User's Guide
HGW-2501GN-R2
Edition 1, 8/2014

Advertisement

loading

Related Manuals for MitraStar HGW-2501GN-R2

Summary of Contents for MitraStar HGW-2501GN-R2

  • Page 1 User’s Guide HGW-2501GN-R2 Edition 1, 8/2014...
  • Page 2  IMPORTANT!  READ CAREFULLY BEFORE USE.  KEEP THIS GUIDE FOR FUTURE REFERENCE. Graphics in this book may differ slightly from the product due to differences in operating systems, operating system versions, or if you installed updated firmware/software for your device. Every effort has been made to ensure that the information in this manual is accurate.

  • Page 3: Table Of Contents

    Contents Chapter 1: Introducción Overview Hardware Connection LEDs (Lights) Chapter 2: The Installation Wizard Overview Access the Router Changing the Password Tu Router Configuración Básica IPTV Configuration VoIP Configuration Configuración Avanzada The Web Configurator Layout Title Bar Main Window Chapter 3: The Client Wizard Access the Router Configuración Básica Wireless Configuration...
  • Page 4 Chapter 6: WAN The WAN Screen Edit Ethernet Connection Chapter 7: Wireless 2.4GHz Wireless General Screen No Security Basic (WEP Encryption) More Secure (WPA(2)) More Secure (WPA(2)-PSK) More AP Screen Edit More AP MAC Authentication Screen The WPS Screen The WDS Screen The WMM Screen Scheduling Screen Add or Edit Schedule...
  • Page 5 The Queue Setup Screen Edit a QoS Queue The Class Setup Screen Add/Edit QoS Class The QoS Monitor Screen Chapter 12: Network Address Translation (NAT) The General Screen The Port Forwarding Screen The Port Forwarding Screen The Port Forwarding Add/Edit Screen The Address Mapping Screen The Address Mapping Rule Edit Screen The DMZ Screen...
  • Page 6 Edit SIP Account The SIP Service Provider Screen Edit SIP Service Provider Phone Screen Call Rule Screen Chapter 19: System Monitor The Log Screen The WAN Traffic Status Screen The LAN Traffic Status Screen The NAT Traffic Status Screen The VoIP Status Screen Chapter 20: User Account Overview The User Account Screen...
  • Page 7 SSH Screen Chapter 28: Diagnostic The Diagnostic Screen Chapter 29: Troubleshooting Overview Power, Hardware Connections, and LEDs Router Access and Login Internet Access Wireless Internet Access Phone Calls and VoIP UPnP Appendix A: Safety Warnings Contents...

  • Page 8: Chapter 1: Introducción

    Chapter 1 1.1 Overview The HGW-2501GN-R2 combines a router which combines high-speed Internet access, a built-in switch, a firewall and high-speed wireless networking capability. It has one phone port for making calls over the Internet (Voice over IP or VoIP). In addition, it supports IPTV service if it is available from your service provider.

  • Page 9: Hardware Connection

    1.2 Hardware Connection Make sure to use the proper cables and power adapter to connect the Router. Figure 2 The Rear Panel La descripción de los conectores y botones anteriormente visualizados se muestra en la siguiente tabla: Table 1 The Rear Panel CONECTOR DESCRIPTION ON/OFF...

  • Page 10: Leds (Lights)

    1.3 LEDs (Lights) The following graphic displays the labels of the LEDs. Figure 3 Front Panel LEDs Table 2 LED Descriptions COLOR STATUS DESCRIPTION Power Green The Router is receiving power and ready for use. The Router has hardware failure. Blinking The Router detected an error while self-testing.
  • Page 11 Table 2 LED Descriptions (continued) COLOR STATUS DESCRIPTION Internet Green The Router has an IP connection but no traffic. It has a WAN IP address (either static or assigned by a DHCP server), PPP negotiation was successfully completed (if used). Blinking The Router is negotiating a PPP connection.

  • Page 12: Chapter 2: The Installation Wizard

    H A PT ER The Installation Wizard Chapter 2 2.1 Overview The web configurator HTML-based management interface allows easy device setup and management via Internet browser. Use Internet Explorer 6.0 and later versions, Mozilla Firefox 3 and later versions, or Safari 2.0 and later versions. The recommended screen resolution is 1024 by 768 pixels.
  • Page 13 The login screen appears. The default password is 1234. Enter the password. Click Iniciar to enter the Installation Wizard. The main screen appears. Click the buttons in this screen for basic or advanced configurations of the Router. Español / English - change the language. Cambiar contraseña - change the configuration password (see Section 2.3 on page 14).

  • Page 14: Changing The Password

    Consejos - display tips and frequently asked questions. Tu Router - display basic information of the Router (see Section 2.4 on page 15). Configuración Básica - select the services you want to use and configure related settings (see Section 2.5 on page 16).

  • Page 15: Tu Router

    2.4 Tu Router Mouse-over the Tu Router button to show basic information of the Router. You can see the manufacturer company name, model name, current firmware version, and whether the Router is connected to the Internet. Chapter 2 The Installation Wizard...

  • Page 16: Configuración Básica

    2.5 Configuración Básica In the Configuración Básica section of the wizard, you can set the services you want to use on the Router. Make sure the services are provided by your service provider. Click the Configuración Básica button to show the following screen. In the Tipo de Servicio Contratado section, if your service provider provides IPTV service, select TRIO.
  • Page 17 A. If your service provider provides an IP for the set-top box, select Estático. Click Asistente de Instalación to show the following screen. The NAT feature is disabled and you need to enter the router’s LAN IP address in Dirección IP (LOCAL).
  • Page 18 B. If your service provider did not provide an IP for the set-top box, select Dinámico NatPat to enable the NAT feature, so the set-top box obtains its IP address automatically from the service provider. Click Asistente de Instalación to show the following screen. The IPTV (set-top box)’s IP address and subnet mask are already configured.

  • Page 19: Voip Configuration

    2.5.2 VoIP Configuration This screen is available only when If you selected SI from the Tu linea de Voz section in the Configuración Básica screen. You need to enter your SIP account number (provided by your service provider) in the following screen.

  • Page 20: Configuración Avanzada

    If you need to configure other settings such as the the Router’s LAN and wireless features, click on the IP address shown in the following screen to go to the Client Wizard screens. If not, click Salir to finish. 2.6 Configuración Avanzada In the Configuración Avanzada section of the wizard, you can access all of the configuration screens of the Router which can be used for advanced setup.
  • Page 21 The Connection Status screen appears. Click Status to display the System Info screen, where you can view the Router’s interface and system information. Chapter 2 The Installation Wizard...

