Step 1 After the device is activated, you can enter the following interface to configure the device unlock pattern. Step 2 Use the mouse to draw a pattern among the 9 dots on the screen. Release the mouse when the pattern is done.

  • Page 21: Login To The Device

    ENVR208 2.4 Login to the Device 2.4.1 Log in via Unlock Pattern ⚫ Only the admin user has the permission to unlock the device. Step 1 Please configure the pattern first before unlocking. Please refer to Chapter 2.2 Step 2In the IP Camera Activation text field, enter the password to activate the IP camera (s) connected to the device.

  • Page 22: Log In Via Password

    ENVR208 ⚫ If you have forgotten your pattern, you can select the Forgot My Pattern or Switch User option to enter the normal login dialog box. ⚫ When the pattern you draw is different from the pattern you have configured, you should try again.
  • Page 23 ENVR208 The Setup Wizard can walk you through some important settings of the device. If you don’t want to use the Setup Wizard at that moment, click the Exit button. Step 1 Configure the date and time on the Date and Time Setup interface.
  • Page 24 ENVR208 Figure 2-7 HDD Management Step 4 To initialize the HDD, click the Init button. Initialization removes all the data saved in the HDD. Step 5 Click Next. You enter the Camera Setup interface to add the IP cameras. 1) Click Search to search the online IP Camera. Before adding the camera, make sure the IP camera to be added is in active status.
  • Page 25 ENVR208 Figure 2-9 Guarding Vision Access Step 7 Click Next to enter the Change Password interface to create the new admin password if required. Figure 2-10 Change Password You can enter click the to show the characters input. Check the checkbox of New Admin Password.

  • Page 26: Enter Main Menu

    ENVR208 We highly recommend you create a strong password of your own choosing (Using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters.) in order to increase the security of your product. And we recommend you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your product.

  • Page 27: System Operation

    ENVR208 System Maintenance: 2.7 System Operation 2.7.1 Log out Purpose: After logging out, the monitor turns to the live view mode and if you want to perform any operations, you need to enter user name and password log in again.

  • Page 28: Chapter 3 Camera Management

    ENVR208 Chapter 3 Camera Management 3.1 Add the IP Cameras 3.1.1 Add the IP Camera Manually Purpose: Before you can get live video or record the video files, you should add the network cameras to the connection list of the device.

  • Page 29: Add The Automatically Searched Online Ip Cameras

    ENVR208 Step 6 (Optional) Click Continue to Add to continue to add other IP cameras. 3.1.2 Add the Automatically Searched Online IP Cameras Step 1 On the Camera Management interface, click the Online Device panel to expand the Online Device interface.

  • Page 30: Add Non-Poe Ip Cameras

    ENVR208 3.2.2 Add Non-PoE IP Cameras You can disable the PoE interface by selecting the manual while the current channel can be used as a normal channel and the parameters can also be edited. Step 1 Go to Camera > Camera > IP Camera.

  • Page 31: Enable The H.265 Stream Access

    ENVR208 ⚫ Short Distance: Short-distance (< 100 meters) network transmission via POE interface. Figure 3-4 PoE Settings ⚫ The PoE ports are enabled with the short distance mode by default. ⚫ The bandwidth of IP camera connected to the PoE via long network cable (100 to 300 meters) cannot exceed 6 MP.

  • Page 32: Upgrade The Ip Camera

    ENVR208 Step 2 Check the checkbox of Enable H.265 (For Initial Access). Step 3 Click OK. 3.4 Upgrade the IP Camera The IP camera can be remotely upgraded through the device. Plug the U-flash drive with the IP camera’s firmware upgrade file to the device.
  • Page 33 ENVR208 Figure 3-5 Protocol Management Step 2 Select the protocol type of transmission and choose the transfer protocols. ⚫ Type: The network camera adopting custom protocol must support getting stream through standard RTSP. ⚫ Path: you have to contact the manufacturer of the network camera to consult the URL (uniform resource locator) for getting main stream and sub-stream.

  • Page 34: Chapter 4 Camera Settings

    ENVR208 Chapter 4 Camera Settings 4.1 Configure OSD Settings Purpose: You can configure the OSD (On-screen Display) settings for the camera, including date/time, camera name, etc. Step 1 Go to Camera >Display. Step 2 Select the camera from the drop-down list.

  • Page 35: Configure Privacy Mask

    ENVR208 4.2 Configure Privacy Mask Purpose: The privacy mask can be used to protect personal privacy by concealing parts of the image from view or recording with a masked area. Step 1 Go to Camera >Privacy Mask. Step 2 Select the camera to set privacy mask.

  • Page 36: Configure The Video Parameters

    ENVR208 4.3 Configure the Video Parameters Purpose: You can customize the image parameters including the brightness, contrast, saturation for the live view and recording effect. Step 1 Go to Camera>Display. Step 2 Select the camera from the drop-down list. Step 3 Adjust the slider or click on the up/down arrow to set the value of the brightness, contrast or saturation.
  • Page 37 ENVR208 ⚫ Exposure: Set the exposure time (1/10000 to 1 sec) of camera. The larger exposure value results in the brighter image. ⚫ Backlight: Set the wide dynamic range (0 to 100) of the camera. When the surrounding illumination and the object have larger difference in brightness, you should set the WDR value.

  • Page 38: Chapter 5 Live View

    ENVR208 Chapter 5 Live View Live view shows you the video image getting from each camera in real time. 5.1 Start Live View Click on the main menu bar to enter the live view. ⚫ You can select a window and double click a camera from the list to play the video from the camera in the selected window.
  • Page 39 ENVR208 ⚫ The connected camera must support the fisheye view. Step 1 In the live view mode, click the to enter the fisheye expansion mode. Step 2 Select the expansion view mode. ⚫ 180° Panorama ( ): Switch the live view image to the 180° panorama view.

  • Page 40: Live View Strategy

    ENVR208 5.1.4 Live View Strategy Step 1 In the live view mode, click to enter the digital zoom operation interface in full screen mode. Step 2 Select the live view strategy to Real-time, Balanced or Fluency. 5.2 Target Detection In live view mode, the target detection function can be used to detect the human motoion/face/vechicle/human body during the last 5 seconds and the following 10 seconds.

  • Page 41: Configure Live View Settings

    ENVR208 5.3 Configure Live View Settings Live View settings can be customized according to different needs. You can configure the output interface, dwell time for screen to be shown, mute or turning on the audio, the screen number for each channel, etc.
  • Page 42 ENVR208 Figure 5-4 Live View Step 2 Select the video output interface, e.g., HDMI/ VGA or channel-zero. Step 3 Select a window division mode from the toolbar. Step 4 Select a division window, and double-click on the camera from the list to set the camera to the window.

  • Page 43: Configure Auto-Switch Of Cameras

    ENVR208 5.5 Configure Auto-Switch of Cameras You can set the auto-switch of cameras to play in different display modes. Step 1 Go to System > Live View > General. Step 2 Set the video output interface, live view mode and dwell time.
  • Page 44 ENVR208 Result: You can view all of the channels in one screen using the CMS or web browser.

