- Page 1 User Manual Model: PDVR-1000 1. Name of each part ① Neck Strap Holder ② Built-in Microphone ③ Hold Key ④ Stop/ESC ⑤ Rec./Pause ⑥ Menu in the recording modes ⑦ Volume down ⑧ Volume up ⑨ RW ⑩ FF ⑪ Play/Stop ⑫...
- Page 2 16 micro SD card slot/USB jack 17 Reset 2. LCD ① Date ② Time ③ Current Memory Storage ④ Speaker On/Off ⑤ Volume Level ⑥ Battery Status ⑦ Current selected menu 3. Quick operation of each button Long Key Short Key Power On/Off Play/Pause in Playing a file.
- Page 3 4. Structure of Main Menu RECORD VIDEO AUDIO IMAGE SETTING 1) RECORD Record an input signal (Video & Audio) from the connected camera. The file recorded in this mode is stored at the Video Folder. 2) VIDEO A recorded video file(s) is stored in the Video folder and the file(s) is played back in this menu. 3) AUDIO A recorded audio only file(s) is stored in the Audio folder and the file(s) is played back in this mode.
- Page 4 a camera is shown on the LCD with "Preview" in red camera is shown on the LCD with "Preview" in red on the right of the LCD before recording. on the right of the LCD before recording. ☞If a camera is not connected or connected in loose, "No Signal"...
- Page 5 ☞ Making a new file while recoding If pressing while recording, the recording file is separated with a new file name. The recording file is stored in “Video Folder” ☞ Changing a setup value While recording, Recording time & Microphone sensitivity are changeable by pressing without stopping the recording.
- Page 6 - Press to stop recording. Recording 2. By Rec. Button - Press to enter into the monitoring. - Press once again to start recording and press it again for pause. - Re-start recording by pressing Press to stop recording. ☞ Making a new file while recoding If pressing while recording, the recording file is separated with a new file name.
- Page 7 Press to preview before taking a photo. Press to preview at the RECORD Mode. If so, Live image from a camera is shown on the LCD Live image from a camera is shown on the LCD with "Preview" in red on the right of the LCD. with "Preview"...
- Page 8 ☞ On the file list, if pressing with short key, submenu(Playback/File Delete/File Protect/File Information) is appeared. Playback: Play a selected file back. File Delete: Delete a selected file.(No, One, All) File Protect: The file with File Protect won’t be deleted.(Off, On) File Information: File name, size, Time, Protect status are displayed.
-
Page 9: Operation Is Subject To The Following Two Conditions
Model: PDVR-1000 ANSI C63.4: 2003 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS. 1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND 2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