  • Page 22: The Web Configurator Layout

    2.7 The Web Configurator Layout Click Connection Status > System Info to show the following screen. As illustrated above, the main screen is divided into these parts: • A - title bar • B - main window • C - navigation panel 2.7.1 Title Bar The title bar shows icons in the upper right corner.

  • Page 23: Main Window

    2.7.2 Main Window The main window displays information and configuration fields. It is discussed in the rest of this document. Click Network Map on the System Info screen (a in Figure on page 22) to display the Connection Status screen. See Chapter 5 on page 39 for more information on the System Info and Connection Status screens.

  • Page 24: Chapter 3: The Client Wizard

    H A PT ER The Client Wizard Chapter 3 3.1 Access the Router The Client Wizard helps you to configure basic settings such as the LAN and wireless configurations on the Router. Connect to the Web Configurator to access the Client Wizard screens. Enter the IP address: http://192.168.1.1.

  • Page 25: Configuración Básica

    For items 1, 2, 3, 4, and 6, refer to Chapter 3 on page 25 for more information. 3.2 Configuración Básica In the Configuración Básica section of the wizard, you can configure some basic settings, such as LAN and wireless settings on the Router. Mouse-over the Configuración Básica button to show the basic setting menu.
  • Page 26 Click Wifi in the menu to show the following screen. Configure the wireless settings in this screen. By default, the wireless feature is enabled. If you want to disable it, switch the Estado button to DESACTIVADA. You can change the Router’s SSID in Identificador Red Inalámbrica (SSID) and select Visible if you allow it to be seen by a SSID scan.

  • Page 27: Ipv4 Nat Port Forwarding Configuration

    In the WPS Configuration section, you can enable WPS on the Router to quickly set up a secured wireless network with its clients. You can also configure wireless MAC filter in the Filtrado MAC section to allow or deny clients based on their MAC addresses.

  • Page 28: Ipv6 Firewall Configuration

    If you want to add a single port, select el puerto in the Abrir field and enter the port number and the internal port number. If you want to add a range of port numbers, select los puertos in the Abrir field and enter the external start/end ports, the internal start/end ports.
  • Page 29 In the Puertos menu. Click Puertos IPv6.0. Click Añadir IPv6.0 regla to add a new firewall rule. Select if this rule is for one single port or a range of ports in the Abrir el puerto o Rango de Puertos de origen field. Enter the port number or port range. In the Abrir el puerto o Rango de Puertos de destino field, enter the internal port number if this rule is for one single port.

  • Page 30: Connection Line Configuration

    Select the protocol used for this rule in the protocolo field. Specify the direction of travel of packets in Interfaz de Dirección. Select the interface to which this rule is applied in Interfaz. ALL means this rule applies to all interfaces of the Router.

  • Page 31: Lan Configuration

    Select whether your connection has NAT enabled. If yes, select Multipuesto and enter the account username and password provided by your ISP to connect to the ONT. If not, select Monopuesto. Click Aplicar to save your settings and exit the screen. 3.2.5 LAN Configuration You can configure the Router’s LAN IPv4/IPv6 address, subnet mask, DHCP and DNS server information for the LAN interface.
  • Page 32 In this screen, configure the Router’s LAN IPv4/IPv6 address, subnet mask, DHCP and DNS server information for the LAN interface. In the Configuración DHCP IPv4 section, enter the Router’s IPv4 IP address and subnet mask. The DHCP feature is set to ACTIVADO by default to to assign IP addresses and provide subnet mask, gateway, and DNS server information to LAN devices.

  • Page 33: Profile Configuration

    Enter the first and second DNS server IPv6 address the Router passes to the DHCPv6 clients in the Configuración DNS IPv6 section. Click Aplicar to save your settings and close the screen. 3.2.6 Profile Configuration In this screen, you can save a profile or restore it on the Router. A profile contains the current settings on the Router which helps you to easily restore the settings in case the Router has been set to factory default.

  • Page 34: Firmware Upgrade

    If you want to restore a profile that you have saved previously, choose the file path in Ruta del archivo and click Cargar. The Router will restart shortly after the profile has been uploaded. Wait several minutes for the restart to finish. If you want to restore the Router to its factory default settings, click the Restaurar button.
  • Page 35  Make sure you are using the correct firmware for this device.  Do NOT turn off the Router while firmware upload is in progress! Chapter 25 on page 139 for more information about firmware upgrade on the Router. Chapter 3 The Client Wizard...

  • Page 36: Chapter 4 Quick Start

    H A PT ER Quick Start Chapter 4 4.1 Overview Use the Quick Start screens to configure the Router’s time zone, basic Internet access, and wireless settings. 4.2 Quick Start Setup Click the Quick Start icon in the top right corner of the web configurator to open the quick start wizard screens.
  • Page 37 Enter the login user name and password provided by your ISP. If your ISP has provided a specific IP address and DNS server(s), you need to configure them manually. If not, the IP address will be assigned automatically. Click Next. Turn the wireless LAN on or off.

  • Page 38: Chapter 5: Connection Status And System Info

    H A PT ER Connection Status and System Chapter 5 Info 5.1 The Connection Status Screen Use this screen to view the network connection status of the device and its clients. A warning message appears if there is a connection problem. You can configure how often you want the Router to update this screen in Refresh Interval.

  • Page 39: The System Info Screen

    In List View, you can also view the client’s information. 5.2 The System Info Screen Click Connection Status > System Info to open this screen. You can look at the current status of the Router, system resources, interfaces (LAN, WAN and WLAN), and SIP accounts. You can also register and unregister SIP accounts.

  • Page 40: Chapter 6: Wan

    H A PT ER Chapter 6 6.1 The WAN Screen The Router must have a WAN interface to allow users to use the Ethernet connection to access the Internet. Use the WAN screen to manage WAN interfaces. Click Network Setting > WAN. Figure 4 Network Setting >...

  • Page 41: Edit Ethernet Connection

    6.1.1 Edit Ethernet Connection In Network Setting > WAN, click the Edit icon next to an Ethernet connection to display the following screen. Use this screen to configure an Ethernet connection. Figure 5 Network Setting > WAN: Edit Table 4 Network Setting > WAN: Edit LABEL DESCRIPTION Active...
  • Page 42 Table 4 Network Setting > WAN: Edit (continued) LABEL DESCRIPTION Mode Select Router (default) if your ISP gives you one IP address only and you want multiple computers to share an Internet account. Select Bridge when your ISP provides you more than one IP address and you want the connected computers to get individual IP address from the ISP’s DHCP server directly.
  • Page 43 Table 4 Network Setting > WAN: Edit (continued) LABEL DESCRIPTION IPv6 Default Enter the default gateway. Gateway IPv6 DNS Server1 Enter the first IPv6 DNS server address. IPv6 DNS Server2 Enter the second IPv6 DNS server address. DHCP IPv6 This is available only when you select Obtain an IP Address Automatically. Select DHCP to obtain an IPv6 address from a DHCPv6 server.