  • Page 45: Chapter 6 Ptz Control

    ENVR208 Chapter 6 PTZ Control 6.1 PTZ Control Wizard Before you start Please make sure the connected IP camera supports the PTZ function and is properly connected. Purpose Follow the PTZ control wizard to guide you through the basic PTZ operation.

  • Page 46: Set Ptz Presets, Patrols & Patterns

    ENVR208 Step 2 Click PTZ Parameters Settings to set the PTZ parameters. Figure 6-2 PTZ Parameters Settings Step 3 Edit the parameters of the PTZ camera. All the parameters should be exactly the same as the PTZ camera parameters. Step 4 Click OK to save the settings.

  • Page 47: Call A Preset

    ENVR208 Step 2 Use the directional buttons on the PTZ control panel to wheel the camera to the location where you want to set preset, and the zoom and focus operations can be recorded in the preset as well. Step 3 Click in the lower right corner of live view to set the preset.

  • Page 48: Set A Patrol

    ENVR208 Figure 6-6 Call Preset (2) 6.3.3 Set a Patrol Purpose: Patrols can be set to move the PTZ to different key points and have it stay there for a set duration before moving on to the next key point. The key points are corresponding to the presets.

  • Page 49: Call A Patrol

    ENVR208 Figure 6-9 Key Point Configuration 1) Configure key point parameters. Preset: It determines the order at which the PTZ will follow while cycling through the patrol. Speed: It defines the speed at which the PTZ will move from one key point to the next.

  • Page 50: Set A Pattern

    ENVR208 The PTZ control panel displays on the right of the interface. Step 2 Click Patrol on the PTZ control panel. Figure 6-11 Patrol Configuration Step 3 Select a patrol in the text field. Step 4 Click Call to call it.

  • Page 51: Call A Pattern

    ENVR208 6.3.6 Call a Pattern Purpose: Follow the procedure to move the PTZ camera according to the predefined patterns. Step 1 Click on the quick settings toolbar of the PTZ camera live view. The PTZ control panel displays on the right of the interface.

  • Page 52: Call Linear Scan

    ENVR208 The speed dome starts linear scan from the left limit to the right limit, and you must set the left limit on the left side of the right limit, as well the angle from the left limit to the right limit should be no more than 180º.

  • Page 53: Auxiliary Functions

    ENVR208 Park (Patrol 1): The dome starts moving according to the predefined patrol 1 path after the park time. Park (Preset 1): The dome moves to the predefined preset 1 location after the park time. The park time can only be set via the speed dome configuration interface. The value is 5s by default.
  • Page 54 ENVR208 Table 6-1 Description of Aux Functions Icons Icon Description Light on/off Wiper on/off 3D positioning Center...

  • Page 55: Chapter 7 Storage

    ENVR208 Chapter 7 Storage 7.1 Storage Device Management 7.1.1 Install the HDD Before startup of the device, install and connect the HDD to the device. Refer to the Quick Start Guide for the installation instructions. 7.1.2 Add the Network Disk You can add the allocated NAS or disk of IP SAN to device, and use it as network HDD.
  • Page 56 ENVR208 Step 7 Select the NAS disk from the list shown below, or you can manually enter the directory in the text field of NetHDD Directory. Step 8 Click the OK to complete the adding of the NAS disk. Result: After having successfully added the NAS disk, return to the HDD Information menu.

  • Page 57: Configure Esata For Data Storage

    ENVR208 Figure 7-2 Add IP SAN Disk Result: After having successfully added the IP SAN disk, return to the HDD Information menu. The added NetHDD will be displayed in the list. If the installed HDD or NetHDD is uninitialized, please select it and click the Init button for initialization.
  • Page 58 ENVR208 Step 3 When the eSATA type is selected to Record/Capture, enter the storage device interface. Step 4 Edit the property of the selected eSATA, or initialize it is required. 7.2 Storage Mode 7.2.1 Configure HDD Group Purpose: Multiple HDDs can be managed in groups. Video from specified channels can be recorded onto a particular HDD group through HDD settings.
  • Page 59 ENVR208 Step 4 Select the Group number for the current HDD. Step 5 Click OK. Regroup the cameras for HDD if the HDD group number is changed. Step 6 Go to Storage> Storage Mode. Step 7 Check the checkbox of Group tab.

  • Page 60: Configure Hdd Quota

    ENVR208 7.2.2 Configure HDD Quota Purpose: Each camera can be configured with allocated quota for the storage of recorded files or captured pictures. Step 1 Go to Storage> Storage Mode. Step 2 Check the checkbox of Quota tab. Step 3 Select a camera to set quota.

  • Page 61: Recording Parameters

    ENVR208 When the quota capacity is set to 0, all cameras will use the total capacity of HDD for record and picture capture. Reboot the device to activate the new storage mode settings. 7.3 Recording Parameters 7.3.1 Main Stream The Main Stream refers to the primary stream that affects data recorded to the hard disk drive and will directly determine your recording quality and image size.

  • Page 62: Configure Advanced Recording Settings

    ENVR208 7.3.3 Picture The picture refers to the live picture capture in continuous or event recording type. Picture Quality: set the picture quality to low, medium or high. The higher picture quality results in more storage space requirement. Interval: the interval of capturing live picture.

  • Page 63: Configure Recording Schedule

    ENVR208 Expired Time: The expired time is period for a recorded file to be kept in the HDD. When the deadline is reached, the file will be deleted. If you set the expired time to 0, the file will not be deleted.
  • Page 64 ENVR208 Figure 7-9 Record Schedule Step 6 Repeat the above steps to schedule recording or capture for other days in the week. The all-day continuous recording is configured for the device by factory default. Step 7 (Optional) Copy the schedule settings of the one day to the other days of the week or holiday.

  • Page 65: Configure Continuous Recording

    ENVR208 Step 8 Click Apply to save the settings. To enable Motion, Alarm, M | A (motion or alarm), M & A (motion and alarm) and Event triggered recording and capture, you must configure the motion detection settings, alarm input settings and other events as well.

  • Page 66: Configure Alarm Triggered Recording

    ENVR208 Step 2 Configure the event detection and select the channel (s) to trigger the recording when event occurs. Refer to Chapter 11 Event and Alarm Settings and Chapter 12 VCA Event Alarm for details. Step 3 Go to Camera > Encoding Parameters > Recording Parameters.

  • Page 67: Configure Picture Capture

    ENVR208 Step 5 Go to Storage > Recording Schedule. Step 6 Select the record type to POS Event. Step 7 Set the schedule for the POS event triggered recording. Refer to Chapter 7.4 Configure Recording Schedule for details. 7.10 Configure Picture Capture The picture refers to the live picture capture in continuous or event recording type.

  • Page 68: Configure Holiday Recording And Capture

    ENVR208 7.11 Configure Holiday Recording and Capture Purpose: Follow the steps to configure the record or capture schedule on holiday for that year. You may want to have different plan for recording and capture on holiday. Step 1 Go to System > Holiday Settings.

