Summary of Contents for SHINE SRFP109
- Page 1 39'' ROUND PEDESTAL FIRE PIT MODEL # SRFP109 Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-866-814-0585, 8 a.m. - 5 p.m., EST, Monday - Friday. E-mail : customerservice@shinerichgroup.com...
- Page 2 PACKAGE CONTENTS QUANTITY QUANTITY Screen hook Fire bowl Screen Pedestal Charcoal grid Base...
- Page 3 HARDWARE CONTENTS (shown actual size) D6 Washer M6 Nut Qty. 9 Flange Nut Qty. 6 Qty. 1 Ring Screw Double End Screw Qty. 1 Qty. 3 SAFETY INFORMATION WARNING: TO AVOID INJURY ‡ FOR OUTDOOR USE ONLY ‡ Do not use the fire pit indoors. Lack of ventilation due to carbon monoxide fumes can cause death. ‡...
- Page 4 ASSEMBLY INSTRUCTIONS 1. Detach the fire bowl (D) and base (F) by unscrewing three M6 double end screws (CC). Hardware Used M6 Double End Screw 2. Attach pedestal (E) to base (F) with three M6 nuts (BB), D6 washers (DD)and M6 double end screws (CC) mentioned in step 1.
- Page 5 ASSEMBLY INSTRUCTIONS 3. Attach fire bowl (D) to base assembly with three M6 nuts (BB), six D6 washers (DD). Hardware Used M6 Nut D6 Washer 4. Attach M6 ring screw (EE) to the top of screen (B) with one M6 flange nut (AA). Warning: Always use the screen hook to lift the screen while this fire pit is in use or remains hot.
- Page 6 ASSEMBLY INSTRUCTIONS 5. Place all parts onto the fire pit in the order as shown.
- Page 7 CARE AND MAINTENANCE Inspecting Inspect this fire pit on a regular basis to ensure product safety and longer product life. DO NOT attempt to inspect this outdoor fire pit until the fire is COMPLETELY out and cooled down. ‡ Check handles to make sure they are secure. ‡...