  • Page 44: Chapter 7: Wireless 2.4Ghz

    H A PT ER Wireless 2.4GHz Chapter 7 7.1 Wireless General Screen Use this screen to enable the Wireless LAN, enter the SSID and select the wireless security mode.  If you are configuring the Router from a computer connected to the wireless LAN and you change the Router’s SSID or security settings, you will lose your wireless connection when you press Apply to confirm.
  • Page 45 Table 5 Network Setting > Wireless 2.4GHz > General LABEL DESCRIPTION Wireless Select the Enable Wireless LAN check box to activate the wireless LAN. Nota: You must also set the Router’s physical Wifi/WPS button to ON to use wireless LAN. The Wifi LED should be on. Wireless Enter a descriptive name for the wireless LAN.

  • Page 46: No Security

    Table 5 Network Setting > Wireless 2.4GHz > General (continued) LABEL DESCRIPTION Operating This is the channel currently being used by your AP. Channel Security Mode Select WEP (Basic) or WPA(2)/WPA(2)-PSK (More Secure) to add security on this wireless network. The wireless clients which want to associate to this network must have same wireless security settings as the Router.

  • Page 47: Basic (Wep Encryption)

    7.1.2 Basic (WEP Encryption) If you want to use WEP encryption for the wireless LAN, select WEP in the Security Mode field. Figure 8 Wireless 2.4 > General: Basic (WEP) Table 6 Wireless 2.4 > General: Basic (WEP) LABEL DESCRIPTION Security Level Select WEP to enable WEP data encryption.

  • Page 48: More Secure (Wpa(2))

    7.1.3 More Secure (WPA(2)) Select WPA or WPA2 from the Security Mode field. Figure 9 Wireless 2.4GHz > General: More Secure: WPA(2) Table 7 Wireless 2.4GHz > General: More Secure: WPA(2) LABEL DESCRIPTION Security Mode Select WPA or WPA2 as the security mode. IP Address Enter the IP address of the external authentication server.

  • Page 49: More Secure (Wpa(2)-Psk)

    Table 7 Wireless 2.4GHz > General: More Secure: WPA(2) (continued) LABEL DESCRIPTION WPA Compatible This field is only available for WPA2. Select this if you want the Router to support WPA and WPA2 simultaneously. Group Key Update This is the rate at which the RADIUS server sends a new group key out to all clients. Timer If the value is set to “0”, the update timer function is disabled.

  • Page 50: More Ap Screen

    Table 8 Wireless 2.4GHz > General: WPA(2)-PSK (continued) LABEL DESCRIPTION WPA-PSK This appears when you choose WPA-PSK2 as the Security Mode. Compatible Enable this to allow wireless devices using WPA-PSK security mode to connect to your Router. The Router supports WPA-PSK and WPA2-PSK simultaneously. Group Key Update This is the rate at which the RADIUS server sends a new group key out to all clients.

  • Page 51: Edit More Ap

    7.2.1 Edit More AP Use this screen to edit an SSID profile. Click the Edit icon next to an SSID in the More AP screen. The following screen displays. Figure 12 Wireless 2.4GHz > More AP: Edit Table 10 Wireless 2.4GHz > More AP: Edit LABEL DESCRIPTION 2.4GHz Wireless...

  • Page 52: Mac Authentication Screen

    7.3 MAC Authentication Screen Use this screen to configure the Router to give exclusive access to specific devices (Allow) or exclude specific devices from accessing the Router (Deny). Use this screen to view your Router’s MAC filter settings and add new MAC filter rules. Click Network Setting >...

  • Page 53: The Wps Screen

    7.4 The WPS Screen Use this screen to configure WiFi Protected Setup (WPS) on your Router. WPS allows you to quickly set up a wireless network with strong security, without having to configure security settings manually. Set up each WPS connection between two devices. Both devices must support WPS.
  • Page 54 Table 12 Network Setting > Wireless 2.4GHz > WPS (continued) LABEL DESCRIPTION Method 1 PBC Use this section to set up a WPS wireless network using Push Button Configuration (PBC). Click this button to add another WPS-enabled wireless device (within wireless range of the Router) to your wireless network.

  • Page 55: The Wds Screen

    7.5 The WDS Screen The WDS screen allows you to configure the Router to connect to other APs wirelessly when WDS is enabled. Configure your WDSlinks between the Router and other wireless APs. You need to know the MAC address of the peer device. Once the security settings of peer sides match one another, the connection between devices is made.

  • Page 56: The Wmm Screen

    7.6 The WMM Screen Use the WMM screen to enable or disable Wi-Fi MultiMedia (WMM) wireless networks for multimedia applications. Click Network Setting > Wireless 2.4GHz > WMM. Figure 16 Network Setting > Wireless 2.4GHz > WMM Table 14 Network Setting > Wireless 2.4GHz > WMM LABEL DESCRIPTION Enable WMM of...

  • Page 57: Scheduling Screen

    7.7 Scheduling Screen Use the Scheduling screen to manage schedules that turn off wireless service for power saving purposes. Click Network Setting > Wireless 2.4GHz > Scheduling. Figure 17 Network Setting > Wireless 2.4GHz > Scheduling Table 15 Network Setting > Wireless 2.4GHz > Scheduling LABEL DESCRIPTION WLAN Power Off...

  • Page 58: Add Or Edit Schedule

    7.7.1 Add or Edit Schedule Use this screen to add or edit a wireless LAN schedule. In the Scheduling screen, click Add New Rule or the Edit icon next to an existing schedule. Figure 18 Wireless 2.4GHz > Scheduling: Add New Rule Table 16 Wireless 2.4GHz >...

  • Page 59: Advanced Screen

    7.8 Advanced Screen Use the Advanced screen to configure advanced wireless settings. Click Network Setting > Wireless 2.4GHz > Advanced. Figure 19 Network Setting > Wireless 2.4GHz > Advanced Table 17 Network Setting > Wireless 2.4GHz > Advanced LABEL DESCRIPTION Fragmentation Enter the maximum data fragment size that can be sent.