  • Page 69: Configure Redundant Recording And Capture

    ENVR208 7.12 Configure Redundant Recording and Capture Purpose: Enabling redundant recording and capture, which means saving the record files and captured pictures not only in the R/W HDD but also in the redundant HDD, will effectively enhance the data safety and reliability.
  • Page 70 ENVR208 Figure 7-14 Record Parameters Step 6 Check the checkbox of Redundant Record/Capture. Step 7 Click OK to save settings.

  • Page 71: Chapter 8 Disk Array

    ENVR208 Chapter 8 Disk Array Purpose: Disk array is a data storage virtualization technology that combines multiple physical disk drive components into a single logical unit. An array stores data over multiple HDDs to provide enough redundancy so that data can be recovered if one disk fails. Data is distributed across the drives in one of several ways called "RAID levels", depending on what level of redundancy and performance...

  • Page 72: One-Touch Creation

    ENVR208 Step 3 Click Apply. Step 4 Reboot device to take effect the settings. 8.1.2 One-Touch Creation Purpose: One-touch configuration helps you to quickly create the disk array. By default, the array type created by one-touch configuration is RAID 5.
  • Page 73 ENVR208 Table 8-1 Create Array Step 3 Enter the array name. Step 4 Select RAID Level as RAID 0, RAID 1, RAID 5, RAID 6, or RAID 10 as required. Step 5 Select the physical disks to constitute array. Table 8-2 Required Number of HDD...

  • Page 74: Configure Hot Spare Disk

    ENVR208 8.2 Rebuild Array Purpose: The status of array includes Functional, Degraded and Offline. To ensure the high security and reliability of the data stored in array, you should take immediate and proper maintenance at arrays according their status. ⚫ Functional: No disk loss in the array.

  • Page 75: Manually Rebuild Array

    ENVR208 8.2.3 Manually Rebuild Array Purpose: If no hot spare disks are configured, rebuild the degraded array manually. Before you start: At least one available physical disk should exist for rebuilding the array. Step 1 Go to Storage > RAID Setup > Array.

  • Page 76: Delete Array

    ENVR208 8.3 Delete Array Deleting array will delete all the data saved in it. Step 1 Go to Storage > RAID Setup > Array. Figure 8-8 Array List Step 2 Click of array to delete. Figure 8-9 Attention Step 3 Click Yes on the popup message box.

  • Page 77: Check And Edit Firmware

    ENVR208 8.4 Check and Edit Firmware Purpose: You can view the information of the firmware and set the background task speed on the Firmware interface. Step 1 Go to Storage > RAID Setup > Firmware. Figure 8-10 Firmware Step 2 Optionally, set the Background Task Speed.

  • Page 78: Chapter 9 File Management

    ENVR208 Chapter 9 File Management 9.1 Search and Export All Files 9.1.1 Search Files Purpose Specify detailed conditions to search videos and pictures. Step 1 Go to File Management > All Files. Step 2 Specify detailed conditions, including time, camera, event type, etc.

  • Page 79: Search And Export Human Files

    ENVR208 9.2 Search and Export Human Files 9.2.1 Search Human Files Purpose Specify detailed conditions to search human pictures and videos. Before you start Configure human body detection function for the cameras you want to search and export human pictures and videos.

  • Page 80: Search And Export Vehicle Files

    ENVR208 9.3 Search and Export Vehicle Files 9.3.1 Search Vehicle Files Purpose Specify detailed conditions to search vehicle pictures and videos. Before you start Configure vehicle detection function for the cameras you want to search and export vehicle pictures and videos.

  • Page 81: Search History Operation

    ENVR208 9.4 Search History Operation 9.4.1 Save Search Condition Purpose You can save the search conditions for future reference and quick search. Step 1 Go to File Management > All Files/People Appearance File/Vehicle File. Step 2 Set the search conditions.

  • Page 82: Chapter 10 Playback

    ENVR208 Chapter 10 Playback 10.1 Play Video Files 10.1.1 Instant Playback Instant Playback enables the device to play the recorded video files in last five minutes. If no video is found, it means there is no recording during the last five minutes.

  • Page 83: Play Smart Searched Video

    ENVR208 Figure 10-2 Playback Interface The playing speed of 256X is supported. 10.1.3 Play Smart Searched Video In the smart playback mode, the device can analyze the video containing the motion, line or intrusion detection information, mark it in red color and play the smart searched video.

  • Page 84: Play Custom Searched Files

    ENVR208 Figure 10-3 Playback by Smart Search Step 5 Set the rules and areas for smart search of line crossing detection, intrusion detection or motion detection event triggered recording. Line Crossing Detection ⚫ Click the icon. Click on the image to specify the start point and end point of the line.

  • Page 85: Play Tag Files

    ENVR208 Figure 10-4 Custom Search Step 5 Click Search. Figure 10-5 Custom Searched Video Files Step 6 On the search results interface, select a file and click to start playing the video. 10.1.5 Play Tag Files Purpose: Video tag allows you to record related information like people and location of a certain time point during playback.
  • Page 86 ENVR208 Step 2 Search and play back the video file(s). Step 3 Click to add the tag. Step 4 Edit the tag information. Step 5 Click OK. Max. 64 tags can be added to a single video file. Edit Tag Files Step 1 Go to Playback.

  • Page 87: Play Event Files

    ENVR208 Figure 10-7 Tag Search Step 4 Click Search. Figure 10-8 Searched Tag Files Step 5 On the search results interface, select a tag file and click to start playing the video. 10.1.6 Play Event Files Purpose Play back video files on one or several channels searched by event type (e.g., alarm input, motion detection, line crossing detection, face detection, vehicle detection, etc.).
  • Page 88 ENVR208 Step 4 Click Search. Step 5 On the search results interface, select an event video file/picture file and double click to start playing the video. Figure 10-9 Event Files You can click button to play 30s backward or forward.

  • Page 89: Play By Sub-Periods

    ENVR208 Event and Alarm Settings and Chapter 12 VCA Event Alarm for details for event and alarm settings. ⚫ Refer to Chapter 7.7 Configure Event Triggered Recording for the event triggered recording/capture settings. 10.1.7 Play by Sub-periods Purpose: The video files can be played in multiple sub-periods simultaneously on the screens.

  • Page 90: Play External File

    ENVR208 Figure 10-10 System Log Search Interface Step 4 Choose a log with video file and click to start playing the log file. 10.1.9 Play External File Purpose: You can play files from the external storage devices. Before You Start: Connect the storage device with the video files to your device.

  • Page 91: Edit Video Clips

    ENVR208 In the Smart/Custom video playback mode, click to set the play strategy. ⚫ When Do not Play Normal Videos is checked, the device will skip the normal video and play the smart (motion/line crossing/intrusion) video and the custom (searched video) only in the normal speed (X1).

  • Page 92: Thumbnails View

    ENVR208 The encoding parameters for the main stream and sub-stream can be configured in Storage > Encoding Parameters. 10.2.4 Thumbnails View With the thumbnails view on the playback interface, you can conveniently locate the required video files on the time bar.

