- Page 1 USERS MANUAL AL-83056 ALCO Sales & Service Co. 6851 High Grove Blvd, Burr Ridge, IL 60527 800-323-4282 www.alcosales.com...
- Page 2 COMPONENTS Your power wheelchair is shipped partially dissembled to protect it during shipping. After unpacking, please check whether you have received the following main components as our standard specification (See Fig.1). 1. Chassis 6. Handle support frame 2. Seat 7.Footrest frame (Right) 3.
-
Page 3: Safety Instruction
SAFETY INSTRUCTION Operation of Wheelchair 1.Always ensure that the power is switched off when getting in or out of the wheelchair. This will eliminate the possibility of causing injury to yourself or others. 2.Always check that the drive wheels are engaged (drive mode) before driving. 3.Set the speed control knob according to your driving ability and the environment in which you are going to operate. -
Page 4: Use While Under The Influence Of Medication Or Alcohol
General 12. Always use a seat belt, and keep your feet on the wheelchair all the time. 13. For safety reasons, make sure that your weight does not exceed the recommended weight limit of the wheelchair. Consult your dealer for the specified weight limits for your particular model. - Page 5 damage the power scooter’s control system. The intensity of the EM energy can be measured in volts per meter (V/m). Each power scooter can resist EMI up to a certain intensity. This is called “immunity level”. The higher the immunity level, the greater the protection.
-
Page 6: Environmental Conditions
ENVIRONMENTAL CONDITIONS Environmental conditions may affect the safety and performance of your power wheelchair. Water and extreme temperatures are the main elements that can cause damage and affect performance. A) Rain, Sleet and Snow If exposed to water, your power wheelchair is susceptible to damage to electronic or mechanical components. -
Page 7: Assembly Instruction
ASSEMBLY INSTRUCTION Follow the procedures listed below for easy assembly of your wheelchair: 1. Installing the Seat (#2) Insert the handle support frame (#6) into the seat frame and use the Allan key to tighten the frame. (See Fig 2, 3) Allan key Handle support frame... - Page 8 2. Installing the Handle Bar (#4) Insert the handle bar (#4) into the handle support frame. Put the ball pin into the desired hole and tighten the quick release lever. (See Fig 7, 8) Quick Ball Pin release Lever Handle Bar (Fig 7) (Fig 8) Then connect the hardness plug.
-
Page 9: Adjustments For Seating Comfort
(Fig 11) (Fig 12) ADJUSTMENTS FOR SEATING COMFORT To maximize seating comfort, your power wheelchair lets you adjust: →Tiller angle →Armrest folding →Seat rotation →Backrest folding A. Tiller Angle Adjustment → loosen the angle adjustment lever → pull up the tiller and adjust the angle →... - Page 10 (Fig 15) D. Backrest Folding Adjustment You can fold your backrest by pulling the tension knob, then the tension knob will lock into the corresponding notch. (See Fig16) Tension Knob (Fig 16) www.alcosales.com...
-
Page 11: Operation
OPERATION The power wheelchair is simple to operate. However, we recommend that you carefully read the following instructions to become familiarized with your new vehicle. A Word of Caution: Before you turn the power on, always be aware of the environment that surrounds you to select your desired speed. - Page 12 2. Manual Speed Adjuster: This allows you to pre-select your desired speed. The adjuster is proportional to speed and can be set anywhere between 1 and 5 increments. Turn the adjuster knob counter-clockwise to minimum for a very gentle operation, and clockwise towards maximum to increase your speed. 3.
-
Page 13: Controller Display
for a few seconds during the self-checking process →When the vehicle is in operation, the surface of the charger will become slightly hot →In case of emergency, let go of the finger lever control and the vehicle will come to a stop B. -
Page 14: Thermal Protection
Your power wheelchair comes with electromagnetic brakes, i.e. an automatic magnetic disc safety brake which is also known as a fail-safe brake. The electro- magnetic brakes are automatic and work when the power wheelchair is ON but in a steady state (i.e. when the wigwag is released to the neutral position), even when the wheelchair is on a slope. -
Page 15: Batteries And Charger
BATTERIES & CHARGER BATTERY We recommend that you use deep-cycle batteries that are sealed and maintenance free for your power wheelchair. Both sealed lead-acid (SLA) and gel cell are deep-cycle batteries and are similar in performance. Deep-cycle batteries are specifically designed to provide power, drain down, and then accept a relatively quick recharge. - Page 16 →Plug the other end of the power cord into a standard wall outlet. →When charging is completed, fuel capacity indicator is shown. →Disconnect the charger power cord from the wall outlet when the batteries are fully charged. Charge Port Door (Fig 21) Important! Do not use for voltage input except the specified.
- Page 17 batteries fully charge for at least once every month. According to the battery type and condition of the batteries, batteries usually can be fully charged in 4-10 hours. This will be indicated when the status light in the battery charger side panel turns green; charging the battery longer than necessary will not harm the battery.
-
Page 18: Maintenance And Repair
MAINTENANCE & REPAIR Your power wheelchair is designed for minimal maintenance. However, like any motorized vehicle it requires routine maintenance. To keep your power chair for years of trouble-free operation, we recommend you follow the following maintenance checks as scheduled. DAILY CHECKS 1. - Page 19 Number of Fault Impact on Notes Flashes wheelchair Battery needs Will drive Battery charge is running low. Recharge the batteries as soon as recharging possible. Battery Drive Battery charge is empty. Recharge the batteries. If the voltage too inhibited wheelchair is left off for a few minutes, battery charge may recover sufficiently to allow driving for a short period of time.
- Page 20 Motor Brush caps New Motor Brush Worn Motor Brush (Fig 24) (Fig 25) 2. Inspect the state of the battery terminals every six months. Make sure that they are not corroded and the connections are tight. Periodically apply a thin film of petroleum jelly on the surface of terminals to guard against corrosion.
- Page 21 5. Jerky motion 6. Pulling to one side 7. Bent or broken wheel assemblies 8. Does not power up 9. Powers up, but does not move ALCO Sales & Service Co. 6851 High Grove Blvd, Burr Ridge, IL 60527 800-323-4282 www.alcosales.com...