  • Page 60: Chapter 8: Lan

    H A PT ER Chapter 8 8.1 The LAN Setup Screen Click Network Setting > LAN to open the LAN Setup screen. Use this screen to set the Local Area Network IP address and subnet mask of your Router and configure the DNS server information that the Router sends to the DHCP client devices on the LAN.
  • Page 61 Table 18 Network Setting > LAN > LAN Setup LABEL DESCRIPTION IP Address Enter the LAN IP address you want to assign to your Router. The factory default is 192.168.1.1. IP Subnet Mask Type the subnet mask of your network. The factory default is 255.255.255.0. Your Router automatically computes the subnet mask based on the IP address you enter, so do not change this field unless you are instructed to do so.

  • Page 62: The Static Dhcp Screen

    Table 18 Network Setting > LAN > LAN Setup (continued) LABEL DESCRIPTION VendorID Mode Specify the IPTV’s vendor ID mode type. VendorID Exclude Specify if you want to enable vendor ID exlude. Option240 State Select Enabled to have the Router multimedia acquire values of option 240 when acquiring parameters of WAN2 interface.

  • Page 63: The Ip Alias Screen

    Table 19 Network Setting > LAN > Static DHCP (continued) LABEL DESCRIPTION MAC Address This field displays the MAC address of the client on the LAN. IP Address This field displays the IP address of the client on the LAN. Modify Click the Edit icon to edit the static DHCP settings.

  • Page 64: The Upnp Screen

    Use the IP Alias screen to change your Router’s IP alias settings. Click Network Setting > LAN > IP Alias. Figure 23 Network Setting > LAN > IP Alias Table 21 Network Setting > LAN > IP Alias LABEL DESCRIPTION IP Alias Select Enable to configure another LAN network for the Router.

  • Page 65: The Ipv6 Lan Setup Screen

    The following table describes the labels in this screen. Table 22 Network Settings > LAN > UPnP LABEL DESCRIPTION UPnP Select Enable to activate UPnP. Be aware that anyone could use a UPnP application to open the web configurator's login screen without entering the Router's IP address (although you must still enter the password to access the web configurator).
  • Page 66 Table 23 Network Setting > LAN > IPv6 LAN Setup LABEL DESCRIPTION IPv6 Enable Select this to enable the IPv6 feature on the Router. Link Local Address Select this to enable the Link Local Address feature on the Router. Enable Link Local Address Select Manual to manually enter a link local address.
  • Page 67 Table 23 Network Setting > LAN > IPv6 LAN Setup (continued) LABEL DESCRIPTION LAN IPv6 Select how you want to obtain an IPv6 address: Address Assign • Stateless: The Router uses IPv6 stateless autoconfiguration. RADVD (Router Setup Advertisement Daemon) is enabled to have the Router send IPv6 prefix information in router advertisements periodically and in response to router solicitations.
  • Page 68 Table 23 Network Setting > LAN > IPv6 LAN Setup (continued) LABEL DESCRIPTION Send RA on Select this to have the Router send RA (Router Advertisement) messages to the LAN hosts. Note: The LAN hosts neither generate global IPv6 addresses nor communicate with other networks if you disable this feature.

  • Page 69: Chapter 9: Static Route

    H A PT ER Static Route Chapter 9 9.1 Configuring Static Route Use the Static Route screen to view and configure IP static routes on the Router. Click Network Setting > Routing to open the Static Route screen. Figure 26 Network Setting > Routing > Static Route Table 24 Network Setting >...

  • Page 70: Add/Edit Static Route

    9.1.1 Add/Edit Static Route Click Add New Static Route in the Static Route screen or click the Edit icon next to a rule. Use this screen to configure a static route. Figure 27 Routing > Static Route: Add/Edit Table 25 Routing > Static Route: Add/Edit LABEL DESCRIPTION Destination IP...

  • Page 71: Add/Edit Ipv6 Static Route

    Table 26 Network Setting > Routing > IPv6 Static Route LABEL DESCRIPTION Add New Static Click this to configure a new IPv6 static route. Route Destination IP This is the IP network address of the final destination. Prefix length This is the bit number of the IPv6 subnet mask. Gateway This is the IPv6 address of the gateway.

  • Page 72: The Dns Route Screen

    9.3 The DNS Route Screen A DNS route forwards DNS queries for a specific domain name through a specific WAN interface to its DNS server. The DNS Route screens let you view and configure DNS routes on the Router. Click Network Setting >...

  • Page 73: The Current Route Screen

    Table 29 Network Setting > Routing > DNS Route: Add/Edit LABEL DESCRIPTION Domain Name Enter the domain name you want to resolve. You can use the wildcard character, an “*” (asterisk) as the left most part of a domain name, such as *.example.com. The Router forwards DNS queries for any domain name ending in example.com to the WAN interface specified in this route.

  • Page 74: Chapter 10: Dns Route

    H AP T ER DNS Route Chapter 10 10.1 Overview DNS (Domain Name System) is for mapping a domain name to its corresponding IP address and vice versa. The DNS server is extremely important because without it, you must know the IP address of a machine before you can access it.

  • Page 75: Add/Edit Dns Route

    Table 31 Network Setting > Routing > DNS Route (continued) LABEL DESCRIPTION Domain Name This is the domain name to which the DNS route applies. Subnet Mask This parameter specifies the IP network subnet mask. Interface This is the WAN interface through which the matched DNS request is routed. Modify Click the Edit icon to configure a DNS route on the Router.

  • Page 76: Chapter 11: Quality Of Service (Qos)

    H AP T ER Quality of Service (QoS) Chapter 11 11.1 The QoS General Screen Use this screen to enable or disable QoS, set the bandwidth, and select to have the Router automatically assign priority to upstream traffic according to the IP precedence or packet length. Click Network Setting >...

  • Page 77: The Queue Setup Screen

    11.2 The Queue Setup Screen Use the Queue Setup screen to configure QoS queue assignment. Click Network Setting > QoS > Queue Setup. Figure 36 Network Setting > QoS > Queue Setup Table 34 Network Setting > QoS > Queue Setup LABEL DESCRIPTION Status...

  • Page 78: Edit A Qos Queue

    11.2.1 Edit a QoS Queue Use this screen to configure a queue. Click the Edit icon next to a QoS queue. Figure 37 QoS > Queue Setup: Edit Table 35 QoS > Queue Setup: Edit LABEL DESCRIPTION Active Select to enable or disable this queue. Name Enter the descriptive name of this queue.
  • Page 79 Click Network Setting > QoS > Class Setup to open the following screen. Figure 38 Network Setting > QoS > Class Setup Table 36 Network Setting > QoS > Class Setup LABEL DESCRIPTION Add new Classifier Click this to create a new classifier. Order This is the order of the classifier.