  • Page 93: Fast View

    ENVR208 10.2.6 Fast View You can hold the mouse to drag on the time bar to get the fast view of the video files. In the video playback mode, use the mouse to hold and drag through the playing time bar to fast view the video files.

  • Page 94: Chapter 11 Event And Alarm Settings

    ENVR208 Chapter 11 Event and Alarm Settings 11.1 Configure Arming Schedule Step 1 Select the Arming Schedule tab. Step 2 Choose one day of a week and set the time segment. Up to eight time periods can be set within each day.

  • Page 95: Audible Warning

    ENVR208 Figure 11-2 Set Linkage Actions Step 2 Select the normal linkage actions, trigger alarm output or trigger recording channel. ⚫ Full Screen Monitoring When an alarm is triggered, the local monitor displays in full screen the video image from the alarming channel configured for full screen monitoring.

  • Page 96: Configure Motion Detection Alarm

    ENVR208 It will send an exception or alarm signal to the remote alarm host when an event occurs. The alarm host refers to the PC installed with Remote Client. The alarm signal will be transmitted automatically at detection mode when remote alarm host is configured.
  • Page 97 ENVR208 Figure 11-3 Set Motion Detection Step 2 Select the camera to configure the motion detection. Step 3 Check Enable. Step 4 Set the motion detection area. ⚫ Full screen: click to set the full-screen motion detection for the image.

  • Page 98: Configure Video Loss Alarm

    ENVR208 11.4 Configure Video Loss Alarm Purpose: The video loss detection enables to detect video loss of a channel and take alarm response action(s). Step 1 Go to System> Event>Normal Event>Video Loss Figure 11-4 Set Video Loss Detection Step 2 Select the camera to configure the video loss detection.

  • Page 99: Configure Video Tampering Alarm

    ENVR208 11.5 Configure Video Tampering Alarm Purpose: The video tampering detection enables to trigger alarm when the camera lens is covered and take alarm response action(s). Step 1 Go to System> Event>Normal Event>Video Tampering. Step 2 Select the camera to configure the video tampering detection.

  • Page 100: Configure Sensor Alarms

    ENVR208 11.6 Configure Sensor Alarms Purpose: Set the handling action of an external sensor alarm. 11.6.1 Configure Alarm Input Step 1 Go to System> Event>Normal Event>Alarm Input Step 2 Select an alarm input item from the list and click Figure 11-6 Alarm Input Step 3 Select the alarm input type to N.C or N.O.

  • Page 101: Configure Alarm Output

    ENVR208 Step 1 Go to System> Event>Normal Event>Alarm Input Step 2 Select the alarm input1 item from the list and click Step 3 Select the alarm input type to N.C or N.O. Step 4 Edit the alarm name. Step 5 Check the radio button of Enable One-Key Disarming.
  • Page 102 ENVR208 Step 3 Edit the alarm name. Step 4 Select the dwell time (the alarm duration) from 5s to 600s, or Manually Clear. Manually Clear: you should manually clear the alarm when the alarm occurs. Refer to Chapter 11.8 Trigger or Clear Alarm Output Manually for detailed instructions.

  • Page 103: Configure Exceptions Alarm

    ENVR208 11.7 Configure Exceptions Alarm The exception events can be configured to take the event hint in the live view window, trigger alarm output and linkage actions. Step 1 Go to System> Event>Normal Event>Exception. Step 2 (Optional) Enable the event hint if you want to display the event hint in the live view window.
  • Page 104 ENVR208 Figure 11-10 Exceptions Handling Step 1 Set the normal linkage and alarm output triggering. Refer to Error! Reference source not found.Error! Reference source not found..

  • Page 105: Configure Auto-Switch Full Screen Monitoring

    ENVR208 Step 2 Setting Alarm Linkage Actions Purpose: Alarm linkage actions will be activated when an alarm or exception occurs, including Event Hint Display, Full Screen Monitoring, Audible Warning (buzzer), Notify Surveillance Center, Trigger Alarm Output and Send Email. 11.7.2 Configure Auto-switch Full Screen Monitoring When an alarm is triggered, the local monitor displays in full screen the video image from the alarming channel configured for full screen monitoring.

  • Page 106: Configure Email Linkage

    ENVR208 Step 2 Set the alarm host IP and alarm host port. Step 3 Go to the Linkage Action interface of the alarm detection (e.g., motion detection, video tampering, face detection, etc.). Step 4 Select the Notify Surveillance Center. 11.7.5 Configure Email Linkage The system can send an email with alarm information to a user or users when an alarm is detected.

  • Page 107: Trigger Or Clear Alarm Output Manually

    ENVR208 Step 2 Select the PTZ Linkage. Step 3 Select the camera to perform the PTZ actions. Step 4 Select the preset/patrol/pattern No. to call when the alarm events occur. Figure 11-11 PTZ Linkage You can set one PTZ type only for the linkage action each time.
  • Page 108 ENVR208 Figure 11-12 Alarm Output...

  • Page 109: Chapter 12 Vca Event Alarm

    ENVR208 Chapter 12 VCA Event Alarm The device supports receiving the VCA detections sent by connected IP cameras. Enable and configure the VCA detection on the IP camera settings interface first. ⚫ VCA detections must be supported by the connected IP camera.

  • Page 110: Vehicle Detection

    ENVR208 Step 4 Check Enable Face Detection. Step 5 Optionally, check Save VCA Picture to save the captured pictures of face detection. Step 6 Drag the Sensitivity slider to set the detection sensitivity. Sensitivity range: [1-5]. The higher the value is, the more easily the face can be detected.

  • Page 111: Line Crossing Detection

    ENVR208 Step 5 Optionally, check Save VCA Picture to save the captured pictures of vehicle detection. Step 6 Set the arming schedule. Refer to Chapter 11.1 Configure Arming Schedule. Step 7 Set the linkage actions. Refer to Chapter 11.2 Configure Alarm Linkage Actions.

  • Page 112: Intrusion Detection

    ENVR208 Step 4 Check Enable Line Crossing Detection checkbox. Step 5 Optionally, check Save VCA Picture to save the captured pictures of line crossing detection. Step 6 Follow the steps to set the line crossing detection rules and detection areas.
  • Page 113 ENVR208 Figure 12-4 Intrusion Detection Step 3 Select a Camera to configure. Step 4 Check Enable Intrusion Detection. Step 5 Optionally, check Save VCA Picture to save the captured pictures of intrusion detection. Step 6 Follow the steps to set the detection rules and detection areas.

  • Page 114: Region Entrance Detection

    ENVR208 12.5 Region Entrance Detection Purpose: Region entrance detection function detects objects that enter a pre-defined virtual region from the outside place. Step 1 Go to System Management > Event Settings > Smart Event. Step 2 Click the Region Entrance Detection item.

  • Page 115: Region Exiting Detection

    ENVR208 Step 8 Click Apply. 12.6 Region Exiting Detection Purpose: Region exiting detection function detects objects that exit from a pre-defined virtual region. Step 1 Go to System > Event > Smart Event. Step 2 Click Region Exiting. Figure 12-6 Region Exiting Detection Step 3 Select a Camera to configure.

