Summary of Contents for Mgl Vega AHRS-1
- Page 1 Vega AHRS-1 Vega AHRS-3 Vega MAG-1 AHRS-1: Artificial Horizon and Magnetic Compass indicator AHRS-3: Self Contained Artificial Horizon, Magnetic Compass indicator MAG-1: Magnetic Compass Indicator Operating Manual – English 1.08...
- Page 2 MGL-Avionics SP-6 compass sensor package to display heading. The AHRS-3 is a self contained attitude display with built in sensors. The AHRS-3 does not require the MGL- Avionics SP-7 sensor package in order to display the attitude, but requires the MGL-Avionics SP-6 compass sen- sor package to display heading.
- Page 3 Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 3 2 Layout 2.1 AHRS-1 / AHRS-3 Layout 2 1/4” (57mm) enclosure. Can be front or rear mounted Sunlight readable color graphic display: Backlight can be adjusted in the menu system...
-
Page 4: Main Displays
Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 4 3 Main Displays The AHRS-1/3 can be set up to show 5 different display screens. Turning the rotary control either clockwise or anti-clock- wise allows you to select the operation of the AHRS-1 / AHRS-3 as an artificial horizon with mini compass and turn and bank indicator, a turn and bank indicator, a digital compass, or as a NMEA GPS viewer The MAG-1 only displays the compass and GPS displays. -
Page 5: Digital Compass
Extended range of operation Please see the corresponding MGL sensor documentation for maximum rate specifications. Depending on conditions maximum rates may reach 180 degrees per second. No caging of the electronic gyro system is required during excessive maneuvering, unlike systems based on mechanical gyros. - Page 6 Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 6 3.3.2 Heading bug and the course steering indication To activate the heading bug, press the F1 key when the compass display is showing. Press the F1 key again to use the current heading as the heading bug or use the rotary control to manually enter a heading.
-
Page 7: Gps Viewer
Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 7 3.3.4 Heading stability issues You may find short term fluctuations of the heading occurring. These tend to be very small and are typically less than one degree. This could still cause the heading to fluctuate occasionally by a single degree. These fluctuations occur naturally in the earth’s magnetic field and can also be caused by nearby electrical equipment such as radios, lamps, electronic in -... -
Page 8: Exiting The Menu System
Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 8 4 Menu System Press the rotary control button during the normal display mode to enter the menu system. Use the rotary control to navi- gate through the menu system. 4.1 Exiting the menu system Press the F1/Up button to exit the menu system when the “EXIT”... - Page 9 Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 9 4.2 Horizon Setup Compass: Select “ON” if you would like to see the compass box on the horizon display. Numeric: Select “ON” if you would like to see a numeric display of bank and pitch angles superimposed on the horizon display.
- Page 10 Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 10 Slip Sense: Select if you want the slip to have a high sensitivity or a low sensitivity setting. Slip Zero: This function allows you to set your slip indicator to exactly zero even if your aircraft tends to fly slightly wing down. The procedure is to place the aircraft in a stable, straight and level attitude during calm flight conditions and then select this function.
- Page 11 After you activate this procedure it takes about 30 seconds to complete it. Keep the aircraft perfectly still during this operation. CAN TX AHRS (AHRS-3 only): Select “ON” to output the MGL Avionics SP7 CAN bus messages. This gives the AHRS-3 the ability to emulate the MGL Avionics SP7 sensor package.
-
Page 12: Compass Setup
Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 12 4.3 Compass Setup Display: Select the style of the compass tape as in section display mode as described in section 3.3 above Heading: Select whether you would like the instrument to display magnetic or true heading. If you select true heading, you need to enter the correct magnetic variation for your location. - Page 13 Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 13 Calibrate This allows calibration of the magnetic sensor. In-Flight calibration Procedure Please see documentation supplied with the SP-6 for more information. Fly the aircraft in safe area where you can perform random banked turns. Do not exceed the safety limits of the aircraft during the calibration flight.
-
Page 14: Gps Setup
Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 14 4.4 GPS Setup GPS Display: Select to enable or disable the GPS display. NMEA Baud: Select the baud rate of the externally connected GPS receiver. Position: Select the display format of the GPS latitude and longitude. -
Page 15: Protocol Format
Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 15 4.5 COMM Setup (Communication Setup) Serial Out: Select “ON” to enable the RS232 serial output. Unit Address: Enter the unit address. Baud Rate: Select the desired baud rate of the serial output. - Page 16 Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 16 4.5.2 Data payload Message type=12 Data Length=12 bytes Output Rate=10Hz Bank Angle: Signed Int (16 bits), Bank Angle in 0.1 degrees Pitch angle: Signed Int (16 bits), Pitch Angle in 0.1 degrees Yaw Angle: Signed Int (16 bits), Yaw Angle in 0.1 degrees...
-
Page 17: Security Setup
Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 17 4.6 MISC Setup (Miscellaneous Setup) Backlight: Select this menu option to adjust the backlight brightness. Security Setup: Select this menu option if you want to password protect the menu system. -
Page 18: Default Settings
Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 18 Default Settings: Select this menu option to reset all the settings to factory defaults. Model: This menu option is used to select which model of display you have. Select MAG-1 if you only want a compass display as then all menus pertaining to the AHRS-1 will be hidden. -
Page 19: Loading Factory Default Settings
Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 19 7 Loading factory default settings Press and hold the F1/Up button and rotary control during power up to load the pre- programmed factory default settings. The following screen will be displayed: Factory default settings can also be loaded in the Miscellaneous setup menu. -
Page 20: Specifications
Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 20 9 Specifications Operating Temperature Range -20ºC to 50ºC (-4ºF to 122ºF) Storage Temperature Range -30ºC to 80ºC (-22ºF to 176ºF) 8 to 30Vdc SMPS (switch mode power supply) with built in 33V over volt-... -
Page 21: Firmware Upgrading
Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 21 10 Operating the alarms The alarm output can be used to switch an external alarm indicator. The external alarm switch is an open collector tran - sistor switch to ground with a maximum rating of 0.25A DC. It is possible to wire the alarm contacts of several Stratomas - ter instruments in parallel should this be desired. -
Page 22: Connection Diagram
Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 22 12.2 Connection Diagram The use of an external 1A fuse is recommended. Connect the supply terminals to your aircrafts power supply. Ensure that the supply voltage will not drop below 8V during operation as this may result in incorrect readings. - Page 23 Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 23 13 Dimensions...
-
Page 24: Warranty
IMPORTANT NOTICE: You must make your own determination if the products sold by MGL Avionics are safe and effective for your intended ap- plications. MGL Avionics makes no representations or warranties as to either the suitability of any of the products we sell as to your particular application or the compatibility of any of the products we sell with other products you may buy from us or anywhere else, and we disclaim any warranties or representations that may otherwise arise by law. - Page 25 Vega AHRS-1 / AHRS-3 / MAG-1 Operating Manual Page 25 Other instruments in the Stratomaster Vega series AHRS-1 Artificial Horizon and Magnetic Compass Indicator AHRS-3 Self contained Artificial Horizon and Magnetic Compass Indicator ALT-5 Altimeter and Vertical Speed Indicator (VSI)