  • Page 80: Add/Edit Qos Class

    11.3.1 Add/Edit QoS Class Click Add new Classifier in the Class Setup screen or the Edit icon next to an existing classifier to configure it. Figure 39 QoS > Class Setup: Add/Edit Chapter 11 Quality of Service (QoS)
  • Page 81 Table 37 QoS > Class Setup: Add/Edit LABEL DESCRIPTION Rule Index Select the (order) number of this rule. Active Select to enable this classifier. Classification Order Select an existing number for where you want to put this classifier to move the classifier to the number you selected after clicking Apply.
  • Page 82 Table 37 QoS > Class Setup: Add/Edit (continued) LABEL DESCRIPTION Port Range If you select TCP or UDP in the IP Protocol field, select the check box and enter the port number(s) of the source. MAC Address Select the check box and enter the destination MAC address of the packet. MAC Mask Type the mask for the specified MAC address to determine which bits a packet’s MAC address should match.
  • Page 83 Table 37 QoS > Class Setup: Add/Edit (continued) LABEL DESCRIPTION DSCP Range (0 ~ Select this option and specify a DSCP (DiffServ Code Point) number between 0 and 63 in the field provided. 802.1P Select this option and select a priority level (between 0 and 7) from the drop-down list box.

  • Page 84: The Qos Monitor Screen

    11.4 The QoS Monitor Screen To view the Router’s QoS packet statistics, click Network Setting > QoS > Monitor. Figure 40 Network Setting > QoS > Monitor Table 38 Network Setting > QoS > Monitor LABEL DESCRIPTION Refresh Interval Enter how often you want the Router to update this screen and click Set Interval. Click Stop to stop refreshing statistics.

  • Page 85: Chapter 12: Network Address Translation (Nat)

    H AP T ER Network Address Translation Chapter 12 (NAT) 12.1 The General Screen Click Network Setting > NAT to open the General screen. You can limit the number of concurrent NAT sessions each client can use. Figure 41 Network Setting > NAT > General Table 39 Network Setting >...
  • Page 86 12.2.1 The Port Forwarding Screen Click Network Setting > NAT to open the Port Forwarding screen. Figure 42 Network Setting > NAT > Port Forwarding Table 40 Network Setting > NAT > Port Forwarding LABEL DESCRIPTION WAN Interface Select the WAN interface for which to configure NAT port forwarding rules. Add new rule Click this to add a new port forwarding rule.

  • Page 87: The Port Forwarding Add/Edit Screen

    12.2.2 The Port Forwarding Add/Edit Screen This screen lets you create or edit a port forwarding rule. Click Add new rule in the Port Forwarding screen or the Edit icon next to an existing rule. Figure 43 NAT > Port Forwarding: Add/Edit Table 41 NAT >...

  • Page 88: The Address Mapping Screen

    Table 41 NAT > Port Forwarding: Add/Edit (continued) LABEL DESCRIPTION Open Start Port Configure this for a user-defined entry. This shows the port number to which you want the Router to translate the incoming port. For a range of ports, enter the first number of the range to which you want the incoming ports translated.

  • Page 89: The Address Mapping Rule Edit Screen

    12.3.1 The Address Mapping Rule Edit Screen Use this screen to edit an address mapping rule. Click the rule’s edit icon in the Address Mapping screen to display the screen shown next. Figure 44 NAT > Address Mapping: Edit Figure 45 NAT > Address Mapping: Edit LABEL DESCRIPTION Type...

  • Page 90: The Dmz Screen

    12.4 The DMZ Screen Click Network Setting > NAT > DMZ to open the DMZ screen. Use this screen to specify the IP address of a default server to receive packets from ports not specified in the Port Forwarding screen. Figure 46 Network Setting >...
  • Page 91 The SIP ALG allows SIP calls to pass through NAT by examining and translating IP addresses embedded in the data stream. When the Router registers with the SIP register server, the SIP ALG translates the Router’s private IP address inside the SIP data stream to a public IP address. You do not need to use STUN or an outbound proxy if you enable the SIP ALG.

  • Page 92: Chapter 13: Dynamic Dns

    H AP T ER Dynamic DNS Chapter 13 13.1 The Dynamic DNS Screen Use the Dynamic DNS screen to enable DDNS and configure the DDNS settings on the Router. Click Network Setting > Dynamic DNS. Figure 48 Network Setting > Dynamic DNS Table 45 Network Setting >...
  • Page 93 Table 45 Network Setting > Dynamic DNS (continued) LABEL DESCRIPTION User This field displays the results of the Router’s attempt to authenticate with the Dynamic Authentication DNS service provider. Result Last Updated This field displays when the Router last updated its WAN IP address to the Dynamic Time DNS service provider.

  • Page 94: Chapter 14: Filter

    H AP T ER Filter Chapter 14 14.1 The IP/MAC Filter Screen Use the IP/MAC Filter screen to create and apply IP/MAC filters. Click Security > Filter to show the IP/MAC Filter screen. Figure 49 Security > Filter > IP/MAC Filter Chapter 14 Filter...
  • Page 95 Table 46 Security > Filter > IP/MAC Filter LABEL DESCRIPTION Rule Type selection Select White List to create a filter rule that allows traffic. Select Black List to create a filter rule that blocks traffic. IP/MAC Filter Rule Index Select the index number of the filter rule. Active Use this field to enable or disable the rule.

  • Page 96: The Ipv6/Mac Filter Screen

    14.2 The IPv6/MAC Filter Screen Use the IPv6/MAC Filter screen to create and apply IPv6 address /MAC filters. Click Security > Filter >IPv6/MAC Filter. Figure 50 Security > Filter > IPv6/MAC Filter Table 47 Security > Filter > IPv6/MAC Filter LABEL DESCRIPTION Rule Type selection...
  • Page 97 Table 47 Security > Filter > IPv6/MAC Filter (continued) LABEL DESCRIPTION Source IP Address Enter the source IP address of the packets you wish to filter. Source Prefix Length Enter the prefix length for the source IPv6 address. Destination IPv6 Address Enter the destination IPv6 address of the packets you wish to filter.

  • Page 98: Chapter 15: Firewall

    H AP T ER Firewall Chapter 15 15.1 TFirewall General Screen Use this screen to enable or disable the firewall protection on the Router. You can also edit existing rules or create new ones. Click Security > Firewall to open the General screen. Figure 51 Security >...