  • Page 116: Unattended Baggage Detection

    ENVR208 Step 8 Set the linkage actions. Refer to Chapter 11.2 Configure Alarm Linkage Actions. Step 9 Click Apply. 12.7 Unattended Baggage Detection Purpose: Unattended baggage detection function detects the objects left over in the pre-defined region such as the baggage, purse, dangerous materials, etc., and a series of actions can be taken when the alarm is triggered.

  • Page 117: Object Removal Detection

    ENVR208 Sensitivity: Similarity degree of the background image. The higher the value is, the more easily the detection alarm can be triggered. Click Draw Region and draw a quadrilateral in the preview window by specifying four vertexes of the detection region.

  • Page 118: Audio Exception Detection

    ENVR208 Step 6 Follow the steps to set the detection rules and detection areas. Select an Arming Region to configure. Up to 4 regions are selectable. 2) Drag the sliders to set Time Threshold and Sensitivity. Time Threshold: The time of the objects removed from the region. If the value is 10, alarm is triggered after the object disappeared from the region for 10s.

  • Page 119: Sudden Scene Change Detection

    ENVR208 1) Select the Exception Detection tab. 2) Check the checkboxes of Audio Loss Exception, Sudden Increase of Sound Intensity Detection, or Sudden Decrease of Sound Intensity Detection. Audio Loss Exception: Detects the sound steep rise in the surveillance scene. You can set the detection sensitivity and threshold for sound steep rise.

  • Page 120: Defocus Detection

    ENVR208 Figure 12-10 Sudden Scene Change Step 3 Select a Camera to configure. Step 4 Check Enable Sudden Scene Change Detection. Step 5 Optionally, check Save VCA Picture to save the captured pictures of sudden scene change detection. Step 6 Drag the Sensitivity slider to set the detection sensitivity. Sensitivity range: [1-100]. The higher the value is, the more easily the change of scene can trigger the alarm.

  • Page 121: Pir Alarm

    ENVR208 Figure 12-11 Defocus Detection Step 3 Select a Camera to configure. Step 4 Check Enable Defocus Detection. Step 5 Optionally, check Save VCA Picture to save the captured pictures of defocus detection. Step 6 Drag the Sensitivity slider to set the detection sensitivity. Sensitivity range: [1-100]. The higher the value is, the more easily the defocus image can be detected.
  • Page 122 ENVR208 Figure 12-12 FIR Alarm Step 3 Select a Camera to configure. Step 4 Check PIR Alarm. Step 5 Optionally, check Save VCA Picture to save the captured pictures of PIR alarm. Step 6 Set the arming schedule. Refer to Chapter 11.1 Configure Arming Schedule.

  • Page 123: Chapter 13 Smart Analysis

    ENVR208 Chapter 13 Smart Analysis With the configured VCA detection, the device supports the smart analysis for people counting and heat map. 13.1 People Counting Purpose: The Counting is used to calculate the number of people entered or left a certain configured area and form in daily/weekly/monthly/annual reports for analysis.
  • Page 124 ENVR208 Step 2 Select a camera. Step 3 Select the report type as Daily Report, Weekly Report, Monthly Report, or Annual Report. Step 4 Set the Data to analyze. Figure 13-2 Heat Map Interface Step 5 Click Counting. Then the results displayed in graphics marked in different colors will show.

  • Page 125: Chapter 14 Pos Configuration

    ENVR208 Chapter 14 POS Configuration The device can be connected with the POS machine/server, and receive the transaction message for overlay on the image during the live view or playback, as well as trigger the POS event alarm. The POS feature is supported by DS-9600/7700/7600-I (/P) series device only.
  • Page 126 ENVR208 Figure 14-2 Universal Protocol Settings ⚫ EPSON The fixed start and end line tag are used for EPSON protocol. ⚫ AVE The fixed start and end line tag are used for AVE protocol. And the serial port and virtual serial port connection types are supported.
  • Page 127 ENVR208 Click the Custom to configure the NUCLEUS settings. Enter the employee No. shift No. and the terminal No. in the field. The matching message sent from the POS device will be used as the valid POS data. The NUCLEUS protocol must be used in the RS-232 connection communication.
  • Page 128 ENVR208 Figure 14-5 USB-to-RS-232 Settings ⚫ RS-232 Connection Connect the device and the POS machine via RS-232. The RS-232 settings can be configured in Menu>Configuration>RS-232. The Usage must be set to Transparent Channel. ⚫ Multicast Connection When connecting the device and the POS machine via Multicast protocol, set the multicast address and port.
  • Page 129 ENVR208 Figure 14-6 Sniff Settings 14.1.2 Configure POS Tex Overlay Step 1 Go to System > POS. Step 2 Click Channel Linkage and Display tab. Step 3 Select the linked channel to overlay the POS characters. Step 4 Set the characters overlay for the enabled POS.

  • Page 130: Configure Pos Alarm

    ENVR208 Figure 14-7 Overlay Character Settings You can adjust the size and position of textbox on the preview screen of POS settings interface by dragging the frame. Step 7 Click Apply to activate the settings. 14.2 Configure POS Alarm Purpose: The POS event can trigger channels to start recording, or trigger full screen monitoring, audio warning, notifying the surveillance center, sending email and so on.
  • Page 131 ENVR208 Figure 14-8 Set Trigger Cameras of POS Step 8 Click Apply.

  • Page 132: Chapter 15 Network Settings

    ENVR208 Chapter 15 Network Settings 15.1 Configure TCP/IP Settings Purpose TCP/IP settings must be properly configured before you can operate the device over network. 15.1.1 Device with Dual Network Interface Step 1 Go to System > Network > TCP/IP. Figure 15-1 TCP/IP Settings Step 2 Select Net-Fault Tolerance or Multi-Address Mode under Working Mode.

  • Page 133: Device With A Single Network Interface

    ENVR208 ⚫ Check Enable DHCP to obtain IP settings automatically if a DHCP server is available in the network. ⚫ Valid range of MTU value is 500 to 9676. Step 4 Click Apply. 15.1.2 Device with a Single Network Interface Step 1 Go to System >...

  • Page 134: Configure Ddns

    ENVR208 15.2 Configure Guarding Vision Purpose Guarding vision provides mobile phone application as well as service platform to access and manage your connected devices with remote access to the surveillance system. Step 1 Go to System > Network > Advanced > Platform Access.

  • Page 135: Configure Pppoe

    ENVR208 You can set Dynamic DNS service for network access. Different DDNS modes are available: DynDNS, PeanutHull, and NO-IP. Before You Start You must register DynDNS, PeanutHull and NO-IP services with your ISP before configuring DDNS settings. Step 1 Go to System > Network > TCP/IP > DDNS.

  • Page 136: Configure Ntp

    ENVR208 Contact your Internet service provider for details about PPPoE service. 15.5 Configure NTP Purpose Connection to a network time protocol (NTP) server can be configured on your device to ensure the accuracy of system date and time. Step 1 Go to System > Network > TCP/IP > NTP.

