WEATHERPROOF INFRARED HEATERS SUITABLE FOR OUTDOOR AND
INDOOR USE - RESIDENTIAL (OUTDOOR USE ONLY), COMMERCIAL AND
INDUSTRIAL USE IN NON-HAZARDOUS AREAS
INFORESIGHT CONSUMER PRODUCTS INC.
125 Traders Blvd. E Unit # 4, Mississauga, Ontario L4Z 2H3
Email: info@solairaheaters.com - Website: www.solairaheaters.com
I M P O R TA N T - S AV E T H E S E I N S T R U C T I O N S F O R F U T U R E R E F E R E N C E
Reference Manual
Solaira
Alpha H3
(Triple Emitter - Candel Range)
CANADA & USA MODELS:
C
Tel: 905-568-7655 - Fax: 905-568-7521
(208V - 2250W /
(208V - 3375W /
(208V - 4500W /
= COLOR CODE
247748
240V - 3000W)
240V - 4500W)
240V - 6000W)
Advertisement
Summary of Contents for Solaira Alpha H3 SALPHAH3-30240LL-C
- Page 1 Reference Manual Solaira Alpha H3 (Triple Emitter - Candel Range) CANADA & USA MODELS: SALPHAH3-30240LL-C (208V - 2250W / 240V - 3000W) SALPHAH3-45240LL-C (208V - 3375W / 240V - 4500W) SALPHAH3-60240LL-C (208V - 4500W / 240V - 6000W) = COLOR CODE...
- Page 2 I M P O R TA N T I N S T R U C T I O N S When using electrical INFRARED HEATERS, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1.
- Page 3 I M P O R TA N T I N S T R U C T I O N S 8. Do not insert or allow foreign objects to enter any opening as this may cause an electric shock or fire, or damage the heater. 9.
- Page 4 I N T R O D U C T I O N The Alpha H3 heater produces radiant heat like the sun, warming people and objects rather than the air in between. It is mounted on an adjustable bracket that allows the heat to be directed exactly where it is required.
- Page 6 C O N F I G U R AT I O N S The Alpha H3 heater is a triple emitter - it contains three emitters. It can be installed as a single unit or joined to another single unit. Joining bars are available that connect the heaters together to increase the size and output of the installation.
- Page 7 Always allow the heater to cool before attempting to reposition/move. Never attempt to move the heater while it is switched on! Observe the minimum safe distance between the heater body and inflammable surfaces and objects when Fig. B mounting.
- Page 8 A S S E M B L I N G - 2 × T R I P L E ( 3 × E M I T T E R S ) H E AT E R S J O I N E D Take the first heater and place it face down on a flat surface.
- Page 9 Fix the heater assembly to the chains via the hole in the centre of the joining bar as shown in Fig. E. and ensure the heaters face directly down when hanging. Secure the supply cable so it is not resting on the body or obstructing the air-vents. Always isolate the heater from the mains supply when adjusting the position.
- Page 10 4. At the back of the heater, remove the plate holding the terminal box by removing the two fixing screws as shown in Fig. H. FIXING SCREWS Fig. H Fig. J 5. Pull the emitter wires one at a time through the plate to remove as shown in Fig. J. 6.
- Page 11 8. Release the lamp emitter end by pressing the top edge of the spring clip away from the lamp emitters ceramic end cap. Gently lift the end of the lamp emitter upwards so it is no longer being retained by the clip (Fig. P). The wire can then be gently pulled from behind the reflector.
- Page 12 12. Refit the grilles by taking a grille and inserting the 2 × prongs into the holes in the end of the heater (left side shown below in Fig. S) and gently flex the wire grille to insert the 2 × opposite prongs into the grille holder holes (to the other side of the lamp emitter as shown in Fig.
- Page 13 WA L L M O U N T E D C O N F I G U R AT I O N - AT A G L A N C E 1 × Alpha H2 Unit C H A I N H A N G I N G C O N F I G U R AT I O N S - AT A G L A N C E 1 ×...
- Page 14 Solaira Alpha H3 CANADA & USA MODELS: SALPHAH3-30240LL-C (208V - 2250W / 240V - 3000W) SALPHAH3-45240LL-C (208V - 3375W / 240V - 4500W) SALPHAH3-60240LL-C (208V - 4500W / 240V - 6000W) = COLOR CODE Also available in this range... Solaira Alpha H1...