  • Page 99: Add/Edit Interface Default Policy Screen

    15.1.1 Add/Edit Interface Default Policy Screen Use this screen to edit existing firewall rules or create new ones. Click the edit icon next to an existing firewall rule or click the Add button in the General screen. Figure 52 Firewall > General: Add/Edit Table 49 Firewall >...
  • Page 100  The ordering of your rules is very important as rules are applied in turn. Figure 53 Security > Firewall > Rules Table 50 Security > Firewall > Rules LABEL DESCRIPTION Packet Direction Select a direction of travel of packets for which you want to configure firewall rules. Create a new rule Select an index number and click Add to add a new firewall rule after the selected after rule number...

  • Page 101: Rules Edit Screen

    15.2.1 Rules Edit Screen Use this screen to configure firewall rules. In the Rules screen, select an index number and click a rule’s Edit icon. Figure 54 Firewall > Rules: Edit Table 51 Firewall > Rules: Edit LABEL DESCRIPTION Active Select this option to enable this firewall rule.

  • Page 102: Dos Screen

    Table 51 Firewall > Rules: Edit (continued) LABEL DESCRIPTION Destination IP Enter the destination IP address. Address Destination Subnet Enter the destination subnet mask. Mask Destination Port Enter a single destination port or a port range. Action for Matched select whether to discard (Drop), deny and send an ICMP destination-unreachable Packets message to the sender of (Reject) or allow the passage of (Permit) packets that match this rule.

  • Page 103: The Dos Advanced Screen

    15.3.1 The DoS Advanced Screen Click Security > Firewall > DoS > Advanced to display the following screen. Figure 56 Firewall > DoS > Advanced Table 53 Firewall > DoS > Advanced LABEL DESCRIPTION TCP SYN-Request This is the rate of new TCP half-open sessions per second that causes the firewall to Count start deleting half-open sessions.

  • Page 104: Chapter 16: Parental Control

    H AP T ER Parental Control Chapter 16 16.1 The Parental Control Screen Parental control allows you to block web sites with the specific URL. You can also define time periods and days during which the Router performs parental control on a specific user. Use the Parental Control screen to enable parental control, view the parental control rules and schedules.
  • Page 105 Table 54 Security > Parental Control (continued) LABEL DESCRIPTION Website Blocked This shows whether the website block is configured. If not, None will be shown. Modify Click the Edit icon to go to the screen where you can edit the rule. Click the Delete icon to delete an existing rule.

  • Page 106: Add/Edit A Parental Control Rule

    16.1.1 Add/Edit a Parental Control Rule Click Add new PCP in the Parental Control screen to add a new rule or click the Edit icon next to an existing rule to edit it. Use this screen to configure a restricted access schedule and/or URL filtering settings to block the users on your network from accessing certain web sites.
  • Page 107 Table 55 Parental Control: Add/Edit (continued) LABEL DESCRIPTION Internet Access Schedule Select check boxes for the days that you want the Router to perform parental control. Time of Day to Apply: (24-Hour Format) Start Time Enter the time period of each day, in 24-hour format, during which parental control End Time will be enforced.

  • Page 108: Chapter 17: Certificates

    H AP T ER Certificates Chapter 17 17.1 Local Certificates Use the Local Certificates screen to view the Router’s summary list of certificates and certification requests. You can import the following certificates to your Router: • Web Server - This certificate secures HTTP connections. •...

  • Page 109: Trusted Ca

    Table 56 Security > Certificates > Local Certificates (continued) LABEL DESCRIPTION Valid From This field displays the date that the certificate becomes applicable. The text displays in red and includes a Not Yet Valid! message if the certificate has not yet become applicable.

  • Page 110: Trusted Ca Import

    Table 57 Security > Certificates > Trusted CA (continued) LABEL DESCRIPTION Subject This field displays information that identifies the owner of the certificate, such as Common Name (CN), OU (Organizational Unit or department), Organization (O), State (ST) and Country (C). It is recommended that each certificate have unique subject information.

  • Page 111: View Certificate

    17.4 View Certificate Use this screen to view in-depth information about the certification authority’s certificate, change the certificate’s name and set whether or not you want the Router to check a certification authority’s list of revoked certificates before trusting a certificate issued by the certification authority.

  • Page 112: Chapter 18: Voip

    H AP T ER VoIP Chapter 18 18.1 The SIP Account Screen The Router uses a SIP account to make outgoing VoIP calls and check if an incoming call’s destination number matches your SIP account’s SIP number. In order to make or receive a VoIP call, you need to enable and configure a SIP account, and map it to a phone port.

  • Page 113: Edit Sip Account

    18.1.1 Edit SIP Account You can configure a SIP account. To access this screen, click the Edit icon next to an account. Figure 64 SIP > SIP Account: Add/Edit Chapter 18 VoIP...
  • Page 114 Table 61 SIP > SIP Account: Edit LABEL DESCRIPTION Enable SIP Select the check box to use this account. Clear it to not use this account. Account SIP Account Enter your SIP number. In the full SIP URI, this is the part before the @ symbol. Number Username Enter the user name for registering this SIP account, exactly as it was given to you.
  • Page 115 Table 61 SIP > SIP Account: Edit (continued) LABEL DESCRIPTION Active Busy Select this if you want the Router to forward incoming calls to the specified phone Forward number if the phone port is busy. Specify the phone number in the To Number field on the right. If you have call waiting, the incoming call is forwarded to the specified phone number if you reject or ignore the second incoming call.

  • Page 116: The Sip Service Provider Screen

    18.2 The SIP Service Provider Screen Use this screen to manage profiles of SIP service provider settings. Click VoIP > SIP > SIP Service Provider to open the SIP Service Provider screen. Figure 65 VoIP > SIP > SIP Service Provider Table 62 VoIP >...

  • Page 117: Edit Sip Service Provider

    18.2.1 Edit SIP Service Provider Use this screen to configure the SIP server information, QoS for VoIP calls, the numbers for certain phone functions and dialing plan for a SIP service provider. Click VoIP > SIP > SIP Service Provider and then click the Edit icon next to a profile of SIP service provider settings to open the following screen.
  • Page 118 Figure 67 SIP > SIP Service Provider > Edit (continued) Table 63 SIP > SIP Service Provider: Edit LABEL DESCRIPTION SIP Service Select this if you want the Router to use this SIP provider. Clear it if you do not want Provider the Router to use this SIP provider.
  • Page 119 Table 63 SIP > SIP Service Provider: Edit (continued) LABEL DESCRIPTION PRACK (RFC 3262) RFC 3262 defines a mechanism to provide reliable transmission of SIP provisional response messages, which convey information on the processing progress of the request. This uses the option tag 100rel and the Provisional Response ACKnowledgement (PRACK) method.
  • Page 120 Table 63 SIP > SIP Service Provider: Edit (continued) LABEL DESCRIPTION T38 Fax Relay Select this if the Router should send fax messages as UDP or TCP/IP packets through IP networks. This provides better quality, but it may have inter-operability problems. The peer devices must also use T.38.
  • Page 121 Table 63 SIP > SIP Service Provider: Edit (continued) LABEL DESCRIPTION Call Waiting This code is used to turn the call waiting feature on. With call waiting, you hear a Enable special beep notifying you of another incoming call while you have a call. It allows you to place the first incoming call on hold and answer the second call so that you won’t miss any important calls.