  • Page 137: Configure Email

    ENVR208 Before You Start Download the SNMP software to receive device information via SNMP port. By setting the trap address and port, the device is allowed to send alarm event and exception message to the surveillance center. Step 1 Go to System > Network > Advanced > SNMP.
  • Page 138 ENVR208 The system can be configured to send an Email notification to all designated users when a specified event occur, such as an alarm or motion event is detected, or the administrator password is changed, etc. Before You Start The device must be connected to a local area network (LAN) that contains an SMTP mail server.

  • Page 139: Configure Ports

    ENVR208 ⚫ Enable Attached Picture: Check to enable the function if you want to send email with attached alarm images. The interval is the time between two adjacent alarm images. Step 3 Click Apply. Step 4 (Optional) Click Test to send a test email.
  • Page 140 ENVR208 Figure 15-8 Port Settings...

  • Page 141: Chapter 16 Hot Spare Device Backup

    ENVR208 Chapter 16 Hot Spare Device Backup Purpose: The device can form an N+1 hot spare system. The system consists of several working devices and a hot spare device; when the working device fails, the hot spare device switches into operation, thus increasing the reliability of the system.

  • Page 142: Set Working Device

    ENVR208 ⚫ The camera connection will be disabled when the device works in the hot spare mode. ⚫ It is highly recommended to restore the defaults of the device after switching the working mode of the hot spare device to normal mode to ensure the normal operation afterwards.
  • Page 143 ENVR208 Table 16-1 Working Status Descrption Working Status Description No record The working device works properly. The working device gets offline, the hot spare device will record the video Backing up of the IP camera connected to the working device for backup The record backing up can be functioned for 1 working device at a time.

  • Page 144: Chapter 17 System Maintenance

    ENVR208 Chapter 17 System Maintenance 17.1 Storage Device Maintenance 17.1.1 Configure Disk Clone Purpose: Select the HDDs to clone to eSATA HDD. Before you start: Connect an eSATA disk to the device. Step 1 Go to Maintenance > HDD Operation > HDD Clone.
  • Page 145 ENVR208 Figure 17-2 Message Box 17.1.2 S.M.A.R.T Detection Purpose: The device provides the HDD detection function such as the adopting of the S.M.A.R.T. and the Bad Sector Detection technique. The S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) is a monitoring system for HDD to detect and report on various indicators of reliability in the hopes of anticipating failures.

  • Page 146: Bad Sector Detection

    ENVR208 Figure 17-3 S.M.A.R.T Settings Interface If you want to use the HDD even when the S.M.A.R.T. checking is failed, you can check the checkbox of the Continue to use the disk when self-evaluation is failed item. 17.1.3 Bad Sector Detection Step 1 Go to Maintenance >...

  • Page 147: Hdd Health Detection

    ENVR208 Figure 17-4 Bad Sector Detection ⚫ You can also pause/resume or cancel the detection. ⚫ After testing completed, you can click Error information button to see the detailed damage information. 17.1.4 HDD Health Detection Purpose: You can view the health status of Seagate HDD that generated after October 1th, 2017 and capacity ranges from 4 TB to 8 TB.

  • Page 148: Search & Export Log Files

    ENVR208 Figure 17-5 Health Detection Step 2 Click a HDD to view details. 17.2 Search & Export Log Files Purpose: The operation, alarm, exception and information of the device can be stored in log files, which can be viewed and exported at any time.

  • Page 149: Export The Log Files

    ENVR208 Figure 17-6 Log Search Results Up to 2000 log files can be displayed each time. Related Operation: ⚫ Click the button or double click it to view its detailed information. ⚫ Click the button to view the related video file.

  • Page 150: Import/Export Ip Camera Configuration Files

    ENVR208 Figure 17-7 Export Log Files Step 3 On the Export interface, select the storage device from the dropdown list of Device Name. Step 4 Select the format of the log files to be exported. Up to 15 formats are selectable.
  • Page 151 ENVR208 Step 3 Export or import the IP camera configuration files. ⚫ Click Export to export configuration files to the selected local backup device. ⚫ To import a configuration file, select the file from the selected backup device and click the Import button.

  • Page 152: Import/Export Device Configuration Files

    ENVR208 17.4 Import/Export Device Configuration Files Purpose: The configuration files of the device can be exported to local device for backup; and the configuration files of one device can be imported to multiple devices if they are to be configured with the same parameters.

  • Page 153: Upgrade System

    ENVR208 17.5 Upgrade System Purpose: The firmware on your device can be upgraded by local backup device or remote FTP server. 17.5.1 Upgrade by Local Backup Device Before You Start: Connect your device with a local storage device with update firmware file.
  • Page 154 ENVR208 Figure 17-10 FTP Upgrade Interface Step 3 Enter the FTP Server Address in the text field. Step 4 Click the Upgrade button to start upgrading. Step 5 After the upgrading is complete, reboot the device to activate the new firmware.

  • Page 155: Restore Default Settings

    ENVR208 17.6 Restore Default Settings Step 1 Go to Maintenance > Default. Figure 17-11 Restore Defaults Step 2 Select the restoring type from the following three options. Restore Defaults: Restore all parameters, except the network (including IP address, subnet mask, gateway, MTU, NIC working mode, default route, server port, etc.) and user account parameters, to the factory default settings.

  • Page 156: Chapter 18 General System Settings

    ENVR208 Chapter 18 General System Settings 18.1 Configure General Settings Purpose: You can configure the BNC output standard, VGA output resolution, mouse pointer speed through the System > General interface. Go to System > General. Step 1 Figure 18-1 General Settings Interface Step 2 Configure the following settings.

  • Page 157: Configure Date & Time

    ENVR208 Mouse Pointer Speed: Set the speed of mouse pointer; 4 levels are configurable. Enable Wizard: Enable/disable the Wizard when the device starts up. Enable Password: Enable/disable the use of the login password. Step 3 Click the Apply button to save the settings.

  • Page 158: Configure Dst Settings

    ENVR208 18.3 Configure DST Settings The DST (daylight saving time) refers to the period of the year when clocks are moved one period ahead. In some areas worldwide, this has the effect of creating more sunlit hours in the evening during months when the weather is the warmest.
  • Page 159 ENVR208 Figure 18-4 User Management Interface Step 2 Click Add to enter the operation permission interface. Step 3 Enter the admin password and click OK. Step 4 In the Add User interface, enter the information for new user, including User Name, Password, Confirm (password), User Level (Operator/Guest) and User’s MAC Address.

  • Page 160: Set The Permission For A User

    ENVR208 Operator: The Operator user level has permission of Two-way Audio in Remote Configuration and all operating permission in Camera Configuration by default. Guest: The Guest user has no permission of Two-way Audio in Remote Configuration and only has the local/remote playback in the Camera Configuration by default.
  • Page 161 ENVR208 Figure 18-7 User Permission Settings Interface Step 3 Set the operating permission of Local Configuration, Remote Configuration and Camera Configuration for the user. ⚫ Local Configuration Local Log Search: Searching and viewing logs and system information of device. Local Parameters Settings: Configuring parameters, restoring factory default parameters and importing/exporting configuration files.

