Summary of Contents for EXTER EXTER T150sr
- Page 1 EXTER T150sr Installation Manual English MAEN966, 2008-11...
- Page 2 EXTER sun-readable provides clear and accurate information even in conditions of bright daylight glare. All operator panels in the EXTER series are developed to satisfy the demands of hu- man-machine communication. Built-in functions such as displaying and controlling text, dynamic indication, time channels, alarm and recipe handling are included.
-
Page 3: Table Of Contents
4.2.2 Touch Screen Surface ..................16 5 Operator Panel Drawings ..............17 5.1 Communication Ports..............17 5.2 EXTER T150 Outline ..............18 6 Additional Installation Tips..............19 6.1 Grounding the Operator Panel ............19 6.2 Ethernet Connection in the Panel ........... 20 6.3 To Achieve Better EMC Protection .......... - Page 4 Table of Contents Beijer Electronics, MAEN966...
-
Page 5: Safety Precautions
Safety Precautions Safety Precautions Both the installer and the owner and/or operator of the operator panel must read and understand this installation manual. 1.1 UL and cUL Installation – This equipment is suitable for use in Class I, Division 2, Groups A, B, C and D OR non-hazardous locations only. -
Page 6: General
Safety Precautions 1.2 General – Read the safety precautions carefully. – Check the delivery for transportation damage. If damage is found, notify the supplier as soon as possible. – Do not use the operator panel in an environment with high explosive hazards. –... -
Page 7: During Use
Safety Precautions 1.4 During Use – Keep the operator panel clean. – Emergency stop and other safety functions may not be controlled from the operator panel. – Do not use too much force or sharp objects when touching the keys, touch screen etc. - Page 8 Safety Precautions Beijer Electronics, MAEN966...
-
Page 9: Installation
Installation Installation 2.1 Space Requirements – Installation plate thickness: 1.5 - 9.0 mm (0.06 - 0.35 inch) – Space requirements when installing the operator panel: 100 mm (4.0 inch) 304 mm (11.97 inch) 100 mm 50 mm 50 mm (4.0 inch) (2.0 inch) (2.0 inch) 100 mm... - Page 10 Installation 3. Secure the operator panel in position, using all the fastening holes and the provided brackets and screws: x 14 0.5 - 1.0 Nm 4. Connect the cables in the specified order. Caution Ensure that the operator panel and the controller system have the same electrical grounding (reference voltage level), otherwise errors in communication may occur.
-
Page 11: Mode Switches
Installation 2.2.1 Mode Switches All mode switches must be in OFF position during operator panel use. The mode switches should not be touched unless by qualified personell. 2.2.2 Connections to the Controller For information about the cables to be used when connecting the operator panel to the controller, please refer to the help file for the driver in question. - Page 12 Installation Beijer Electronics, MAEN966...
-
Page 13: Technical Data
Technical Data Technical Data Parameter EXTER T150sr Front panel, W x H x D 398 x 304 x 6 mm Mounting depth 60 mm (160 mm including clearance) Front panel seal IP 66 Rear panel seal IP 20 Keyboard material/... - Page 14 Technical Data Beijer Electronics, MAEN966...
-
Page 15: Chemical Resistance
Chemical Resistance Chemical Resistance 4.1 Metal Casing The frame and casing material is powder-coated aluminum. This powder paint withstands exposure to the following chemicals without visible change: Acetic acid 10% Phosphoric acid 4% Citric acid 10% Phosphoric acid 10% Diesel Sea water Distilled water Sodium chloride 2%... -
Page 16: Touch Screen And Overlay
Chemical Resistance 4.2 Touch Screen and Overlay 4.2.1 Autotex XE Autotex XE covers the overlay surrounding the touch screen. Autotex XE has been developed to endure high or widely fluctuation temperatures, excessive humidity and strong levels of ultraviolet light. Solvent Resistance With continous contact, some chemicals will begin to remove the UV absorber, reducing its UV resistance. -
Page 17: Operator Panel Drawings
Operator Panel Drawings Operator Panel Drawings 5.1 Communication Ports RS-232 RS-422 RS-485 RS-422/485 Ethernet Drawing No. S-5005, Date 2004-10-27 Beijer Electronics, MAEN966... -
Page 18: Exter T150 Outline
Operator Panel Drawings 5.2 EXTER T150 Outline Drawing No. S-5141, Date 2004-10-26 Beijer Electronics, MAEN966... -
Page 19: Additional Installation Tips
Additional Installation Tips Additional Installation Tips When experiencing communication problems in for example noisy environments or when operating close to temperature limits, the following recommendations are to be noticed. 6.1 Grounding the Operator Panel Door Mounting plate in the cabinet Operator panel Power supply 24 V DC... -
Page 20: Ethernet Connection In The Panel
Additional Installation Tips 6.2 Ethernet Connection in the Panel Industrial Ethernet RJ45 RJ45 RJ45 RJ45 Operator panel RJ45 Operator panel RJ45 Short and Operator panel unshielded Shielded RJ45 Operator panel RJ45 0.1 uF 250 V 5351 1. In some industrial units for Ethernet, the RJ45 contact’s shield is connected to the chassis via a capacitor. -
Page 21: To Achieve Better Emc Protection
Additional Installation Tips 6.3 To Achieve Better EMC Protection – Initially, use the original cabling from Beijer Electronics primarily. – Use shielded cables for RS232 communication. – Use twisted pair and shielded cabling for RS422 and RS485. – Use the cabling intended for the bus type; Ethernet, Profibus, CC-Link, CAN, Device Net etc. -
Page 22: Ambient Temperature
Additional Installation Tips 6.4 Ambient Temperature The maximum ambient temperature for the operator panel is provided in the specifications. The ambient temperature refers to the temperature in the device cabinet which cools the panel’s electronics. ° inside Operator Power panel Power Axial fan 120x120 mm... -
Page 23: Safety
Additional Installation Tips 6.5 Safety Most of the operator panels are fed with 24 V DC. Power supply 230 V AC to 24 V DC Operator panel +24 V Power supply 230 V AC to 24 V DC Operator panel +24 V Distance? Power supply... -
Page 24: Galvanic Isolation
Additional Installation Tips 6.6 Galvanic Isolation Internal electronic Ethernet DC/DC Filter galvanic isolation DC/AC +24 V DC 0 V (GND) 1.5 m RS422/485 RS232 5356 The operator panel has galvanic isolation against the 24 V DC feed but no galvanic isolation between the communication ports for RS232, RS422/485 and USB. -
Page 25: Cable And Bus Termination Rs485
Additional Installation Tips 6.7 Cable and Bus Termination RS485 – Use shielded and twisted pair cable. The pair capacitance may not exceed 52.5 pF/m and area at least 0.25 mm (AWG 24), if you want to use the maximum transfer distance and maximum transfer speed. - Page 26 HEAD OFFICE SUBSIDIARIES SWEDEN GERMANY Beijer Electronics Products AB Elektronik-Systeme Lauer GmbH & Co. KG Beijer Electronics Inc. Box 426 Kelterstraße 59 939 N. Plum Grove Road, Suite F 72669 Unterensingen, GERMANY Schaumburg, IL 601 73, USA SE-201 24 Malmö, Sweden Tel: +46 40 35 86 00 Tel: +49 7022 9660 0 Tel: +1 847 619 6068...