  • Page 122: Phone Screen

    Table 63 SIP > SIP Service Provider: Edit (continued) LABEL DESCRIPTION Outgoing SIP Enter the key combinations that you can enter to select the SIP account that you use to make outgoing calls. If you enter #12(by default)<SIP account index number>#<the phone number you want to call>, #1201#12345678 for example, the Router uses the first SIP account to call 12345678.

  • Page 123: Call Rule Screen

    18.4 Call Rule Screen Use this screen to add, edit, or remove speed-dial numbers for outgoing calls. Speed dial provides shortcuts for dialing frequently-used (VoIP) phone numbers. You also have to create speed-dial entries if you want to call SIP numbers that contain letters. Once you have configured a speed dial rule, you can use a shortcut (the speed dial number, #01 for example) on your phone's keypad to call the phone number.

  • Page 124: Chapter 19: System Monitor

    H AP T ER System Monitor Chapter 19 19.1 The Log Screen Click System Monitor > Log to open the Log screen. Use the Log screen to see the system logs for the categories that you select in the upper left drop-down list box. Figure 70 System Monitor >...

  • Page 125: The Wan Traffic Status Screen

    19.2 The WAN Traffic Status Screen Click System Monitor > Traffic Status to open the WAN Traffic Status screen. You can view the WAN traffic statistics in this screen. Figure 71 System Monitor > Traffic Status > WAN Table 67 System Monitor > Traffic Status > WAN LABEL DESCRIPTION Status...

  • Page 126: The Lan Traffic Status Screen

    19.3 The LAN Traffic Status Screen Click System Monitor > Traffic Status > LAN to open the following screen. You can view the LAN traffic statistics in this screen. Figure 72 System Monitor > Traffic Status > LAN Table 68 System Monitor > Traffic Status > LAN LABEL DESCRIPTION Refresh Interval...

  • Page 127: The Nat Traffic Status Screen

    19.4 The NAT Traffic Status Screen Click System Monitor > Traffic Status > NAT to open the following screen. You can view the NAT status of the Router’s clients in this screen. Figure 73 System Monitor > Traffic Status > NAT Table 69 System Monitor >...

  • Page 128: The Voip Status Screen

    19.5 The VoIP Status Screen Click System Monitor > VoIP Status to open the following screen. You can view the VoIP traffic statistics in this screen. Figure 74 System Monitor > VoIP Status Table 70 System Monitor > VoIP Status LABEL DESCRIPTION Refresh Interval...
  • Page 129 Table 70 System Monitor > VoIP Status (continued) LABEL DESCRIPTION Last Incoming This field displays the last number that called the SIP account. The field is blank if no Number number has ever dialed the SIP account. Last Outgoing This field displays the last number the SIP account called. The field is blank if the SIP Number account has never dialed a number.

  • Page 130: Chapter 20: User Account

    H AP T ER User Account Chapter 20 20.1 Overview You can configure the system password in the User Account screen. 20.2 The User Account Screen Use the User Account screen to configure system password. Click Maintenance > User Account to open the following screen. Figure 75 Maintenance >...
  • Page 131 H AP T ER TR-069 Client Chapter 21 21.1 The TR-069 Screen Click Maintenance > TR-069 Client to open the following screen. Use this screen to configure your Router to be managed by an ACS. Figure 76 Maintenance > TR-069 Client Table 72 Maintenance >...

  • Page 132: Chapter 21 Tr-069 Client

    Table 72 Maintenance > TR-069 Client (continued) LABEL DESCRIPTION Connection The default port for access to the Router from the management server is the HTTP port, Request Port port 80. If you change it, make sure it does not conflict with another port on your network and it is recommended to use a port number above 1024 (not a commonly used port).

  • Page 133: Chapter 22: System

    H AP T ER System Chapter 22 22.1 The System Screen Use the System screen to configure the system’s inactivity time-out interval. Click Maintenance > System to open the following screen. Figure 77 Maintenance > System Table 73 Maintenance > System LABEL DESCRIPTION Administrator...

  • Page 134: Chapter 23: Time Setting

    H AP T ER Time Setting Chapter 23 23.1 The Time Setting Screen To change your Router’s time and date, click Maintenance > Time. The screen appears as shown. Use this screen to configure the Router’s time based on your local time zone. Figure 78 Maintenance >...
  • Page 135 Table 74 Maintenance > System > Time Setting (continued) LABEL DESCRIPTION Daylight Savings Daylight saving is a period from late spring to early fall when many countries set their clocks ahead of normal local time by one hour to give more daytime light in the evening.

  • Page 136: Chapter 24: Log Setting

    H AP T ER Log Setting Chapter 24 24.1 The Log Setting Screen To change your Router’s log settings, click Maintenance > Log Setting. The screen appears as shown. Figure 79 Maintenance > Log Setting Chapter 24 Log Setting...
  • Page 137 Table 75 Maintenance > Log Setting LABEL DESCRIPTION Syslog Logging Select the Active check box to enable syslog logging. Mode Select Local File to have the Router save the log file locally. Select Local File and Remote to have the Router save the log file locally and send it to an external syslog server.
  • Page 138 Table 75 Maintenance > Log Setting (continued) LABEL DESCRIPTION Alarm Interval Specify the number of seconds between the sending of alarm log e-mails. Log Category Select the categories of logs that you want to record. Log Level Select the severity level of logs that you want to record. If you want to record all logs, select ALL.

  • Page 139: Chapter 25: Firmware Upgrade

    H AP T ER Firmware Upgrade Chapter 25 25.1 The Firmware Upgrade Screen Click Maintenance > Firmware Upgrade to open the following screen. The upload process uses HTTP (Hypertext Transfer Protocol) and may take up to three minutes. After a successful upload, the system will reboot.
  • Page 140 After you see the firmware updating screen, wait a few minutes before logging into the Router again. Figure 81 Firmware Uploading The Router automatically restarts in this time causing a temporary network disconnect. In some operating systems, you may see the following icon on your desktop. Figure 82 Network Temporarily Disconnected After two minutes, log in again and check your new firmware version in the Status screen.

