U s e r M a n u a l
PSC40

PRODUCT FEATURES:

Image Sensor: 1099 HD CCD
TV Lines: 480
Lumen: 0.1 Lux
Horizontal Angle: 170 Degrees
Vertical Angle: 120 Degrees
TV System: NTSC/PAL
Video Output: 1.0V p-p 75ohm
Operating Voltage: 12V DC (Negative Ground)
Current Consumption: 120mA @ 13.8V
Waterproof Rating: IP68
Operating Temperature: -20 Degrees C to +70 Degrees C
Parking Lines: Yes
Image: Mirror/Normal
Enhanced performance in low light: Yes

DISCLAIMER:

Prior to Installation
Read the manual prior to installation. Technical knowledge is necessary for installation. Please
ensure you use the correct tools to avoid damage to the vehicle or product.
Parksafe can not be held responsible for the installation of this product.

Technical Support

Parksafe want to provide a fast and suitable resolution should you encounter any technical
issues. With this in mind, when contacting Parksafe, try to provide as much information as
possible. This will speed up the process and help us to help you.
Please use our dedicated online technical support centre: Technical@parksafeautomotive.com
Rearview Camera

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSC40 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Parksafe PSC40

  • Page 1 Parksafe want to provide a fast and suitable resolution should you encounter any technical issues. With this in mind, when contacting Parksafe, try to provide as much information as possible. This will speed up the process and help us to help you.
  • Page 2 CONTENTS - Camera with 1m cable to mini male 6 pin connector - 1m camera connection cable with mini female 6 pin connector and RCA female connector - 6m Male to Male RCA extension cable - 18mm hole saw - Instructions INSTALLATION 1.