  • Page 162: Set Local Live View Permission For Non-Admin Users

    ENVR208 Remote Alarm Control: Remotely arming (notify alarm and exception message to the remote client) and controlling the alarm output. Remote Advanced Operation: Remotely operating HDD management (initializing HDD, setting HDD property), upgrading system firmware, clearing I/O alarm output. Remote Shutdown/Reboot: Remotely shutting down or rebooting the device.

  • Page 163: Edit The Admin User

    ENVR208 Figure 18-8 Enable Live View Permission Step 5 Click of non-admin user. Step 6 Enter Camera Configuration tab. Step 7 Select Camera Permission as Local Live View. Step 8 Select cameras to live view. Step 9 Click OK. 18.4.4 Edit the Admin User For the admin user account, you can modify its password the unlock pattern.
  • Page 164 ENVR208 Figure 18-9 Edit User (Admin) Step 3 Edit the admin user information as demand, including the new admin password (strong password is required), and MAC address. Step 4 Edit the unlock pattern for the admin user account. 1) Check the checkbox of Enable Unlock Pattern to enable the use of unlock pattern when logging in to the device.

  • Page 165: Edit The Operator/Guest User

    ENVR208 ⚫ After the device is activated, you should properly keep the password. ⚫ When you have enabled the Export GUID, continue to export the GUID file to the USB flash driver for the future password resetting. ⚫ You can duplicate the password to the IP cameras that are connected with default protocol.

  • Page 166: Delete A User

    ENVR208 Step 2 Select a user from the list and click Modify. Figure 18-11 Edit User (Operator/Guest) Step 3 Edit the user information as demand, including the new password (strong password is required), and MAC address. 18.4.6 Delete a User The admin user account has the permission to delete the operator/guest user account.

  • Page 167: Chapter 19 Appendix

    ENVR208 Chapter 19 Appendix 19.1 Specifications...
  • Page 168 ENVR208 DS-7608NI- DS-7616NI- DS-7632NI- Model K2/8P K2/16P K2/16P IP video input 8-ch 16-ch 32-ch Video/ Incoming 80 Mbps 160 Mbps 256 Mbps bandwidth Audio input Outgoing 160 Mbps bandwidth 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × HDMI output 1080/60Hz, 1600 ×...
  • Page 169 ENVR208 8, RJ-45 10/100 Mbps self- 16, RJ-45 10/100 Mbps self- Interface adaptive adaptive Ethernet interface Ethernet interface Interface Power ≤ 120 W ≤ 200 W Supported IEEE 802.3 af/at standard Power supply 100 to 240 VAC Power ≤ 180 W ≤...
  • Page 170 ENVR208 19.2 Glossary • Dual Stream: Dual stream is a technology used to record high resolution video locally while transmitting a lower resolution stream over the network. The two streams are generated by the device, with the main stream having a maximum resolution of 4CIF and the sub-stream having a maximum resolution of CIF.

  • Page 171: Troubleshooting

    ENVR208 19.3 Troubleshooting ⚫ No image displayed on the monitor after starting up normally. Possible Reasons: − No VGA or HDMI connections. − Connection cable is damaged. − Input mode of the monitor is incorrect. Step 1 Verify the device is connected with the monitor via HDMI or VGA cable.
  • Page 172 ENVR208 3) Go to Menu>Storage>Storage Device. 4) If the status of the HDD is “Uninitialized”, please check the checkbox of corresponding HDD and click the “Init” button. Step 11 Verify the HDD is detected or is in good condition. 5) Select Menu>Storage>Storage Device.
  • Page 173 ENVR208 If not, please contact the engineer from our company to do the further process.  The IP camera frequently goes online and offline and the status of it displays as “Disconnected”. Possible Reasons: amera and the device versions are not compatible.
  • Page 174 ENVR208 And then you connect the device with the monitor via VGA or HDMI interface and reboot the device, there is black screen with the mouse cursor. Connect the device with the monitor before startup via VGA or HDMI interface, and manage the IP camera to connect with the device locally or remotely, the status of IP camera displays as Connect.
  • Page 175 ENVR208 Go to Menu>Camera>Encoding Parameters, and set the Frame rate to Full Frame. Step 27 Check if the fault is solved by the above steps. If it is solved, finish the process. If not, please contact the engineer from our company to do the further process.
  • Page 176 ENVR208 Figure 19-1 Windows task management interface ⚫ Select the “Performance” tab; check the status of the CPU and Memory. ⚫ If the resource is not enough, please end some unnecessary processes. Step 31 Check if the fault is solved by the above steps.
  • Page 177 ENVR208 The device supports G722.1 and G711 standards, and if the encoding parameter of the input audio is not one of the previous two standards, you can log in the IP camera to configure it to the supported standard. Step 35 Check if the fault is solved by the above steps.
  • Page 178 ENVR208 If not, please contact the engineer from our company to do the further process. ⚫ No record file found in the device local HDD, and prompt “No record file found”. Possible Reasons: − The time setting of system is incorrect.

  • Page 179: Summary Of Changes

    ENVR208 19.4 Summary of Changes Version 4.1.10 ⚫ Optimize the GUI information design. Version 4.1.0 ⚫ Complete new GUI information design for more fluent and visual user experience. ⚫ Important files management and playback. ⚫ HDD health monitoring for Seagate HDD.
  • Page 180 ENVR208 ⚫ Add the new models of DS-8600NI-I8. ⚫ DS-7600/7700/8600/9600-I (/P) series device is accessible by the thermal network camera, and supports the advanced search for fire/ship/temperature/temperature difference detection triggered alarm and the recorded video files and pictures. ⚫ DS-7600/7700/8600/9600-I (/P) series device supports the playback by main stream or sub stream.
  • Page 181 ENVR208 ⚫ Update the digital zoom operation in image. Version 3.3.9 Updated: ⚫ Support H.265 video encoding format. Deleted: ⚫ Delete the PPPoE settings. Version 3.3.7 Added: ⚫ Add the new models of DS-8600NI-K8, DS-7700NI-K4(/P) and DS-7600NI-K2(/P). ⚫ Add the front panel and rear panel of the new models.