  • Page 141: Chapter 26: Backup/Restore

    H AP T ER Backup/Restore Chapter 26 26.1 The Backup/Restore Screen Click Maintenance > Backup/Restore. Information related to factory defaults, backup configuration, and restoring configuration appears in this screen, as shown next. Figure 84 Maintenance > Backup/Restore Backup Configuration Backup Configuration allows you to back up (save) the Router’s current configuration to a file on your computer.
  • Page 142 Restore Configuration Restore Configuration allows you to upload a new or previously saved configuration file from your computer to your Router. Table 77 Restore Configuration LABEL DESCRIPTION File Path Click Choose File and find the file you want to restore. Upload Click this to begin the upload process.

  • Page 143: The Reboot Screen

    Reset to Factory Defaults Click the Reset button to clear all user-entered configuration information and return the Router to its factory defaults. The following warning screen appears. Figure 86 Reset Warning Message Figure 87 Reset In Process Message You can also press the Reset button on the back panel to reset the factory defaults of your Router. Refer to Chapter 1 on page 9 for more information on the Reset button.

  • Page 144: Chapter 27: Remote Management

    H AP T ER Remote Management Chapter 27 27.1 The General Screen Remote management allows you to determine which services/protocols can access which Router interface (if any) from which computers. Click Maintenance > Remote MGMT to display the General screen. Select Enable to activate remote management on the Router.
  • Page 145 Maintenance > Remote MGMT > WWW Table 78 Maintenance > Remote MGMT > WWW LABEL DESCRIPTION Server Port This displays the service port number for accessing the Router using HTTP or HTTPS. If the number is grayed out, it is not editable. Server Access Select the interfaces through which a computer may access the Router using this service.

  • Page 146: Telnet Screen

    27.3 Telnet Screen You can use Telnet to access the Device’s command line interface. Specify which interfaces allow Telnet access and from which IP address the access can come. Click Maintenance > Remote MGMT > Telnet tab to display the screen as shown. Figure 89 Maintenance >...
  • Page 147 Use this screen to specify which interfaces allow FTP access and from which IP address the access can come. To change your Router’s FTP settings, click Maintenance > Remote MGMT > FTP. The screen appears as shown. Figure 90 Maintenance > Remote MGMT > FTP Table 80 Maintenance >...

  • Page 148: Snmp Screen

    27.5 SNMP Screen To change your Router’s SNMP settings, click Maintenance > Remote MGMT > SNMP tab. The screen appears as shown. Figure 91 Maintenance > Remote MGMT > SNMP Table 81 Maintenance > Remote MGMT > SNMP LABEL DESCRIPTION Server Port This displays the port the SNMP agent listens on.

  • Page 149: Dns Screen

    Table 81 Maintenance > Remote MGMT > SNMP (continued) LABEL DESCRIPTION Get Community Enter the Get Community, which is the password for the incoming Get and GetNext requests from the management station. The default is public and allows all requests. Set Community Enter the Set community, which is the password for incoming Set requests from the management station.

  • Page 150: Icmp Screen

    Table 82 Maintenance > Remote MGMT > DNS (continued) LABEL DESCRIPTION Access Status Select the interfaces through which a computer may send DNS queries to the Router. Secured Client IP A secured client is a “trusted” computer that is allowed to send DNS queries to the Address Router.

  • Page 151: Ssh Screen

     If you want your device to respond to pings and requests for unauthorized services, you will also need to configure the firewall accordingly by disabling SPI. Figure 93 Maintenance > Remote MGMT > ICMP Table 83 Maintenance > Remote MGMT > ICMP LABEL DESCRIPTION Respond to Ping...
  • Page 152 Click Maintenance > Remote MGMT > SSH tab to display the screen as shown. Figure 94 Maintenance > Remote MGMT > SSH Table 84 Maintenance > Remote MGMT > SSH LABEL DESCRIPTION Server Port This displays the service port number for accessing the Router. If the number is grayed out, it is not editable.

  • Page 153: Chapter 28: Diagnostic

    H AP T ER Diagnostic Chapter 28 28.1 The Diagnostic Screen Ping and traceroute help check availability of remote hosts and also help troubleshoot network or Internet connections. Click Maintenance > Diagnostic to open the Diagnostic screen shown next. Figure 95 Maintenance > Diagnostic Table 85 Maintenance >...

  • Page 154: Chapter 29: Troubleshooting

    H AP T ER Troubleshooting Chapter 29 29.1 Overview This chapter offers some suggestions to solve problems you might encounter. The potential problems are divided into the following categories. • Power, Hardware Connections, and LEDs • Router Access and Login •...

  • Page 155: Router Access And Login

    Inspect your cables for damage. Contact the vendor to replace any damaged cables. Turn the Router off and on. If the problem continues, contact the vendor. 29.3 Router Access and Login  I forgot the IP address for the Router. The default IP address is 192.168.1.1.

  • Page 156: Internet Access

    If the problem continues, contact the network administrator or vendor, or try one of the advanced suggestions. Advanced Suggestions • Try to access the Router using another service, such as Telnet. If you can access the Router, check the remote management settings and firewall rules to find out why the Router does not respond to HTTP.

  • Page 157: Wireless Internet Access

    If you are trying to access the Internet wirelessly, make sure the wireless settings in the wireless client are the same as the settings in the AP. If you are trying to access the Internet wirelessly, make sure you have enabled the wireless LAN by the Wifi/WPS button or the Network Setting >...

  • Page 158: Phone Calls And Voip

    • Electrical devices: microwaves, monitors, electric motors, cordless phones, and other wireless devices. To optimize the speed and quality of your wireless connection, you can: • Move your wireless device closer to the AP if the signal strength is low. •...
  • Page 159 The Telf light should come on. Make sure that your telephone is connected to the Telf1 port. You can also check the VoIP status in the System Info screen. If the VoIP settings are correct, use speed dial to make peer-to-peer calls. If you can make a call using speed dial, there may be something wrong with the SIP server, contact your VoIP service provider.

  • Page 160: Appendix A: Safety Warnings

    P P EN D IX Safety Warnings Appendix A • Do NOT use this product near water, for example, in a wet basement or near a swimming pool. • Do NOT expose your device to dampness, dust or corrosive liquids. •...
