AirID FIDO Mini - User Manual
Thank you for purchasing the AirID FIDO Mini. Before using AirID FIDO
Mini, please take the time to read this user manual, to learn about all the
features and capabilities of your new AirID FIDO Mini.
Table of Content
Intended Use
AirID FIDO is a wireless Security Key that you can carry with you at all times. The AirID FIDO communicates via a secure Bluetooth Low Energy (BLE)
connection with your device and makes the internal FIDO Security Key available for cryptographical operations such as authentication.
Questions / Support
For more information about our products & services, please visit our website:
For technical assistance & support, please visit
Or create a support ticket here:
certgate GmbH
Kaiserswerther Straße 45
40477 Düsseldorf
Germany
https://airid.com/service-portal
create a support request
https://airid.com/en/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FIDO Mini and is the answer not in the manual?

Questions and answers

Summary of Contents for AiRide FIDO Mini

  • Page 1: Table Of Contents

    AirID FIDO Mini - User Manual Thank you for purchasing the AirID FIDO Mini. Before using AirID FIDO Mini, please take the time to read this user manual, to learn about all the features and capabilities of your new AirID FIDO Mini.

  • Page 2: About This Guide

    The AirID FIDO is a family of wireless, flexible FIDO Security Keys, providing secure FIDO compliant strong, hardware based user authentication. They are available either in a very small form factor (the AirID FIDO Mini) or as a BADGE holder (the AirID FIDO BADGE) to hold and present standard ID cards.

  • Page 3: Hardware Features

    2 Low Power LCD Display 3 2-button navigation 4 LED indicator 5 USB interface Control Element AirID FIDO Mini is designed for easy menu navigation using a 2-button-navigation. Button Meaning left Long keypress: switching the device On / Off Short keypress: scrolling down...

  • Page 4: Menu Layout

    Color Mode Meaning Static on during battery charging; off when battery charging is done blue Static on during bluetooth communication activities blue Blinking ongoing FIDO communication - User Presence, waiting for input 3. Menu Layout In the AirID FIDO device menu, you can configure various settings and get status information about your AirID FIDO security key. You can access the different menu entries by navigating with the control element.

  • Page 5: Settings

    Pairing Code This menu is only shown the first time a connection is established with a host device and is used to display Pairing Code the pairing key. 123456 To confirm the displayed code on your AirID FIDO select 'Yes' and confirm using the control element. Pairing Code 123456 Pairing...
  • Page 6 FIDO User Activate or deactivate the acoustic feedback of the AirID FIDO. FIDO User Signal Signal > FIDO User Signal > Prefer With this setting you can manage your AirID FIDO Bluetooth connections to your Prefer Device Device host systems: >...

  • Page 7: Airid Info

    Reset LTK This setting deletes the saved LTK keys. You have the option to delete all keys or Reset LTK Key Keys only the keys for a specific device. > Reset LTK Key > Confirm: Reset LTK Key > 'Device Name' Reset LTK Key >...

  • Page 8: Firmware Update

    Board Version of the AirID FIDO board Board Ver A2XX1.1.0 Bootloader Version of the AirID FIDO boot loader Bootloader Ver 202002 Firmware Version of the AirID FIDO firmware version Firmware 2.1.0 Back Select Back to return to the main menu Back <...

  • Page 9: Using Airid Fido Mini

    5.1 Using AirID FIDO Mini To setup and use the AirID FIDO Mini follow these three simple steps: 1. Pair your AirID FIDO with your host device* Follow the steps below to set up the Bluetooth pairing: Turn on your AirID FIDO...

  • Page 10: Safety Instructions

    Item AirID FIDO Mini Enclosure Shape similar to a key fob Dimension 72 x 38 x 14 mm Weight 36 g Human interface Display type LCD, 128x128 Display size ca. 25 x 25 mm Control element 2 button logic USB port USB-2.0-Micro-B...

  • Page 11: Disposal And Recycling

    8. Disposal and Recycling The device must not be disposed of with household waste. B2B equipment must be returned to the manufacturer. 9. Maintenance and Care Clean the device only with a soft, clean and dry cloth. Do not expose the device to harsh chemicals, cleaning solutions or strong cleaning agents. Do not allow liquid to penetrate the product.