  • Page 182: List Of Compatible Ip Cameras

    ENVR208 19.5 List of Compatible IP Cameras ⚫ For the list, our company holds right to interpret. ⚫ ONVIF compatibility refers to the camera can be supported both when it uses the ONVIF protocol and its private protocols. Only ONVIF is supported refers to the camera can only be supported when it uses the ONVIF protocol.
  • Page 183 ENVR208 IP Camera Max. Manufacturer Model Version Sub-stream Audio Resolution or Protocol ACM3401-09L-X-00227 A1D-220-V3.13.16-AC 1208*1024 × × TCM4301-10D-X-00083 A1D-310-V4.12.09-AC ACTi 1208*1024 × √ TCM5311-11D-X-00023 A1D-310-V4.12.09-AC 1208*960 × √ AV1305 M 65175 1208*1024 √ × AV2815 65220 1920*1080 √ × Arecont...
  • Page 184 ENVR208 1920*1080 VB-H410(ONVIF Ver.+1.0.0 × √ compatibility) (1280*960) VB-S9000F Ver. 1.0.0 1920*1080 × × VB-S300D Ver. 1.0.0 1920*1080 × × Canon VB-H6100D Ver. 1.0.0 1920*1080 × × VB-H7100F Ver. 1.0.0 1920*1080 × √ VB-S8000 Ver. 1.0.0 1920*1080 × × SP306H Application:1.34...
  • Page 185 ENVR208 (ONVIF compatibility) IP8332 0105b 1280*800 × × (ONVIF compatibility) D5110 (ONVIF MG.1.6.03P8 1280*1024 √ (×) × compatibility) F3106 (ONVIF M2.1.6.03P8 1280*1024 √ (×) √ compatibility) F3110 (ONVIF M2.1.6.01 Zavio 1280*720 √ (×) √ compatibility) F3206 (ONVIF MG.1.6.02c045 1920*1080 √ (×) √...
  • Page 186 ENVR208 DS-2CD4032FWD V5.3.0 build150327 2048*1536 √ √ DS-2CD4065F V5.3.0 build150327 3072*2048 √ √ DS-2CD4124F-I(2.8- V5.3.0 build150327 1920*1080 √ √ 12mm) DS-2CD4132FWD-I(2.8- V5.3.0 build150327 2048*1536 √ √ 12mm) DS-2CD4212F-I(2.8- V5.3.0 build150327 1280*1024 √ × 12mm) DS-2CD4212F-IS(2.8- V5.3.0 build150327 1280*1024 √ √...
  • Page 187 ENVR208 V2.0 build 110614 DS-2CD852MF-E V2.0 build 110426 1600*1200 √ √ V2.0 build 100521 DS-2CD855F-E V5.2.0 build 140721 1920*1080 √ √ V2.0 build 110614 DS-2CD862MF-E V2.0 build 110426 1280*960 √ √ V2.0 build 100521 DS-2CD863PF/NF-E V5.2.0 build 140721 1280*960 √...
  • Page 188 ENVR208 DS-2CD9111(B) V3.7.1 build140417 1360*1024 √ × DS-2CD9151A V3.8.2 build141121 2448*2048 √ × DS-2CD9152-H V3.8.2 build141121 2592*2048 √ × iDS-2CD9282 V3.8.2 build141121 3296*2472 √ × DS-2CD9131-K V4.0.0 build150213 2048*1536 √ √ DS-2CD9152-HK V3.8.2 build141121 2592*2048 √ √ iDS-2CD9131-E V3.8.2 build141121 2048*1536 √...
  • Page 189 ENVR208 DS-6508HCI- SATA V1.0.1 build130607 352*288 √ √ DS-6508HFI V1.0.1 build130607 704*576 √ √ DS-6508HFI- SATA V1.0.1 build130607 704*576 √ √ DS-6516HCI V1.0.1 build130607 352*288 √ √ DS-6516HCI- SATA V1.0.1 build130607 352*288 √ √ DS-6516HFI V1.0.1 build130607 704*576 √ √...
  • Page 190 ENVR208 DS-2DF7276-A/D/AF V5.2.8 build150124 1280*960 √ √ iDS-2DF7276-A/D/AF V5.2.8 build150124 1280*960 √ √ DS-2DF5276- V5.2.8 build150124 1280*960 √ √ A/D/A3/D3/AF/A3F iDS-2DF5276- V5.2.8 build150124 1280*960 √ √ A/D/A3/D3/AF/A3F DS-2DF7274- V5.2.8 build150124 1280*960 √ √ AH/DH/AFH iDS-2DF7274- V5.2.8 build150124 1280*960 √ √...
  • Page 191 ENVR208 iDS-2DF5296- V5.2.8 build150124 2048*1536 √ √ A/D/A3/D3/AF/A3F DS-2DF6223-A V5.2.8 build150124 1920*1080 √ √ iDS-2DF6223-A V5.2.8 build150124 1920*1080 √ √ DS-2DF8223i-A V5.2.8 build150124 1920*1080 √ √ iDS-2DF8223i-A V5.2.8 build150124 1920*1080 √ √ DS-2DF7284-A/D/AF V5.2.8 build150124 1920*1080 √ √ iDS-2DF7284-A/D/AF V5.2.8 build150124 1920*1080 √...
  • Page 192 ENVR208 DS-2DE7174-A/AE/D V5.2.10 build150128 1280*960 √ √ DS-2DE7176-A/AE V5.2.10 build150128 1280*960 √ √ DS-2DE7120i-A/AE V5.2.10 build150128 1280*960 √ √ DS-2DM7130i-A V5.2.10 build150128 1280*960 √ √ DS-2DM4120-A V5.2.10 build150128 1280*960 √ √ DS-2DE5120I-A V5.2.10 build150128 1280*960 √ √ DS-2DM5120-A V5.2.10 build150128 1280*960 √...
  • Page 193 ENVR208 DS-2DE5194-A/A3 V5.2.10 build150128 2048*1536 √ √ DS-2DF1-518 V3.2.0 build131223 704*576 √ √ DS-2DM1-718 V3.2.0 build131223 704*576 √ √ DS-2DM1-518 V3.2.0 build131223 704*576 √ √ DS-2DF1-718 V3.2.0 build131223 704*576 √ √ DS-2DF1-514 V3.2.0 build131223 704*576 √ √ DS-2DF1-714 V3.2.0 build131223 704*576 √...
  • Page 194 ENVR208 DS-2ZMN2007 V5.2.7 build141107 1920*1080 √ √ DS-2ZMN3007 V5.2.7 build141107 1920*1080 √ √ DS-2ZMN3007(B) V5.2.7 build141107 1920*1080 √ √ DS-2ZMN0407 V5.2.7 build141107 1920*1080 √ √ DS-2ZMN3207 V5.2.7 build141107 1920*1080 √ √ DS-2ZMN2008 V5.2.7 build141107 2048*1536 √ √ DS-2ZCN2008 V5.2.7 build141107 2048*1536 √...
  • Page 195 ENVR208 19.6 List of IP Cameras Connected to PoE by Long Network Cable (100 - 300 m) Index Model DS-2CD4665F-IZHS DS-2CD4026FWD-AP DS-2CD4A35FWD-IZHS DS-2CD2642FWD-IZS DS-2CD2F42FWD-IWS DS-2CD2942F-IWS DS-2CD2510F DS-2CD2342WD-I DS-2CD2322WD-I DS-2CD2352-I DS-2CD2642FWD-IZS DS-2CD2642FWD-I DS-2CD2642FWD-IS DS-2CD2642FWD-IZ DS-2CD2742FWD-IZS DS-2CD2742FWD-I DS-2CD2742FWD-IS DS-2CD2742FWD-IZ DS-2CD2T42WD-I8 DS-2CD2T42WD-I5...
  • Page 196 Made in PRC Imported by Velleman Group nv Legen Heirweg 33, 9890 Gavere, Belgium www.velleman.eu...
